DUK SE57 Madoka BRC1H519 Remote Controller
Installation & Commissioning
Insert title here
Presented by: XXXXXX

Advertisement

loading
Need help?

Need help?

Do you have a question about the DUK SE57 Madoka BRC1H519 and is the answer not in the manual?

Questions and answers

Related Manuals for Daikin DUK SE57 Madoka BRC1H519

Summary of Contents for Daikin DUK SE57 Madoka BRC1H519

  • Page 1 DUK SE57 Madoka BRC1H519 Remote Controller Installation & Commissioning Insert title here Presented by: XXXXXX...
  • Page 2 your comfort. our world. Introduction Welcome Safety Instructions Training...
  • Page 3 your comfort. our world. Trainee Responsibility We assume that all trainees are qualified to work with electricity Should this not be the case, then you have to inform the instructor. We will only allow you to watch the exercises...
  • Page 4 Daikin Website & Business Portal...
  • Page 5 How To Register For The Business Portal www.daikin.eu https://my.daikin.eu/content/denv/en_US/login.html Fill in your company details using a company email address, then click “Submit”...
  • Page 6 Unit sizes Sound data Optional accessories Installation Service Manuals Manuals Description of system functions Field setting information Pipe work sizing (If available) Pipe work installation Fault code descriptions Pressure testing Additional refrigerant calculations www.daikin.eu Manuals can be downloaded from https://my.daikin.eu/content/denv/en_US/login.html...
  • Page 7 Business Portal & Additional Assistance Once you receive your Business Portal LOGIN and PASSWORD You will be able to log into the Business Portal and access installation manuals, technical data books and Daikin selection software, Additional Assistance: Daikin Air Conditioning Helpdesk: 0845 641 9200...
  • Page 8 your comfort. our world. Introduction To Madoka...
  • Page 9 Bluetooth enable, simplified, compact, hard wired remote controller. It maintains all the advanced control features standard Daikin BRC1E53 remote controller, whilst employing a simple to use, stylish end user interface. This is achieved by keeping the basic control functions...
  • Page 10 your comfort. our world. What is Madoka? The Modaka is available in 3 colours, White, Silver & Black. All 3 models are functionally identical and are provided with a separate surface mount backbox, Installation & Operation manual, raw plugs & mounting screws.
  • Page 11 your comfort. our world. Compatibility The Madoka is compatible with all units fitted with P1/P2 controller connections:- VRV fan coil units since K series R22. HRV (VAM) units F series. SkyAir fan coil units. Split fan coil units (those fitted with P1/P2 connections).

  • Page 12: Installation

    your comfort. our world. Installation Although the Madoka is compact (85x85mm), care must be taken whilst positioning the control to allow for cable routing. There are four possible options:- Rear, Top, Bottom & Left.
  • Page 13 your comfort. our world. Installation...
  • Page 14 your comfort. our world. Installation For Top, Bottom & Left cable routing, it will be necessary to remove a piece of the rear mounting box. Ensure that the correct specification of cable is employed, that the outer sheath of the cable is removed and that only the 2 inner cables pass through the mounting box.
  • Page 15 your comfort. our world. Installation The 2 separate cores can then be wired into the screw terminals located on the back of the controller – N.B. the P1/P2 wiring is NOT polarity sensitive. The controller can then be closed by mounting the top of the controller on the 2 tabs located on the mounting plate.
  • Page 16 your comfort. our world. Using the Madoka Remote Controller On initial power up the remote controller will flash with the number 1 in a circle for approximately 10 seconds. This indicates that the remote controller is starting in ’master’ mode. This is the factory default and is normal where only one P1/P2 device is connected into the indoor unit.
  • Page 17 your comfort. our world. Using the Madoka Remote Controller Once the controller has initialised, then you will be presented with the home screen, showing the current status of the unit. This display can be changed to the detailed display, which will be illustrated later. N.B.
  • Page 18 From a sub menu increases a value. Status indicator light (Daikin eye). – Blue illuminated light when the unit is running, off when the unit is stopped and blinking when the unit is in fault (this light operation can be...
  • Page 19 your comfort. our world. Using the Madoka Remote Controller So, we can adjust the unit set point from the home screen by using the ‘+’ & ‘-’ buttons. However to make another other adjustments to the operation of the unit we have to enter the main menu.
  • Page 20 your comfort. our world. Using the Madoka Remote Controller Operation mode. Entering the operation mode will display the units current mode. Pressing the ‘+’ or ‘– will allow you to cycle through the available options. Pressing ‘O’ will confirm the change and return you to the home screen.
  • Page 21 your comfort. our world. Using the Madoka Remote Controller Louver position (Selection missing if unit does not have louvers). Entering the louver position will display the louvers current position (in white). Pressing the ‘+’ or ‘– will allow you to cycle through the available options.
