AIM24000-48 Interface Module
Installation Instructions
Document Number AIM2-A2-GZ40-20
May 2005
Contents
AIM2-A2-GZ40-20
.......................................................................... 3
................................................................................................... 3
....................................................................................... 4
...................................................................... 4
.................................................................................................. 6
............................................................................ 7
................................................................................. 11
........................................................................................... 12
.......................................................................... 13
................................................................................................... 13
.............................................................................................. 14
.................................................................................... 14
.......................................................................................... 15
.............................................................................. 20
...................................................................................................... 21
........................................................................................... 22
..................................................................................................... 24
May 2005
...................................................... 2
........................................... 3
.......................................................... 4
................................................. 23
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Paradyne AIM24000
Summary of Contents for Paradyne AIM24000
-
Page 1: Table Of Contents
Warranty, Sales, Service, and Training Information ........... 3 AIM24000 Description ..................4 Unpacking and Inspecting the AIM24000 ............4 Installing the AIM24000 in a BLC ..............4 Verifying Power ....................6 Connecting the ADSL Cables ................7 ADSL Remote Connection ................. -
Page 2: Software And Firmware License Agreement
Software and Firmware License Agreement ONCE YOU HAVE READ THIS LICENSE AGREEMENT AND AGREE TO ITS TERMS, YOU MAY USE THE SOFTWARE AND/OR FIRMWARE INCORPORATED INTO THE PARADYNE PRODUCT. BY USING THE PARADYNE PRODUCT YOU SHOW YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE AGREEMENT. IN THE EVENT THAT YOU DO NOT AGREE WITH ANY OF THE TERMS OF THIS LICENSE AGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT IN ITS ORIGINAL PACKAGING AND YOUR SALES RECEIPT OR INVOICE TO THE... -
Page 3: Product Documentation Online
and you may also have other rights which vary from one state or jurisdiction to another. 6. In no event will Paradyne be liable to Licensee for any consequential, incidental, punitive or special damages, including any lost profits or lost savings, loss of business information or business interruption or other pecuniary loss arising out of the use or inability to use the Software, whether based on contract, tort, warranty or other legal or equitable grounds, even if... -
Page 4: Aim24000 Description
NOTE: Although the AIM24000 can be installed in both the 12000 and the 12000E BLC, the 12000 has the capability to support AIM24000 ports 1–24 only. In order to make use of all 48 ports, you must install the AIM24000 in a 12000E. Procedure To install the AIM24000 in a 12-slot BLC: 1. - Page 5 PCB with the slot module guides. 3. Slide the AIM24000 into the chassis until it is fully seated. Do not use excessive force.
-
Page 6: Verifying Power
PCB with the slot module guides on both sides. 3. Slide the AIM24000 into the chassis until it is fully seated. Do not use excessive force. 4. Tighten the fastening screws on the AIM24000 faceplate. Do not over-tighten the fastening screws. -
Page 7: Connecting The Adsl Cables
ADSL connection for AIM24000 ports 1–24 and the top row of RJ21 connectors (B) provides the ADSL connection for ports 25–48. For example, if the AIM24000 is installed in Slot 3 of a 12000E, ADSL cables must be connected to: RJ21 Connector 3B for AIM24000 ports 25–48... - Page 8 Attaching RJ21 Connectors to the 12-Slot BLC Procedure 1. Detach the hook and loop fastener strap from the RJ21 receptacle. Lift the hook and loop fastener tab on the left and pull the strap open towards the right, leaving it looped under the right side of the connector frame. 2.
- Page 9 ADSL connection for AIM24000 ports 1-24 and the connectors on the right (B) provide the ADSL connection for AIM24000 ports 25–48. For example, if the AIM24000 is installed in Slot 3 of a 4000E, ADSL cables must be connected to: RJ21 Connector 3A for AIM24000 ports 1–24...
- Page 10 Attaching RJ21 Connectors to the 4-Slot BLC Procedure 1. Detach the hook and loop fastener strap from the female RJ21 connector port: lift the hook and loop fastener tab from the bottom and pull the strap open, towards the top of the chassis, leaving it looped under the top side of the connector frame.
