  • Page 1 2023 MD500-PLUS Quick Guide INOVANCE TECHNOLOGY EUROPE V1.0...
  • Page 3 Introduction The MD500-PLUS series AC drive is a general-purpose high-performance vector control AC drive designed to control and regulate the speed and torque of three-phase AC asynchronous motors and permanent magnet synchronous motors. It can be used to drive textile machines, paper machines, wire drawing machines, machine tools, packaging machines, food machines, fans, water pumps, and other automated production equipment.

  • Page 4: Fundamental Safety Instructions

    Use this equipment according to the designated environment requirements. Damage caused by improper use is not covered by warranty. Inovance shall take no responsibility for any personal injuries or property damage caused by improper use.
  • Page 5  Never stand or stay below the equipment when the equipment is being hoisted by the hoisting equipment.  When hoisting the equipment with a steel rope, ensure the equipment is hoisted at a constant speed without suffering from vibration or shock. Do not turn the equipment over or let the equipment stay hanging in the air.
  • Page 6 Wiring  Equipment installation, wiring, maintenance, inspection, or parts replacement must be performed only by professionals.  Before wiring, cut off all the power supplies of the equipment, and wait for at least the time designated on the equipment warning label before further operations because residual voltage exists after power-off.
  • Page 7 Operation  The equipment must be operated only by professionals. Failure to comply will result in death or personal injuries.  Do not touch any connecting terminals or disassemble any unit or component of the equipment during operation. Failure to comply will result in an electric shock. ...

  • Page 8: Installation Location

    Failure to comply may result in an electric shock. 2. Environment. When installing MD500-PLUS drive please observe the environmental conditions described in table 1 below, for a long life and safe operation. Table 1. Environmental conditions in the installation location of MD500-PLUS drive.
  • Page 9 3. Product model list, frames and dimensions. The following table below lists the MD500-PLUS drive models and frames. Table 2. MD500-PLUS drive models and frames. Three Phase 380–480 V Three Phase 200–240 V Single Phase 200‑240 V Frame models models models MD500T0.4G/0.7PB-PLUS...
  • Page 10 4. External dimensions and mounting dimensions of MD500-PLUS drives. 4.1 Dimensions of T1 to T4 frames models. Figure 1. External dimensions and mounting dimensions of T1 to T4 frames models. Table 3. External and mounting dimensions of T1 to T4 frames models.
  • Page 11 4.3 Dimensions of T7 to T9 models. Figure 3. External dimensions and mounting dimensions of T7 to T9 frames models. Table 5. External and mounting dimensions of T7 to T9 frames models. Mounting Holes Spacing External Dimensions Mounting mm (in.) mm (in.) Holes Mass...

  • Page 12: Mounting Clearances

    4.4.2 Models with output reactor. Figure 5. External dimensions and mounting dimensions of T10 to T12 frames models with output reactor. Table 7. External dimensions and mounting dimensions of T10 to T12 frames models with output reactor. Mounting Mounting Holes Spacing External Dimensions Holes Mass...
  • Page 13 D2 ≥ 20 6. Basic keypad operation. Figure 8 below describes the keys and LED indicators of the built-in keypad of MD500-PLUS drive. Figure 8. Keys and LED indicators of the built-in keypad of MD500-PLUS drive. Table 10 below describes the functions of the keys of the built-in keypad of MD500-PLUS drive.
  • Page 14 Switchover between menu modes as defined by the setting of FP-03 selection key (user-defined and/or modified parameters display selection). Table 11 below describes the functions of the LED indicators of the built-in keypad of MD500-PLUS drive. Table 11. Functions of the LED indicators of the built-in keypad of MD500-PLUS.
  • Page 15 Figures 9 and 10 below show the procedure to view and modify the value set in a parameter. Figure 9. How to view the value set in a parameter. Figure 10. How to edit/modify the value set in a parameter.

  • Page 16: Wiring Diagram

    7. Wiring diagram. The figure 11 below describes the wiring diagram of MD500-PLUS. Figure 11. Wiring diagram of MD500-PLUS. Table 12 below describes the main circuit (power) terminals of MD500-PLUS drive.
  • Page 17 Connected to a three-phase U, V, W Output terminals motor. Used for protective Grounding terminals (PE) grounding. Figure 12 below shows the control circuit terminals layout. Figure 12. Control circuit terminals layout. Table 13 below describes the control circuit terminals of MD500-PLUS.
  • Page 18 Table 13. Control circuit terminals of MD500-PLUS. Type Terminal(s) Function Description Provides +10V reference voltage to a potentiometer or another external device. Maximum output +10V reference +10V-GND current: 10 mA. voltage Normally used to supply a potentiometer with an impedance Power supply between 1 kΩ...
  • Page 19 Table 13. Control circuit terminals of MD500-PLUS (continued). Type Terminal(s) Function Description NPN transistor digtal output. Digital DO1-COM Digital output 1 Maximum output voltage: 24 V outputs Maximum output current: 50 mA Normally closed T/A1-T/B1 contact relay 1 Contact driving capacity:...
  • Page 20 8. Step by Step start-up procedure. Please follow below procedure in order to set up the MD500-PLUS drive. Before applying power to the drive ensure that the AC drive model is suitable for the power supply voltage available on the installation.
  • Page 21 Table 14. Relevant clauses for each motor type and control mode. Relevant clauses & Motor type Control mode sequence V/f control 4.2 -> 5 Sensorless vector control 4.3 -> 4.4 -> 4.8 -> 5 Induction (SVC) motor Feedback vector control 4.3 ->...
  • Page 22 If the motor cannot be decoupled from the load, perform static auto-tuning (F1-37=1 or 3). F1-37=3 is able to perform a complete identification of the motor parameters without moving the motor. If the motor can be decoupled from the load, perform dynamic auto-tuning (F1-37=2). 8.6 When using sensorless vector control (SVC) for PM synchronous motor.

  • Page 23: Parameter Group

    9. Concise list of parameters. Table 15 below lists the parameter groups with a short description. For more detailed information refer to the “MD500-PLUS Software Guide” listed in the clause “List of documentation for MD500- PLUS drive” of this document.

  • Page 24: Troubleshooting

    10. Troubleshooting. The AC drive MD500-PLUS is equipped with a set of protection functions in order to protect the motor, the electrical installation, the machine and/or the drive itself. When the AC drive detects a failure, enters in alarm state, removes RUN status, and indicates the alarm code in the LED display of the keypad.
  • Page 25 Table 16. Error codes in MD500-PLUS drive. Error code(s) Basic description E02.00 Overcurrent during acceleration E03.00 Overcurrent during deceleration E04.00 Overcurrent during operation at constant speed E05.00 Overvoltage during acceleration E06.00 Overvoltage during deceleration E07.00 Overvoltage during operation at constant speed E09.00...
