Ptlease read the manual before using the product. The manual and carton
contain important information, please keep them properly for later
reference.Failure to follow the instructions may be dangerous to children.In
order to improve the product and quality, we may change some of the
structure,appearance, packing method, assembly method and function without
any notice. When there is any difference between the manual and the product,
please refer to the actual product. We are sorry for any inconvenience.
Manual of Battery Powered Car
Products should be assembled by an adult. Protective equipment should be worn. Not to
be used in traffic. Not suitable for children under 3 years.
Choking hazard- small parts. There are potentially hazardous small parts in an
unassembled state. Please keep out of the reach of small children. Pay attention to the
potential hazards of using the toy in areas other than private grounds.
Executive standard:
WARNING
Advertisement
Related Manuals for Tobbi TH17P0977
Summary of Contents for Tobbi TH17P0977
- Page 1 Ptlease read the manual before using the product. The manual and carton contain important information, please keep them properly for later reference.Failure to follow the instructions may be dangerous to children.In order to improve the product and quality, we may change some of the structure,appearance, packing method, assembly method and function without any notice.
- Page 2 PARTS LIST Part Name Picture Quantity Part Name Picture Quantity Number Number Steering Car body wheel Seat backrest Wind Front deflector bumper Front Handrail wheel Rear Wheel wheel cover Rear Drive shaft motor Charger...
- Page 3 ASSEMBLY INSTRUCTIONS 1.Install the wheel Install the wheel on the shaft, fit the 8mm nut with a wrench,and install the wheel cover. 2.Install the steering wheel First connect the wire on the steering wheel with the wire on the body, and then clamp the steering wheel at the specified position.
- Page 4 3.Install the wind deflector Insert the wind deflector into the specified position of the vehicle body. 4.Install the bumper Insert the bumper into the specified position of the body. 5.Connect the power supply Open the seat and connect the two plugs.
- Page 5 6.Install the backrest Insert the backrest into the body and fix it with two 4*12mm screws. 6.Install the seat Put the seat into the bottom of the backrest, then lay it flat and insert it into the body. 7.Mount the handrails Insert directly into both sides of the body as shown in the figure.
- Page 6 PRODUCT SPECIFICATIONS Battery 12V4.5 Main material Suitable age 37-60 Months Weight limit 66 lbs Product size 37 x 24 x 20 Inches Carton Size 35 x 19 x 13 Inches Speed 3-5km/h 1-2 hours after charging for 8-12 hours, Runtime based on riding conditions 12V0.5A Charger...
- Page 7 Attention: ·Do not use incorrect batteries or chargers. ·Do not mix old and new or different types of batteries. ·The battery terminal should not be short circuit. ·Do not open the battery or charger. ·Do not leave batteries up side down when charging. ·Check the charger, battery and plug before charging.
- Page 8 MAINTENANCE AND SERVICE 1.Parents should check whether all the parts are in good condition before use, like the battery, charger, wire, plug, body and other parts,whether any screws are loose,whether there are potential safety hazards. If found, it must be repaired. 2.Wipe moving parts with a small amount of lubricating oil to prevent wear parts from rusting after using the toys for some time.
- Page 9 10.Don't put toys for other purposes. Put batteries in the right polarity. 11.Do not short-circuit the negative battery. Non rechargeable batteries, can't be charged. 12.Chargeable batteries can only be charged uder adult supervision. 13.Don’t mix old or new batteries or different types of batteries. 14.Exhausted batteries should be removed from the toy properly to prevent children from playing.
