- Page 1 Quick Installation Guide NO. G03-65X_MI215QIG-F Rev: 2.0 Release date: 2023-08-14 Notice: The photos in this file are for illustration purpose only. The model may not be the latest version. Please refer to the product you purchased for actual specification.
-
Page 2: To Open The Chassis
I. To Open the Chassis 1. Locate the screws in the spots marked on the 2. The internal structural view of the system for top cover of the system and unscrew them one further installation. by one and lift the cover up to open the chassis. II. - Page 3 Alignment Key Alignment Key Golden Finger Indicator 5. Make sure that Pin-1 Golden Finger Indicator in the place as shown in the above photo and match the two alignment keys on the CPU with two points of the socket. CPU can only be correctly installed in this direction.
- Page 4 Top Side Top Side Paste Here! Place the CPU heatsink upon the installed CPU. And Apply corresponding thermal pad to CPU heatsink tighten up the 4 screws on marked spot. (P/N: HCS310HS1-F*1pcs, 60*52*1.0 mm). When installation finished, tear off the protective film *Note: Please make sure the screw holes on the top of from the pads.
- Page 5 V. To Install M.2 M-Key (2280) *Note: M.2 M-Key type-2280 slot (at location M2M1) supports SATA/PCIe Gen.3 x4 interface and M.2 M-Key type-2242 slot (at location M2M2) supports SATA/PCIe Gen.4 x4 interface. Both of M-Key slots support NVMe. M2M1 (2280) M2M2 (2242) 1.
- Page 6 VI.To Install M.2 E-Key (2230) *Note: M.2 E-Key type-2230 slot supports PCIe x1/USB2.0 interface and CNVio for Wi-Fi. 1. Locate the M.2 E-Key (2230) slot on the board. 2. Remove the marked screw and screw bolt at location Prepare compatible M.2 E-Key (2230) card. MH1, and use screw bolt to lock compatible card to the slot in later installation.
- Page 7 6-1. The washer①&the hexagonal screw nut②. 6-2. Push the washer① through the antenna head. 7. And then lock the antenna screw head to the front 8. Press the metal hat on the end of the antenna string side of the panel with the hexagonal screw nut ② to corresponding antenna slot on the card as and tighten it up.
- Page 8 3. Insert the golden-finger side of the compatible card 4. Secure the card to the board by tightening up the into the slot and press down. See to it that the golden- screw to the marked spot. finger side should be fully plugged into the slot. *Note: 1.
- Page 9 IX. To Install 2.5” Device to HDD Racks 1. Locate the HDD racks on the chassis. 2. Remove the above marked screws that lock the racks to the chassis and pick them out of the chassis (4 screws in total on both sides). SATA Power Cable SATA Cable...
- Page 10 Notice: Make sure that: 1.the racks are installed to its original place; 2. HDD SATA & power connectors face towards the direction of the chassis with enough room to facilitate cable connection. Notice: When all necessary installations are finished, please make sure that all cables unplugged before installations are connected to their original locations before restoring the cover to the chassis and screws locked to its original locations (Refer to Part II).
- Page 11 This QIG is intended to be used as a practical and informative guide only and is subject to change without prior notice. It does not represent commitment from Jetway Information Co., Ltd. Jetway shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of the product or documentation, nor for any infringements upon the rights of third parties, which may result from such use.