  • Page 22 your comfort. our world. Using the Madoka Remote Controller Ventilation rate (Selection missing if unit is not a VAM). Entering the ventilation rate will display the VAM units current fan speed. Pressing the ‘+’ or ‘– will allow you to cycle through the available options.
  • Page 23 your comfort. our world. Using the Madoka Remote Controller Ventilation mode (Selection missing if unit is not a VAM). Entering the ventilation mode will display the VAM units current mode of operation. Pressing the ‘+’ or ‘– will allow you to cycle through the available options.
  • Page 24 your comfort. our world. Using the Madoka Remote Controller Bluetooth menu 96:AB:C0 Entering the menu displays whether Bluetooth is currently enabled or not, and shows if a device (App) is currently connected. Pressing the ‘+’ will allow you to toggle the Bluetooth on and off. Pressing ‘O’...
  • Page 25 your comfort. our world. Using the Madoka Remote Controller Time & date menu Entering the menu displays the current time and date. Pressing the ‘+’ (below the edit icon) will make the current settings editable. Pressing the ‘+’ or ‘-’ will change the value for the highlighted field. Pressing ‘O’...
  • Page 26 your comfort. our world. Using the Madoka Remote Controller Set point menu Entering the menu returns you to the home screen – as this is where the unit set point is adjusted.
  • Page 27 your comfort. our world. Using the Madoka Remote Controller Home screen icons. Unit on/off status Remote controller Fault/maintenance temperature information available Schedule enabled Further information Bluetooth enabled available Main menu Mode of operation function(s) restricted change restricted Unit current operating Temperature units mode VAM unit connected...
  • Page 28 your comfort. our world. Using the Madoka Remote Controller Information screen. Should the further information icon or the fault/maintenance icons appear, then it is possible to obtain more information or reset the condition from the information screen. To access the information screen, with the screen illuminated, press and hold the ‘O’ button for 5 seconds.
  • Page 29 your comfort. our world. Using the Madoka Remote Controller Information screen. Demand control Setback enabled active Software version Master controller (2 = slave) Further information Bluetooth enabled screen indication Mode of operation change restricted Schedule enabled Backup unit Hot start / Defrost operational Individual louver Main menu...
  • Page 30 your comfort. our world. Using the Madoka Remote Controller Information screen - Advanced. Upon pressing and holding the ‘O’ for a second 5 seconds you enter the advanced information screen where filter signs and faults can be reset. Fault To reset a filter alarm, press the ‘+’ below the X icon. To reset a fault press and hold the ‘+’...
  • Page 31 your comfort. our world. Using the Madoka Remote Controller Information screen - Advanced. There is a special procedure that occurs when 2 master control devices (remote controllers, RTDs, etc) are connected on the same P1/P2 cable. A fault code of U5 or U8 will appear. It then be necessary to set one controller as a slave.
  • Page 32 your comfort. our world. Using the Madoka Remote Controller Installer menu. To access the Installer menu, it is necessary to first enter the information screen. So, with the screen illuminated, press and hold the ‘O’ button for 5 seconds. This will enter you into the information screen. Then press and hold the ‘O’...
  • Page 33 your comfort. our world. Using the Madoka Remote Controller Screen brightness. Entering the screen brightness menu will display the current brightness level of the main screen. Pressing the ‘+’ or ‘– will allow you to adjust the brightness. Pressing ‘O’ will confirm the change and return you to the installer menu screen.
  • Page 34 your comfort. our world. Using the Madoka Remote Controller Screen contrast. Entering the screen contrast menu will display the current contrast level of the main screen. Pressing the ‘+’ or ‘– will allow you to adjust the contrast. Pressing ‘O’ will confirm the change and return you to the installer menu screen.
  • Page 35 your comfort. our world. Using the Madoka Remote Controller Status indicator brightness. Entering the status indicator brightness menu will illuminate the status indicator. Pressing the ‘+’ or ‘– will allow you to adjust the brightness. Pressing ‘O’ will confirm the change and return you to the installer menu screen.
  • Page 36 your comfort. our world. Using the Madoka Remote Controller Indoor unit field settings. Entering the indoor unit field setting menu will allow you to view and adjust the field settings in the connected indoor unit(s). N.B. Remember that indoor unit field settings reside in the indoor unit PCB. Therefore any changes made will remain with the indoor unit, even if the Madoka controller is subsequently removed or moved to another indoor unit(s).
  • Page 37 your comfort. our world. Using the Madoka Remote Controller Indoor unit field settings. When you first enter the menu you will be presented with the option to choose the mode (main code) and unit to view/adjust. Press ‘-’ Press ‘O’ Press ‘O’...
  • Page 38 your comfort. our world. Using the Madoka Remote Controller Indoor unit field settings. The setting code is indicated by ‘SW’ and the value is below it. Press ‘-’ Press Press ‘O’ Press ‘O’ or ‘+’ ‘+’ or ‘-’ Press ‘-’ Press ‘O’...
