SERVICE MANUAL
2016
Drive cover removal procedure
ODE-3 FRAME SIZE 1 IP66
Place the drive on a flat surface
Using a Philips screwdriver
remove the terminal cover.
The drive will look as shown
opposite
For the Switched variant,
disconnect all connection to the
terminal connector of the drive
Page 3 of 6
