SERVICE MANUAL
2016
ODE-3 FRAME SIZE 1 IP66
Using a torx screwdriver T10,
remove the 3 x screws
highlighted opposite 1Nm
With the heatsink removed,
access can now be made to the
IGBT module
Page 6 of 6