  • Page 39 your comfort. our world. Using the Madoka Remote Controller Remote controller settings. Entering the remote controller setting menu will allow you to view and adjust the field settings associated with the remote controller. N.B. Remember that remote controller settings reside in the remote controller PCB.
  • Page 40 your comfort. our world. Using the Madoka Remote Controller Remote controller settings. When you first enter the menu you will be presented with the option to choose the mode (main code). The unit icon is displayed but cannot be selected. Press ‘-’...
  • Page 41 your comfort. our world. Using the Madoka Remote Controller Remote controller settings. The setting code is indicated by ‘SW’ and the value is below it. Press ‘-’ Press Press ‘O’ Press ‘O’ or ‘+’ ‘+’ or ‘-’ Press ‘-’ Press ‘O’ Press ‘O’...
  • Page 42 your comfort. our world. Using the Madoka Remote Controller Remote controller settings. The available remote controller settings are:...
  • Page 43 your comfort. our world. Using the Madoka Remote Controller Remote controller settings. The available remote controller settings are: 0: Hidden (& Bluetooth disabled) Bluetooth menu available 1: Available...
  • Page 44 your comfort. our world. Using the Madoka Remote Controller Remote controller settings. The below table gives further details on the status light behaviour, as defined in setting R1, SW11.
  • Page 45 your comfort. our world. Using the Madoka Remote Controller Addressing. This menu is absent if the connected unit is not VRV or connected to a centralised device. In this menu you can set the DIII-Net group address by group or by unit, and set the indoor and outdoor Airnet address.
  • Page 46 your comfort. our world. Using the Madoka Remote Controller Addressing. DIII-Net addressing by group. Press ‘+’ Press ‘O’ Press ‘+’ Press ‘O’ Press ‘O’ Press ‘O’ then ‘+’ then ‘+’ then ‘+’ Until required Tick confirms you wish to address is displayed set address Press ‘-’...
  • Page 47 your comfort. our world. Using the Madoka Remote Controller Addressing. DIII-Net addressing by unit. Press ‘O’, Press ‘O’ Press ‘O’ then ‘+’, then ‘+’ then ‘+’ then ‘O’ to select different fan coil Follow from Follow from Press ‘-’ 1 through to 3 (above) to 2 (previous set address...
  • Page 48 your comfort. our world. Using the Madoka Remote Controller Addressing. Indoor Airnet addressing. Press ‘O’, Press ‘O’ Press ‘O’ then ‘+’, then ‘+’x2 then ‘+’ then ‘O’ to select different fan Press ‘+’ then ‘O’ coil Press ‘O’ Press ‘O’ Press ‘O’...
  • Page 49 your comfort. our world. Using the Madoka Remote Controller Addressing. Outdoor Airnet addressing. Press ‘O’, Press ‘O’ Press ‘O’ then ‘+’, then ‘+’x3 then ‘+’ then ‘O’ to select different Press ‘+’ then ‘O’ outdoor unit Press ‘O’ Press ‘O’ Press ‘O’...
  • Page 50 your comfort. our world. Using the Madoka Remote Controller External input. This menu is absent if a BRP7A51 external input card is not connected to the indoor unit. When you enter this menu, the Parameters field is already selected. Use the ‘+’ or ‘-’ to scroll through the required parameters and ‘O’...
  • Page 51 your comfort. our world. Using the Madoka Remote Controller External input. This menu is absent if a BRP7A51 external input card is not connected to the indoor unit.
  • Page 52 your comfort. our world. Using the Madoka Remote Controller External input. This menu is absent if a BRP7A51 external input card is not connected to the indoor unit.
  • Page 53 your comfort. our world. Using the Madoka Remote Controller Force fan on. This is used to individually identify fan coil units when multiple units are connected to a single remote controller. N.B. Ensure the units are stopped before employing this menu. Unit 1 will now run Unit 0 will now run in high fan speed...
  • Page 54 your comfort. our world. Using the Madoka Remote Controller Switch heat/cool master. This menu will have a cross through it, and be inaccessible, unless you are on the heat/cool master of a heat pump VRV system or heat/cool master of a BS box with more than one fan coil unit on a heat recovery VRV system.
  • Page 55 your comfort. our world. Using the Madoka Remote Controller Information. When you enter this menu you will be presented with page 1 of 2. Press ‘+’ to move to second page. Press ‘O’ to return to installer menu. Press ‘+’...
  • Page 56 your comfort. our world. Using the Madoka Remote Controller Return. Pressing ‘O’ when on the above icon will leave the installer menu and return you back to the home screen. Press ‘O’...
