  • Page 1 User Guide for the Tuner Free & Directional Alpha Multiband Antenna Manufactured by: Alpha Antenna 1.888.482.3249 Website: http://AlphaAntenna.com User Guide Version 2.2 June 9, 2017 Page 1...
  • Page 2: Table Of Contents

    REPORTING EQUIPMENT IMPROVEMENT RECOMMENDATIONS (EIR) If your Alpha Multiband Antenna needs improvement, let us know. You, the user, are the only one who can tell us what you don’t like about your equipment. Mail or email us an EIR to the contact information on the last page of this manual.
  • Page 3: Safety Information

    Safety Information When installing or operating this antenna or any other antenna/tower, please observe the following safety tips. NOTE – High voltages are present when transmitting, no matter how much or little power is applied. Do not touch any part of the antenna while transmitting. WARNING: INSTALLATION OR OPERATION OF THIS PRODUCT NEAR POWER LINES IS DANGEROUS! FOR YOUR SAFETY, FOLLOW THE ENCLOSED INSTALLATION DIRECTIONS.
  • Page 4: Excess Rf Exposure Warning

    The FCC Office of Engineering Technology (OET) Bulletin 65, Supplement B, Evaluating Compliance with FCC Guidelines for Human Exposure to Radio frequency Electromagnetic Fields directly concerns the use and operations of all Alpha Antenna systems. This bulletin establishes safe operating distances from antennas associated power levels in order to permit the operator and persons who may be impacted by operation to exist in a safe environment.
  • Page 5: Section 1 - Concept Of Operation

    SECTION 1 – Concept of Operation The tuner free & directional Alpha Multiband Antenna is a multipurpose antenna system, which can be configured to launch your signal at your target. Many short-range HF communication circuits use vertical whip antennas that are not directional.
  • Page 6 above ground. Such radiation characteristics are omnidirectional in azimuth and provide an l-hop range of about 300 miles. The antenna gain varies mainly with the height of the antenna above ground. Because it is highly desirable to have minimum height and weight for tactical antennas, the immediate problem becomes one of determining the minimum effective antenna height required.
  • Page 7: Section 2 - System Overview

    SECTION 2 – System Overview This instruction manual contains technical data, installation procedures, theory of operation, and an illustrated parts list covering the Alpha Multiband Antenna and optional components. The antenna was designed to be used with HF radios. Table 1-1 SUMMARY OF AVAILABLE EQUIPMENT...
  • Page 8: Swr

    NVIS element enables long-range & DX propagation for distances greater than 300 miles. The Alpha Multiband Antenna may be used with tactical HF (high frequency) radios on the frequency range of 3.5 to 29.7 MHz (54.0 MHz when mounted on the tripod options) with a maximum RF power of 500 watts PEP SSB, 250 watts CW, or 100 watts digital.
  • Page 9 SWR Analysis on Tripod Page 9...
  • Page 10 SWR Analysis on Jaw Mount Page 10...
  • Page 11: Leading Particulars

    Leading Particulars Leading particulars and equipment for the Alpha Multiband Antenna are listed in Tables 1-2 through 1-4. Personnel should become thoroughly familiar with data and procedures contained in the entire technical manual before working on or using the antenna.
  • Page 12: Section 3 - General Information

    SECTION 3 – General Information Site Selection For maximum antenna operating efficiency, the Alpha Multiband Antenna should be located in the center of a clear area. Installation of the antenna near any tall metal object or under heavy foliage should be avoided. Under no circumstances should structures come in contact with the antenna.
  • Page 13: Section 4 - Specific Deployments

    SECTION 4 – Specific Deployments Options A through C represent the various Specific Deployment options. Option A – Tripod Deployment Option A.1 – Instructions Step 1 – On the tripod, loosen the leg braces, extend the legs, & secure the legs Step 2 –...
  • Page 14: Option B - Jaw Mount Deployment

    Option B – Jaw Mount Deployment Option B.1 – Instructions Step 1 – Install JWMNT-2.1 on a stable support Step 2 – Place and secure the Ring Connector of GND-2.1 onto the bottom stainless steel bolt of MTCH-2.1 Step 3 – Screw the MTCH-2.1 in place onto JWMNT-2.1 Step 4 –...
  • Page 15: Option C - Mobile Deployment

    Step 3 – Remove the extra stainless steel nut located at the bottom of the MTCH-2.1. Insert the 24x3/8 stud in the hole of the Alpha Antenna Jam Mount and replace the nut. Use two wrenches to ensure the bottom nut is tight & DO NOT twist the MTCH-2.1 while tightening;...
  • Page 16: Support

    Support If you have any questions or problems with your Alpha Antenna, please contact us. You can reach us via: Email – support@AlphaAntenna.com Phone – 1-888-482-3249 Web – www.AlphaAntenna.com Our mailing address is: Alpha Antenna 112 East Commercial Street Pleasant Hill, MO 64080...
