Hotwire
5546 RTU Customer Premises
Installation Instructions
Document Number 5546-A2-GN10-00
September 1998

Before You Begin

The Hotwire
5546 RTU (Remote Termination Unit) interoperates with the Hotwire
8546 DSL Card in the DSLAM system. Verify that the 8546 DSL card has Firmware
Release 2.2 or higher.
An optional POTS (Plain Old Telephone Service) splitter is available for the Hotwire
5546 RTU. When a POTS splitter is installed, the telephone and 5546 RADSL (Rate
Adaptive Digital Subscriber Line) RTU can function at the same time over the same pair
of copper wires. In order to confirm the RTU installation, the POTS splitter should be
installed first.
To install a POTS splitter, refer to the appropriate POTS splitter document:
Document Number Document Title
5030-A2-GN10
5038-A2-GN10
Contact your sales or service representative to order additional product documentation.
Paradyne documents are also available on the World Wide Web at:
http://www.paradyne.com
Select Service & Support
Package Checklist
Verify that your package contains the following:
Model 5546 Remote Termination Unit (RTU)
DSL interface cable with RJ11 connectors
RJ45 to DB9 adapter plug (Part No. 002-0093-0031)
One ferrite choke (Model 5546-A1-200 only)
Power cord with power transformer
Warranty card
TM
Hotwire 5030 POTS Splitter Customer Premises
Installation Instructions
Hotwire 5038 Distributed POTS Splitter Customer
Premises Installation Instructions
Technical Manuals
1