  • Page 57 your comfort. our world. Using the Madoka Assistant. The Madoka Assistant (App) is available for both Android & iOS devices. Operating Version Typical models system iPhone 5 and later iPad 2 and later 9.3.5 or higher. All iPad minis iPod Touch 5th generation and later 5.0 or higher.
  • Page 58 Using the Madoka Assistant. Browse your relevant App store (iTunes or Play Store) and search using the key words - “Daikin Madoka” or “Madoka Assistant”. Install the App and then, when within range* of a Madoka controller, open the App.
  • Page 59 your comfort. our world. Using the Madoka Assistant. The first time the App is opened it will require you to agree to the ‘Terms of Use’.
  • Page 60 your comfort. our world. Using the Madoka Assistant. The App will then ask for permission to access your ‘Location’ so that it has access to the phones’ Bluetooth connection. After which a list of controllers in range will be displayed.
  • Page 61 your comfort. our world. Using the Madoka Assistant. The first time the App is run, it will be necessary to ‘login’ as an “Installer” so that all features are available from the App. Press the 3 horizontal lines in the top right of the screen.
  • Page 62 your comfort. our world. Using the Madoka Assistant. Quick tap 5 times on “Application version”. The Installer mode is now activated. – It can be set to auto time out after minutes required, yellow status bar can be hidden if required. Press the arrow in the top right to return to the previous screen.
  • Page 63 your comfort. our world. Using the Madoka Assistant. When you first select a controller, you will be asked to ‘pair’ to it. The passkey will appear on the controller. The passkey will also appear on the App.
  • Page 64 your comfort. our world. Using the Madoka Assistant. It is essential that you confirm the passkey on the controller before you confirm the passkey on the App, else the pairing will time out after about 3 seconds. If the code is not confirmed, or Confirm the controller passkey by times out, the above message will pressing the ‘-’...
  • Page 65 your comfort. our world. Using the Madoka Assistant. Once paired, you have the option to rename this controller. This name will remain with the controller and be seen when anyone tries to connect to it with the App. Click pen icon to Click the tick icon edit controller to save the...
  • Page 66 your comfort. our world. Using the Madoka Assistant. Once paired, clicking on the controller will open the controller interface screen.
  • Page 67 your comfort. our world. Using the Madoka Assistant. From this screen, basic control functions and statuses are available. Warnings & faults Remote controller sensor temperature Advanced settings* Filter inspection required Stop unit Start unit Outdoor air temperature Mode change: (SkyAir only) Auto, Cool, Heat, Set point Fan only, Dry...
  • Page 68 your comfort. our world. Using the Madoka Assistant. When you start the fan coil unit, the display changes colour to show the current operating mode and set point (if applicable). Heating / Cooling / Fan only Stopped Auto heat Auto cool...
  • Page 69 your comfort. our world. Using the Madoka Assistant. When selecting fan speed, one of louver icons or VAM unit mode, the bottom of the display pops up. Once finished, click on any part of the original screen to close the pop up. Manual Manual Manual...
  • Page 70 your comfort. our world. Using the Madoka Assistant. When selecting fan speed, one of louver icons or VAM unit mode, the bottom of the display pops up. Once finished, click on any part of the original screen to close the pop up. FVA unit only VAM unit only Manual...
  • Page 71 your comfort. our world. Using the Madoka Assistant. To access the Advanced settings menu press the cog icon. The screen will change to show a list of available settings.
  • Page 72 your comfort. our world. Using the Madoka Assistant. Firmware update. This is used to update the Bluetooth interface (Communications module) and Remote controller – should there be a required update. Current Bluetooth version Back to Available Bluetooth version list Press to update Bluetooth version Current remote controller version Available remote controller version Press to update remote controller version...
  • Page 73 your comfort. our world. Using the Madoka Assistant. Notification. This screen shows any actions that are needed – typically filter inspection or dust collect box to be emptied (self cleaning unit). Notification Back to list...
  • Page 74 your comfort. our world. Using the Madoka Assistant. Remove bonding information. This is used to unpair your device from the controller. Back to Un-pairing your device from the list controller will mean you will need to re-pair your device to the controller next time you wish to access it.
  • Page 75 your comfort. our world. Using the Madoka Assistant. Setpoint auto reset. Back to list Enable/disable Setpoint auto reset function. Default setpoint to return to after timed period away Period that the setpoint from this. is allowed to be away from default before being reset (30/60/90/120 minutes).
  • Page 76 your comfort. our world. Using the Madoka Assistant. Schedule. 3 schedules can be set. Press the arrow to edit the required schedule Back to list Current settings Add new instruction...
  • Page 77 your comfort. our world. Using the Madoka Assistant. Schedule - Time. Press to change time of action Exit without saving Select the required hour and then display will change to minutes. Then select the required minutes and press ‘OK’.
