Hotwire
6038 MVL
Customer Premises Installation Instructions
Document Number 6038-A2-GN10-00
June 1998
Before You Begin
The Hotwire
6038 MVL
POTS (Plain Old Telephone Service) Filter works with
the Hotwire 6310 MVL Modem.
For MVL modem installation information, refer to
Document No. 6310-A2-GN10, Hotwire 6310 MVL
Modem Customer Premises Installation Instructions.
Verify that your package contains a Hotwire 6038 MVL
POTS Filter and an interface cable with RJ11 connectors.
What Does the Hotwire 6038 MVL POTS Filter Do?
The Hotwire 6038 MVL POTS Filter and Hotwire 6310 MVL Modem are components in
the Hotwire MVL System. This system provides high-speed Internet or remote LAN
access over traditional twisted-pair copper telephone wiring. With some telephones, an
optional POTS filter may be used to improve the data transmission throughput and
minimize the audible background noise during a telephone conversation.
Customer
Premises (CP)
Optional
POTS Filter
MVL Modem
FAX
RJ11
Wall Jack
TM
POTS Filter
(Multiple Virtual Lines)
Hub
Printer
Ethernet
Cable
1
6038 MVL POTS Filter
MVL Modem
Optional
POTS Filter
98-15995
RJ11
Wall
Jack
98-16039
Advertisement
Table of Contents
Related Manuals for Paradyne Hotwire 6038
Summary of Contents for Paradyne Hotwire 6038
- Page 1 POTS Filter and an interface cable with RJ11 connectors. What Does the Hotwire 6038 MVL POTS Filter Do? The Hotwire 6038 MVL POTS Filter and Hotwire 6310 MVL Modem are components in the Hotwire MVL System. This system provides high-speed Internet or remote LAN access over traditional twisted-pair copper telephone wiring.
- Page 2 Installing the Hotwire 6038 MVL POTS Filter Procedure To connect a Hotwire 6038 MVL POTS filter: 1. Unplug the existing telephone interface cable from the RJ11 wall jack. 2. Plug the existing cable into the POTS filter jack labeled PHONE.
-
Page 3: Important Safety Instructions
6038 MVL POTS Filter Technical Specifications Item Specification Height x Width x Depth 1.02 x 1 x 2.5 (2.6 cm x 2.5 cm x 6.4 cm) Weight 2.1 ounces (59.5 grams) Approvals Refer to the equipment’s label for the FCC Part 68 Registration Number and Safety Certifications. - Page 4 RENs, contact the local telephone company. If the Model 6038 Telephone Line Filter causes harm to the telephone network, the telephone company will notify you in advance that temporary discontinuance of service may be required.
