- Page 1 USE AND MAINTENANCE MANUAL O.ME.R. S.p.A. Via Galileo Galilei, 20 30035 MIRANO (VENEZIA) Italy Tel.+39 041.5700303 Fax +39 041.5700273 Numero verde 800 017745 E-Mail: info@omerlift.com www.omerlift.com Versions: Capacity 4500 Kg Noiselevels 70dB(A) Collaudo Italia...
-
Page 3: Table Of Contents
SAFETY DEVICE FEATURES ............3-2 STICKERS AND PLATES ............... 3-3 ACCESSORIES ................7-1 INSTALLATION REPORT ............8-1 MAINTENANCE REPORT ............9-1 INSTALLATION ............4-1 TRANSPORT AND HANDLING ............4-1 PLACE OF INSTALLATION ............4-3 CONNECTING THE LIFT..............4-4 MFOX04500910 FOX 45... -
Page 5: Symbols Used In The Manual
Non- IMPORTANT compliance with the indications can be dangerous for the operator and can damage the system. Indicates that the specific activity or PROHIBITION operating sequence must avoided MFOX04500910 FOX 45... -
Page 7: General Information
Table identification plate: 1.3 Assistance Please use the following contact details for assistance requests : TEL. +39 041/5700303 (O.ME.R. switchboard ) FAX. +39 041/5700273 (specify FAO LIFT ASSISTANCE ) TOLL-FREE NUMBER : 800 017745 (direct lift assistance line) MFOX04500910 FOX 45... -
Page 8: Description Of Personnel
EXPOSED PERSON: any person wholly or partly in a hazardous area. HAZARDOUS OR RISKY AREA: any area inside and/or close to a machine in whose presence an exposed person constitutes a risk for his/her health and safety. MFOX04500910 FOX 45... -
Page 9: Description Of The Machine
MODEL WITH AUXILIARY WHEEL RELEASE 2 Hz LIFT Filtered and PNEUMATIC POWER SUPPLY lubricated MAXIMUM PRESSURE OF HYDRAULIC POWER SUPPLY QUANTITY OF OIL UPSTROKE/DOWNSTROKE 50 / 50 TIME MIN/MAX OPERATING °C TEMPERATURE SOUND EMISSION LEVEL db(A) < 80 MFOX04500910 FOX 45... - Page 10 LT- auxiliary lift Extension lead External scissors Internal scissors Base Hydraulic cylinder (main lift) Hydraulic cylinder (auxiliary lift) Recess Oscillating plates Wheel stop Access ramps Torsion bar Bar cover Command control unit Protective pipe ducts Union platform Pit cover MFOX04500910 FOX 45...
-
Page 11: Overall Dimensions
2-3Pagina 2-3 di 57 2.3 Overall dimensions FOX 45 CT-LT ABOVE GROUND MFOX04500910 FOX 45... - Page 12 2-2Pagina 2-2 di 57 FOX 45 CT-LT FLUSH MOUNT MFOX04500910 FOX 45...
- Page 13 2-3Pagina 2-3 di 57 FOX 45 CT-LT ABOVE GROUND COLLAUDO ITALIA MFOX04500910 FOX 45...
-
Page 14: Loading Conditions
2-4Pagina 2-4 di 57 2.4 Loading conditions LIFT MAX 4500 KG AUXILIARY LIFT LT MAX 3500 KG MFOX04500910 FOX 45... -
Page 15: Safety
Use as described in this manual only. Always use the accessories Protect the control unit adequately if used outdoors. recommended by the manufacturer. O.ME.R. S.p.A. declines all responsibility for non-compliance with the indications given in this manual. MFOX04500910 FOX 45... -
Page 16: Precaution
O.ME.R. declines responsibility for any Do not tamper with the lift's upstroke and downstroke inconvenience deriving from non-compliance with speeds, which have been adjusted by OMER during the instructions for use. factory tests in compliance with applicable legislation. MFOX04500910... -
Page 17: Improper Use
NEVER remove the wheel stop (A) and the union platform (B). They prevent the vehicle from coming off the platform. NEVER lift vehicles using equipment other than that envisaged by the manufacturer NEVER lift vehicles that are only partially on the lift MFOX04500910 FOX 45... -
Page 18: Safety Device Features
Chock and union Front and rear in both lift They prevent the vehicle from coming off the platforms. DEVICES platform platforms. See paragraph: SIGNALS Stickers and plates Draw attention to residual risks and precautions for use. Stickers and plates MFOX04500910 FOX 45... -
Page 19: Stickers And Plates
3-3Pagina 3-3 di 57 3.5 Stickers and plates IDENTIFYING THE LIFT MFOX04500910 FOX 45... - Page 20 3-4Pagina 3-4 di 57 TABLE SAFETY MFOX04500910 FOX 45...