  • Page 78 your comfort. our world. Using the Madoka Assistant. Schedule – Off command. Select required action (on/off) Exit without saving For an ‘Off’ action you can also activate cooling and/or heating setback along with an associated temperature Once action selected, then press ‘Done’...
  • Page 79 your comfort. our world. Using the Madoka Assistant. Schedule – On command. Select required action (on/off) Exit without saving For an ‘On’ action you can also activate a setpoint...
  • Page 80 your comfort. our world. Using the Madoka Assistant. Schedule – Days. Once On/Off settings have been set, then press ‘Next’ Exit without saving Click on the required day(s) then press ‘Save’...
  • Page 81 your comfort. our world. Using the Madoka Assistant. Schedule. Return to main schedule screen Added setting will appear here Press arrow to edit instruction Ability to copy schedule to another Add more actions schedule, or to delete if required all instructions...
  • Page 82 your comfort. our world. Using the Madoka Assistant. Schedule. Back to list Ensure schedule is enabled Ability to save or load all schedules to a file...
  • Page 83 your comfort. our world. Using the Madoka Assistant. Setpoint mode. Back to list Switch between indoor unit & remote controller automatic heat/cool changeover modes. – see N.B. following slides. When connected to a centralised controller, then only indoor unit setpoint mode is possible.
  • Page 84 your comfort. our world. Using the Madoka Assistant. Setpoint mode. Indoor unit automatic heat/cool changeover - 0°c Diff (field setting 22, 4-01). Changeover thermistor based on 20, 2-0x setting. Solid line = Thermostat on – active heating or cooling. Dashed line = Thermostat off – natural temperature gains or loses. Heating Cooling Set point Auto...
  • Page 85 your comfort. our world. Using the Madoka Assistant. Setpoint mode. Indoor unit automatic heat/cool changeover - 2°c Diff (field setting 22, 4-03). Changeover thermistor based on 20, 2-0x setting. Solid line = Thermostat on – active heating or cooling. Dashed line = Thermostat off – natural temperature gains or loses. Heating Cooling Set point Auto cool...
  • Page 86 your comfort. our world. Using the Madoka Assistant. Setpoint mode. Remote controller automatic heat/cool changeover. Solid line = Thermostat on – active heating or cooling. Dashed line = Thermostat off – natural temperature gains or Minimum 1 hour loses. between mode changes Heating Cooling...
  • Page 87 your comfort. our world. Using the Madoka Assistant. Ability to save or load configuration to a file Setback. Back to list Enable/disable setback. Temperature to which the space must rise when the unit is stopped, before the unit will automatically start in cooling and bring the room down by the cooling recovery differential Temperature to which the space...
  • Page 88 your comfort. our world. Using the Madoka Assistant. Individual airflow direction. This will only be available if you have a fan coil unit capable of individual louver position control. Back to list...
  • Page 89 your comfort. our world. Using the Madoka Assistant. Individual airflow direction. Press save after This will only be available if you have a fan coil unit capable adjusting all of individual louver position control. required positions Back to list Select unit to adjust louvers on.
  • Page 90 your comfort. our world. Using the Madoka Assistant. Setpoint range. Minimum cooling setpoint Enable Maximum setpoint heating limitation setpoint Back to list Indoor unit Setpoint mode N.B. Common Setpoint limitations only apply to setpoint heating and cooling modes – not range Remote controller to automatic mode.
  • Page 91 your comfort. our world. Using the Madoka Assistant. Function lock. Disables buttons and functions on both the remote controller and App. Back to list Pressing the padlock (such that it turns blue) will lock / disable the associated function...
  • Page 92 your comfort. our world. Using the Madoka Assistant. Errors and warnings. Back to list Last 10 faults detected by When Display remote controller. errors or warnings (Time & date is turned off, then stamped) it will automatically be re-enabled after 48 hours.
  • Page 93 your comfort. our world. Using the Madoka Assistant. Group address. – Installer mode only. This menu is only available if the indoor unit is connected to a centralised controller. Back to list Press to set Group address group address (set to released if individual group Press to set...
  • Page 94 your comfort. our world. Using the Madoka Assistant. Filter notifications. Back to list Reset run timer back to zero – filter indication & replace filter Reset indication symbol – filter indication & replace filter...
  • Page 95 your comfort. our world. Using the Madoka Assistant. Field settings. – Installer mode only. This menu is indoor unit field settings only – not remote controller settings. Switch between field settings & remote Back to list controller settings Mode number Unit number (Not available if Switch (SW)
  • Page 96 your comfort. our world. Using the Madoka Assistant. Field settings. – Installer mode only. This menu is indoor unit field settings only – not remote controller settings. Discard changes Controller restarts...
  • Page 97 your comfort. our world. Using the Madoka Assistant. Field settings. – Installer mode only. This menu is indoor unit field settings only – not remote controller settings. Previous screen Settings changed. Return to Field From – To. Settings main screen...
