ASSEMBL Y
A9235 PRO SPEAK EVO
FOR FL YON II
1.
2.
3.
4.
Remove the inner linings as indicated in
the helmet user manual.
Place the right speaker (R) in its seat on
the velcro.
Repeat the operations performed for the
right (R) speaker for positioning the left
(L).
Place the microphone base under the
chinstrap.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Caberg PRO SPEAK EVO
Summary of Contents for Caberg PRO SPEAK EVO
- Page 1 ASSEMBL Y A9235 PRO SPEAK EVO FOR FL YON II Remove the inner linings as indicated in the helmet user manual. Place the right speaker (R) in its seat on the velcro. Repeat the operations performed for the right (R) speaker for positioning the left (L).
- Page 2 ASSEMBL Y A9235 PRO SPEAK EVO FOR FL YON II Adjust the position of the microphone by deforming the boom and insert it in the relative seat indicated by the symbol of the microphone on the shell left side. WARNING check that the triangle on the microphone is facing the mouth.
- Page 3 ASSEMBL Y A9235 PRO SPEAK EVO FOR FL YON II Place the USB socket between the inner linings and the shell. Fit the keypad on the left side (helmet on), approximately 5 mm from the lower edge of the shell using the provided adhesive.