- Page 21 3-5Pagina 3-5 di 57 CONTROL UNIT MFOX04500910 FOX 45...
-
Page 23: Installation
(Bubble pack - cardboard). harness using dedicated straps MFOX04500910 FOX 45... - Page 24 4-2Pagina 4-2 di 57 PACKING LIST FOX 45 is usually sent in 3 packages: WEIGHT frame VERSION OF of table with control control unit LIFT unit accessories FOX 45 N ~ 2120 FOX 45 CT FOX 45 CA...
-
Page 25: Place Of Installation
TO 40 ° C. The lift must in any case be fastened to the floor using dedicated chemical anchor capsules. (*) press calculated under the base plates. To install the anchor capsules, the foundation must have the following characteristics: MFOX04500910 FOX 45... -
Page 26: Connecting The Lift
12x120 screw anchors in Ø 12 mm holes with a depth of 100 mm. (see paragraph: anchorage capsule installation). The control unit must be positioned so that the operator has a full view over the lift area. MFOX04500910 FOX 45... -
Page 27: Connecting The Lift's Commands
Connect the pipe 1 to the pipe fitting B. 4.4 Connecting the lift’s commands 4.4.1 Hydraulic connections Ref. Description Dimension LIFT POWER SUPPLY 3/8” PIPE LT POWER SUPPLY 1/4” PIPE Connect the pipe 3 to the hydraulic block A.. MFOX04500910 FOX 45... -
Page 28: Pneumatic Connection
Once the hoses have been positioned, cut away any excess. Insert the hoses (RILSAN) into the union next to the hydraulic block, each one in its own utility Ref. Description Colour LIFT AIR WHITE PLATE AIR LIGHT BLUE MFOX04500910 FOX 45... -
Page 29: Electric Connection
Only connect the machine to type approved sockets with an earth cable PICKUP CURRENT 129,5 of proven efficiency. FUSE (DELAYED) Periodically have qualified personnel check the correct tightening of the FUSE (FAST) electric cables of the various components. THERMOMAGNET MFOX04500910 FOX 45... -
Page 30: Levelling
LEVELLING ADJUSTERS to adjust the height of the base. press the down button (PD) to take the platforms back down to the ground. TABLE/CONTROL UNIT WIRING use the LEVELLING ADJUSTERS to adjust the level of the TERMINAL BOARD platforms. MFOX04500910 FOX 45... -
Page 31: Purging Air From The Hydraulic Circuit
900÷1.000 mm off the ground. press the down button (PD) to take the platforms back down to the ground. hold the PD button down for 10-15 more sacs. Repeat this operation three times.. PLATFORM AND BASE LEVELLING ADJUSTER MFOX04500910 FOX 45... -
Page 32: Anchorage Capsule Installation
TYPE OF ANCHOR CAPSULE HAS M12X120/25/45 MIN. BORE DEPTH MIN. ANCHOR CAPSULE DEPTH MIN. THICKNESS OF CONCRETE HOLE DIAMETER LIFT BASE SPACER N° NUMBER OF PINS To be agreed with START TWISTING MOMENT manufacturer DRILL BIT DIAMETER TIGHTENING TORQUE 4-10 MFOX04500910 FOX 45... -
Page 33: Checks Before Use
The static and dynamic load tests with overloads are performed at the Manufacturer's premises. The user may perform nominal load tests (with a 10% tolerance admitted for maximum valve calibration) with distribution of the loads as described in the Loading conditions paragraph of the installation, use and maintenance manual. 4-11 MFOX04500910 FOX 45... -
Page 35: Uso
(24 Volts). Use the PEFT key to exclude the photocells; in this case, by keeping the PEFT button turned it is also possible to perform the upstroke (PS) and downstroke operations (PD). MFOX04500910 FOX 45... - Page 36 5-2Pagina 5-2 di 57 MFOX04500910 FOX 45...
-
Page 37: Residual Risks
HAZARD CONDITION RISK PIPE BREAKING Maintenance technician MAINTENANCE Contact with squirts of pressurised oil ELECTRIC SHOCK Maintenance technician MAINTENANCE Contact with live components SHEARING Maintenance technician MAINTENANCE Shearing of hands and feet with lift is in movement. MFOX04500910 FOX 45... -
Page 39: Maintenance
All scheduled maintenance operations must be performed by adequately trained personnel able to work in full safety. The lift bodies, control devices and safety devices must be periodically checked by the user to ensure that the unit is always in good condition MFOX04500910 FOX 45... -
Page 40: Safety Standards For Maintenance
Lock the cut-off switch in the open position using a padlock make certain that the system is not repowered while the works are in progress NEVER operate directly on control breaker NEVER lubricate parts while they are moving MFOX04500910 FOX 45... - Page 41 Vent hydraulic pressure before loosening the connections Cut off power to the machine panel before performing any welding operations on the platform. Platform welding operations can seriously damage electric, electronic instrumentation and equipment if they are powered. MFOX04500910 FOX 45...