  • Page 98 your comfort. our world. Using the Madoka Assistant. Field settings. – Installer mode only. To apply previously saved settings to a new unit/controller. Select applicable previously saved settings Units to be copied to will be shown Apply settings...
  • Page 99 your comfort. our world. Using the Madoka Assistant. Field settings. – Installer mode only. This menu is indoor unit field settings only – not remote controller settings. Previous screen Controller restarts Settings changed. From – To. Return to Field Settings main screen...
  • Page 100 your comfort. our world. Using the Madoka Assistant. Unit status. This menu is used to see the fan coil unit status & thermistor values. Outdoor status & thermistor values are available for SkyAir systems only. Back to list Select thermistor Code Thermistor Temperature...
  • Page 101 your comfort. our world. Using the Madoka Assistant. Unit status. This menu is used to see the fan coil unit status & thermistor values. Outdoor status & thermistor values are available for SkyAir systems only.
  • Page 102 your comfort. our world. Questions...
  • Page 103 your comfort. our world. Thank you for your attention...
  • Page 104 your comfort. your comfort. our world. our world. Appendix All Madoka Assistant functions...
  • Page 105 your comfort. our world. Using the Madoka Assistant. Firmware update. This is used to update the Bluetooth interface (Communications module) and Remote controller – should there be a required update. Current Bluetooth version Back to Available Bluetooth version list Press to update Bluetooth version Current remote controller version Available remote controller version Press to update remote controller version...
  • Page 106 your comfort. our world. Using the Madoka Assistant. Notification. This screen shows any actions that are needed – typically filter inspection or dust collect box to be emptied (self cleaning unit). Notification Back to list...
  • Page 107 your comfort. our world. Using the Madoka Assistant. Master/slave status. This is a read only status shown on the advanced list. Read only value Back to list...
  • Page 108 your comfort. our world. Using the Madoka Assistant. Screen. Permits switching of controller home screen between standard and detailed. Also adjustment of brightness Back to and contrast. list Switch between standard & detailed controller home screen Controller screen brightness (slider) Controller screen contrast (slider)
  • Page 109 your comfort. our world. Using the Madoka Assistant. Date and time. Adjustment of controller time and date. Back to list Press to set controller time & date equal to current mobile device time & date Manual adjustment of time & date Enable/disable daylight saving...
  • Page 110 your comfort. our world. Using the Madoka Assistant. About. Current Bluetooth & controller software version (read only). Back to list Remote controller software version Bluetooth software version...
  • Page 111 your comfort. our world. Using the Madoka Assistant. Remove bonding information. This is used to unpair your device from the controller. Back to Un-pairing your device from the list controller will mean you will need to re-pair your device to the controller next time you wish to access it.
  • Page 112 Using the Madoka Assistant. Presence detector. This will only be available if you have a Daikin presence sensor accessory fitted to your fan coil unit. The Daikin presence sensor has 3 functions: Temperature de-stratification – adjusts louver position to de-stratify the room temperature.
  • Page 113 your comfort. our world. Using the Madoka Assistant. Auto off settings Presence detector. Back to list Enable/disable setpoint adjustment Setpoint adjustment Increase the settings cooling set point by X after Y Decrease the heating set minutes of point by A after B minutes of no movement, movement, and ever B...
  • Page 114 your comfort. our world. Using the Madoka Assistant. Presence detector. Auto off settings Back to list Enable/disable Auto off function Setpoint adjustment Switch unit off after this settings period of no movement.
  • Page 115 your comfort. our world. Using the Madoka Assistant. Off timer. Back to list Enable/disable Auto off function Switch unit off after this period following unit start.
  • Page 116 your comfort. our world. Using the Madoka Assistant. Energy consumption (R32 SkyAir only). Back to list Select report period Summary of this period Breakdown of period by vs last period. sub-periods. Day  2 hour period. Week  Day. Year  Month. (Scroll down for rest of the breakdown).
  • Page 117 your comfort. our world. Using the Madoka Assistant. Power consumption limit (R32 SkyAir only). Back to list Select maximum operating level – 70% or 40%. Ability to save or load configuration to a file Period during which Enable/disable timed system operation is power limiting function.
  • Page 118 your comfort. our world. Using the Madoka Assistant. Setpoint auto reset. Back to list Enable/disable Setpoint auto reset function. Default setpoint to return to after timed period away Period that the setpoint from this. is allowed to be away from default before being reset (30/60/90/120 minutes).
  • Page 119 your comfort. our world. Using the Madoka Assistant. Schedule. 3 schedules can be set. Press the arrow to edit the required schedule Back to list Current settings Add new instruction...
  • Page 120 your comfort. our world. Using the Madoka Assistant. Schedule - Time. Press to change time of action Exit without saving Select the required hour and then display will change to minutes. Then select the required minutes and press ‘OK’.
