Alpha Antenna Alpha DX EMCOMM Operating Manual

______________________
Model – Alpha DX EMCOMM Antenna
Operating Manual, Version 1.3, April 11, 2020
Overview
The Alpha DX EMCOMM is designed to operate from 10 through 80 meters as a capacity hat
antenna. It is rated at 250W PEP SSB, 100W CW, and 50W Digital (25W Digital if 'always on').
Operation
The DX EMCOMM Antenna an ultra-portable multiband and multipurpose HF antenna that fits
in an included Field Bag. This system requires no moving clips on coils or readjusting of whips
for tuning. An integrated leveling bubble enables precise spatial alignment of all elements,
resulting in equal take-off angles. You may also use an external antenna tuner if your antenna
is installed over a poor ground or not placed in a clear area.
Excess RF Exposure Warning
In the United States, the Federal Communications Commission has established guidelines for
human exposure to Radio Frequency (RF) electromagnetic fields. The commission's
requirements are detailed in parts 1 & 2 of the FCC's rules and regulations {47 CFR, 1.1307(b),
1.1310, 22.1091, 2.1093}. It is the responsibility of the owner/operator of this device to follow
all applicable warnings and precautions regarding human exposure to RF fields. Additional
references: http://www.arrl.org/rf-exposure
Site Selection/Propagation
Place in a center of a clear area for the following propagation pattern.
support@alphaantenna.com – (888) 482-3249 – www.alphaantenna.com,
Page 1