-
Page 42: Routine Maintenance
TUBE UNIONS INSPECTION TANK + HYDRAULIC CLEAN months UNIT FILTER AGIP LH 46 HYDRAULIC TANK OIL CHANGE months UNIT ESSO OSO H 46 Periodically check the electrical safety devices and report any faults to the Service Centre. MFOX04500910 FOX 45... - Page 43 6-5Pagina 6-5 di 57 LUBRICATION POINTS (repeat symmetrically on both sides of the table) MFOX04500910 FOX 45...
-
Page 44: Maximum Pressure Valve Calibration
7) If the pressure does not correspond to P, put the table in the nearest mechanical safety position and repeat points 5 and 6 8) If pressure is equal to P, reassembly the nut loosened in point 4 and reassembly cap nut. PRESSURE MFOX04500910 FOX 45... - Page 45 5) Adjust pressure with an allen screw: (part. D) Turn clockwise to increase calibration pressure Turn anticlockwise to reduce calibration pressure 6) If pressure is equal to P, reassembly the nut loosened in point 3 and reassembly cap nut. PRESSURE MFOX04500910 FOX 45...
-
Page 46: Photocell Alignment
RED LED is switched off. POSITIONING CHECK mark the position the work field is between the two marks the lift’s permitted operating field must be ±50mm. MFOX04500910 FOX 45... -
Page 47: Parachute Valve
2. Loosen the washer and lock nut (3) beneath the valve. 3. Move the plate of the valve (4) closer or further away as desired, checking the height with the dedicated thickness gauge (5). Reassemble and test. MFOX04500910 FOX 45... -
Page 48: Safety Manoeuvres
EV1, fully unscrew the knurled pin (see photograph) and allow the table to lower; to restore, return the manual command of valve EV2 to its position and tighten the knurled pins. Supporto-POMPA 6-10 MFOX04500910 FOX 45... -
Page 49: Abnormal Operation
MECHANICAL SAFETY d.1. EV1 24 V coil burnt out. DEVICES e.1. mechanical safety devices mechanically blocked. AIR VALVE f.1. EV2 air blocked (does not open the mechanical safety devices). f.2. EV2 requires power. 6-11 MFOX04500910 FOX 45... -
Page 51: Accessories
(ITALY & EUROPE) LIGHTING SYSTEM (4 NEAN STRIPS) FOR LIFTS OVERSEAS 4033041400 (OVERSEAS) SP2B (P.P.G. for motor vehicles with two rectangular 4023010300 movements) SP4B (P.P.G. for motor vehicles with 4 rectangular 4023021200 movements) BOARD WITH RAMPS BETWEEN THE PLATFORMS MFOX04500910 FOX 45... - Page 53 COMPILED BY THE TECHNICIAN AT THE TIME OF INSTALLATION. INSTALLATIONS- PRÜFBERICHT WIRD BEI DER INSTALLATION DURCH DEN TECHNIKER AUSGEFÜLLT. LE PROCES-VERBAL D’INSTALLATION ET DE CONTRÔLE EST REMPLI PAR LE TECHNICIEN AU MOMENT DE L’INSTALLATION. CERTIFICADO INSTALACIÓN CONTROL PRUEBA RELLENA TÉCNICO MOMENTO INSTALACIÓN. MFOX04500910 FOX 45...
-
Page 55: Maintenance Report
AUF DEM STEUERGERÄT DER HEBEBÜHNE BEFESTIGT ADHESIF: INDIQUE LA DATE D’ECHEANCE POUR L’ENTRETIEN PROGRAMME.IL EST APPLIQUE SUR LA CENTRALE DU PONT ADHESIVO: INDICA LA FECHA DE CADUCIDAD PARA EL MANTENIMIENTO PROGRAMADO.SE COLOCA EN LA CENTRALINA DEL PUENTE MFOX04500910 FOX 45... - Page 56 VERIFICA GENERALE / GENERAL TESTING VERIFICA GENERALE / GENERAL TESTING VERIFICA GENERALE / GENERAL TESTING VERIFICA GENERALE / GENERAL TESTING VERIFICA GENERALE / GENERAL TESTING VERIFICA GENERALE / GENERAL TESTING VERIFICA GENERALE / GENERAL TESTING VERIFICA GENERALE / GENERAL TESTING MFOX04500910 FOX 45...
- Page 57 9-1Pagina 9-1 di 57 MFOX04500910 FOX 45...