  • Page 121 your comfort. our world. Using the Madoka Assistant. Schedule – Off command. Select required action (on/off) Exit without saving For an ‘Off’ action you can also activate cooling and/or heating setback along with an associated temperature Once action selected, then press ‘Done’...
  • Page 122 your comfort. our world. Using the Madoka Assistant. Schedule – On command. Select required action (on/off) Exit without saving For an ‘On’ action you can also activate a setpoint...
  • Page 123 your comfort. our world. Using the Madoka Assistant. Schedule – Days. Once On/Off settings have been set, then press ‘Next’ Exit without saving Click on the required day(s) then press ‘Save’...
  • Page 124 your comfort. our world. Using the Madoka Assistant. Schedule. Return to main schedule screen Adding setting will appear here Press arrow to edit instruction Ability to copy schedule to another Add more actions schedule, or to delete if required all instructions...
  • Page 125 your comfort. our world. Using the Madoka Assistant. Schedule. Back to list Ensure schedule is enabled Ability to save or load all schedules to a file...
  • Page 126 your comfort. our world. Using the Madoka Assistant. Holiday. Back to list Select or Deselect all days in one go. Click on appropriate day to select or deselect it from the holiday period (scroll down for more days)
  • Page 127 your comfort. our world. Using the Madoka Assistant. Setpoint mode. Back to list Switch between indoor unit & remote controller automatic heat/cool changeover modes. – see N.B. following slides. When connected to a centralised controller, then only indoor unit setpoint mode is possible.
  • Page 128 your comfort. our world. Using the Madoka Assistant. Setpoint mode. Indoor unit automatic heat/cool changeover - 0°c Diff (field setting 22, 4-01). Changeover thermistor based on 20, 2-0x setting. Solid line = Thermostat on – active heating or cooling. Dashed line = Thermostat off – natural temperature gains or loses. Heating Cooling Set point Auto...
  • Page 129 your comfort. our world. Using the Madoka Assistant. Setpoint mode. Indoor unit automatic heat/cool changeover - 2°c Diff (field setting 22, 4-03). Changeover thermistor based on 20, 2-0x setting. Solid line = Thermostat on – active heating or cooling. Dashed line = Thermostat off – natural temperature gains or loses. Heating Cooling Set point Auto cool...
  • Page 130 your comfort. our world. Using the Madoka Assistant. Setpoint mode. Remote controller automatic heat/cool changeover. Solid line = Thermostat on – active heating or cooling. Dashed line = Thermostat off – natural temperature gains or Minimum 1 hour loses. between mode changes Heating Cooling...
  • Page 131 your comfort. our world. Using the Madoka Assistant. Ability to save or load configuration to a file Setback. Back to list Enable/disable setback. Temperature to which the space must rise when the unit is stopped, before the unit will automatically start in cooling and bring the room down by the cooling recovery differential Temperature to which the space...
  • Page 132 your comfort. our world. Using the Madoka Assistant. Individual airflow direction. This will only be available if you have a fan coil unit capable of individual louver position control. Back to list...
  • Page 133 your comfort. our world. Using the Madoka Assistant. Individual airflow direction. Press save after This will only be available if you have a fan coil unit capable adjusting all of individual louver position control. required positions Back to list Select unit to adjust louvers on.
  • Page 134 your comfort. our world. Using the Madoka Assistant. Activate airflow circulation (B series Roundflow cassette only). Back to list Enable active airflow function...
  • Page 135 your comfort. our world. Using the Madoka Assistant. Setpoint range. Minimum cooling setpoint Enable Maximum setpoint heating limitation setpoint Back to list Indoor unit Setpoint mode N.B. Common Setpoint limitations only apply to setpoint heating and cooling modes – not range Remote controller to automatic mode.
  • Page 136 your comfort. our world. Using the Madoka Assistant. Cooling/Heating masterhood. Back to list Unlock or set unit as heat/cool master.
  • Page 137 your comfort. our world. Using the Madoka Assistant. Airflow direction range. FVA unit only. Back to list Horizontal louver position...
  • Page 138 your comfort. our world. Using the Madoka Assistant. Draft prevention. Louver units only. Enable draft prevention Back to list (Disables lower 2 louver positions to prevent the possibility of cold draughts)
  • Page 139 your comfort. our world. Using the Madoka Assistant. Quick start (SkyAir only). Back to list Enable Quick start operation. Used to bring room to temperature as quickly as possible.
  • Page 140 your comfort. our world. Using the Madoka Assistant. Defrost operation (SkyAir only). Back to list Press to start a forced defrost run.
  • Page 141 your comfort. our world. Using the Madoka Assistant. Function lock. Disables buttons and functions on both the remote controller and App. Back to list Pressing the padlock (such that it turns blue) will lock / disable the associated function...