-
Page 11: Adsl Remote Connection
RJ21 cable connector to the connector frame on the chassis using the captive screws. ADSL Remote Connection A single line connection can be established between any port on the AIM24000 and any compatible G.lite, ADSL, ADSL2, or ADSL2+ modem. AIM2-A2-GZ40-20... -
Page 12: Adsl Rj21 Pinouts
ADSL RJ21 Pinouts Table 1. RJ21 Pinouts Port Ring RJ21 Connector on BLC RJ21 Cable Connector (Pins 25 and 50 are not used) May 2005 AIM2-A2-GZ40-20... -
Page 13: Verify The Adsl Connection(S)
Link up time between the AIM24000 and remote modems can vary from 15 seconds to five minutes depending on the quality, gauge, and distance of the copper cable pair or pairs being used. -
Page 14: Adsl Parameters
ADSL Parameters No configuration is necessary for the AIM24000 to operate at the default settings. Table 3. AIM24000 Defaults Parameter Default Backbone-VLAN Downstream Speed n/a (Adaptive Port Mode) Flood Uplink Frame Type 1483LLC IP Range 1 0.0.0.0 – 255.255.255.255 IP Range 2-4 0.0.0.0 –... -
Page 15: Circuit Configuration
Port Mode Default: Adaptive Adaptive – An AIM24000 port set to port mode adaptive will automatically train up to the best possible speed supported by the AIM24000, the ADSL modem at the remote end, and the copper cable pair connecting the two. - Page 16 The modems will train at a lower speed if line conditions deteriorate. Off – An AIM24000 port set to port mode off has been administratively turned off. Filter IP Address Settings IP Range 1 Default: 0.0.0.0 –...
- Page 17 DHCP Option 82 Default: Disabled NOTE: DHCP Option 82 is available for configuration in NMS only; it cannot be configured via the CLI or SNMP. Dynamic Host Configuration Protocol (DHCP) Option 82 allows dynamic configuration of IP addresses by adding an identifying string to packets (Option 82) that enables your DHCP Server to recognize which BLC port an IP address request is coming from.
- Page 18 VPI and VCI to the same settings at which the ATM cells from the remote ADSL modem were detected. Off – An AIM24000 port with VPI/VCI Detect off will default to VPI 0 and VCI 35 unless the port was previously set at VPI/VCI Detect on and had already detected the VPI and VCI settings of the remote ADSL modem.
- Page 19 Alcatel – Alcatel is ADSL technology and Alcatel ADSL modem compatible. Full Rate ADSL – An AIM24000 port that is operating in full rate ADSL mode and utilizing a single line for both phone and data requires an in-line splitter at both ends of the ADSL connection.
-
Page 20: Other Configuration Options
15. The eventual outcome could be any combination of existing possible upstream and downstream bandwidths, and may or may not be reflected in the following tables. For AIM24000 ports configured at Fixed or Fixed Adaptive port modes, bandwidth parameters must be manually specified. -
Page 21: Data Storage
Data Storage Configuration backup is inherent in the AIM24000. Upon initial power up of the host BLC, default parameters of the AIM24000 will remain in place unless changed through the NMS, CLI, or SNMP. Memory AIM24000 parameter configurations are automatically recorded in both the Random Access Memory (RAM) of the AIM24000 and the Non-Volatile Random Access Memory (NVRAM) of the BLC's management module. -
Page 22: Firmware Upgrades
Downloading a Port Template AIM24000 configuration files can also be flash downloaded from a local file to your BLC's management module via a TFTP tool using a put command. A previously saved port configuration file can be applied to multiple ports on your AIM24000 simultaneously, via your BLC management module, by entering the port value as follows. -
Page 23: Regulatory Compliance For Class A Equipment
Regulatory Compliance for Class A Equipment The following regulatory information applies to the AIM24000 as installed in a BLC. NEBS: GR-63-CORE, GR-1089-CORE EMC: FCC Part 15; CSA/C108.8; EN55022, EN55024 SAFETY: UL 60950-1 1st Edition, UL Marking; CSA 22.2 No. 60950-1-03;... -
Page 24: Specifications
Specifications Table 6. AIM24000 Specifications Specification Criteria Dimensions 12.75" High x 1.15" Wide x 16.75" Deep (32.4 cm x 2.9 cm x 42.5 cm) Environment Operating Temperature: 32°F to 122°F (0°C to 50°C) in a 12000 BLC –40°F to 149°F (–40°C to 65°C) in a 4000 BLC·...