  • Page 142 your comfort. our world. Using the Madoka Assistant. Quiet mode (R32 SkyAir only). Back to list Enable/disable timed quiet mode. Period during which system operation is restricted.
  • Page 143 your comfort. our world. Using the Madoka Assistant. External input interlock (only if BRP7A51 card fitted). Back to list Run on delay after key card removed. Actions to be sent after ‘Reset timer’ Period following key has elapsed. card removal before subsequent actions sent.
  • Page 144 your comfort. our world. Using the Madoka Assistant. Errors and warnings. Back to list Last 10 faults detected by When Display remote controller. errors or warnings (Time & date is turned off, then stamped) it will automatically be re-enabled after 48 hours.
  • Page 145 your comfort. our world. Using the Madoka Assistant. Unit number. This menu allows you to swap the pre-generated unit group addresses. You can also force individual units to run in fan only – to identify them. Back to list Press to swap addresses Select the first unit address...
  • Page 146 your comfort. our world. Using the Madoka Assistant. Unit number. This menu allows you to swap the pre-generated unit group addresses. You can also force individual units to run in fan only – to identify them. Indoor unit & Back to list Outdoor unit model numbers, and R32 indication are unit...
  • Page 147 your comfort. our world. Using the Madoka Assistant. Filter auto clean. This menu is only available if the connected indoor unit has a filter self cleaning module. Enable/disable self Back to list cleaning function Set self cleaning period window Start self cleaning Reset collection box test operation full indication...
  • Page 148 your comfort. our world. Using the Madoka Assistant. Airnet address. – Installer mode only. This menu is only available if the connected indoor unit or associated outdoor unit is part of a VRV system. Back to list Press to set Airnet address Indoor unit and Indoor unit...
  • Page 149 your comfort. our world. Using the Madoka Assistant. Group address. – Installer mode only. This menu is only available if the indoor unit is connected to a centralised controller. Back to list Press to set Group address group address (set to released if individual group Press to set...
  • Page 150 your comfort. our world. Using the Madoka Assistant. Contact information. Back to list Reset filter dirty timer or filter replacement timer (possible even prior to timer elapsing / symbol appearing). Reset filter dirty symbol or filter replacement symbol once timer has elapsed / symbol has appeared.
  • Page 151 your comfort. our world. Using the Madoka Assistant. Contact information. Press to input contact Back to list phone number (up to 16 digits) Press to dial contact phone number...
  • Page 152 your comfort. our world. Using the Madoka Assistant. Filter notifications. Back to list Reset run timer back to zero – filter indication & replace filter Reset indication symbol – filter indication & replace filter...
  • Page 153 your comfort. our world. Using the Madoka Assistant. Field settings. – Installer mode only. This menu is indoor unit field settings only – not remote controller settings. Switch between field settings & remote Back to list controller settings Mode number Unit number (Not available if Switch (SW)
  • Page 154 your comfort. our world. Using the Madoka Assistant. Field settings. – Installer mode only. This menu is indoor unit field settings only – not remote controller settings. Discard changes Controller restarts...
  • Page 155 your comfort. our world. Using the Madoka Assistant. Field settings. – Installer mode only. This menu is indoor unit field settings only – not remote controller settings. Previous screen Settings changed. Return to Field From – To. Settings main screen...
  • Page 156 your comfort. our world. Using the Madoka Assistant. Field settings. – Installer mode only. To apply previously saved settings to a new unit/controller. Select applicable previously saved settings Units to be copied to will be shown Apply settings...
  • Page 157 your comfort. our world. Using the Madoka Assistant. Field settings. – Installer mode only. This menu is indoor unit field settings only – not remote controller settings. Previous screen Controller restarts Settings changed. From – To. Return to Field Settings main screen...
  • Page 158 your comfort. our world. Using the Madoka Assistant. Duty rotation. This menu is only available if at least 2 compatible systems (RZA systems) are connected to the same controller. Back to list Enable/disable the duty rotation function Adjust the duty rotation period Select required period then press...
  • Page 159 your comfort. our world. Using the Madoka Assistant. Test operation. This menu is only for SkyAir systems and performs a test cooling run. Back to list Press to start test operation...
  • Page 160 your comfort. our world. Using the Madoka Assistant. Unit status. This menu is used to see the fan coil unit status & thermistor values. Outdoor status & thermistor values are available for SkyAir systems only. Back to list Select thermistor Code Thermistor Temperature...
  • Page 161 your comfort. our world. Using the Madoka Assistant. Unit status. This menu is used to see the fan coil unit status & thermistor values. Outdoor status & thermistor values are available for SkyAir systems only.
  • Page 162 your comfort. our world. Using the Madoka Assistant. Operating hours. – Installer mode only. This menu is used to see the unit run time, the fan run time, the compressor run time and how long power has been applied to the system. Outdoor data is only available for SkyAir systems.
