- Page 1 JETWAY AIO System User's Manual NO. HA238SAH-H110-QIG Revision: 1.0 Release Date: July 26, 2017...
- Page 2 Information in this manual is protected by copyright laws and is the property of JETWAY. Changes to the specifications and features in this manual may be made by JETWAY without prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or published in any form or by any means without JETWAY's prior written permission.
-
Page 3: Table Of Contents
Table of Contents Overview Of Your Documentation ................. 4 Box Contents ........................5 Specifications ........................6 Getting Start With Your PC ..................... 7 Disassembly Instructions ....................Adjustment of View Angle ....................13 Setting Up Your PC ......................15 Appendix 1 : Precautions and Safety Notices ..... -
Page 4: Overview Of Your Documentation
Overview Of Your Documentation Document Type Your documentation contains PDF user manuals to help you perform various tasks. Document Type User’s manual provides information about setting up your computer. Non-printed documentation Manual CD (containing this manual) provides information about using your computer, cleaning and maintaining the monitor and the accessories, and the common solutions to problems you may encounter while using your computer. -
Page 5: Box Contents
Box Contents Carefully unpack the system and check that the following items were included. If any are missing or damaged, please contact your vender. Retain the box and packing in case of you need to transport your personal computer in the future. The fitted foam packing is ideal for protecting the device during transporting. -
Page 6: Specifications
Specifications Jetway Model Intel® Kabylake-S/Skylake-S Prozessor LGA 1151 Socket Core™i7/ i5/ i3 Processor(CPU) Support Max. 65W. Intel® H110 Express Chipse Chipset Operating System Windows 7 / 8.1 / 10 Dual channel SODIMM DDR4 2133MHz Memory 2 x SODIMMs. 32GB Maximum 1 x 2.5"... -
Page 7: Getting Start With Your Pc
Getting Start With Your PC Touring Your PC This section describes the views and the features of the controls, ports, buttons, components, and connectors of your computer. Front View Item Description Power Press power button to turn on computer. Indicators LED indicators... -
Page 8: Rear View
Rear View Item Description Vents The design of the vents is to prevent the computer from overheating. The internal fans blow hot air away from heat-sensitive components in the computer. Keep the vents clean and free of dirt and dust, as blocking it may cause serious thermal problems. Computer Stand You can adjust the computer stand for the best viewing angle. - Page 9 Right-side View Item Description USB 2.0 Ports Connect the USB plugs into the USB ports to connect your USB devices, such as MP3 players, digital cameras, keyboard and mouse, or external hard disk drives, etc.
- Page 10 Bottom-side View Ver 2.0 Item Description DC Power Connector Connect the DC power to this port USB3.0 The USB port supports the USB3.0 specification. Use this port for USB devices such as a USB USB3.0 keyboard/mouse, USB printer, USB flash drive and etc. DisplayPort DisplayPort is a digital display interface which is primarily used to connect a video source to a DisplayPort display device such as a computer monitor, though it can also be used to transmit audio, USB, and other forms...
-
Page 11: Disassembly Instructions
Disassembly Instructions Follow steps below to disassemble the AIO. Face Down the AIO Face down the AIO on a smooth surface using a soft material between surface and AIO to protect faceplate. Remove the Back Cover Remove the back cover by removing the 9 fixed screws.(Red circle)Then pull over back cover. Separate MB Shield Cover Remove the 8 fixed screws and lift the shield cover. - Page 12 Separate the CPU Thermal Module Loosen the 6 fixed screws and lift the CPU thermal module. Separate the DRAM Thermal Module HDD bracket separate Loosen 4 screws to separate HDD-bracket...
-
Page 13: Adjustment Of View Angle
Adjustment of View Angle Tilt Range (degree): Tilt Range (degree): Backward 20°~23° Forward -5°~-2° Lift Range: 130mm+/-5mm... - Page 14 Pivot function: The screen of the All-In-One PC is 90 degree rotatable. In order to avoid scratching foot stand and bezel, move screen up, then rotate. To adjust the image alignment, follow steps A and B. A. Right-click on the desktop then select “Display settings”. B.
-
Page 15: Setting Up Your Pc
Setting Up Your PC This section describes how to set up your computer and make adjustments to the monitor. Preparing To Setup Your PC Before attempting to set up your computer, to protect the computer and monitor, you should: • find a flat open area on your desk to position your computer. •... -
Page 16: Turning On Your Pc
Turning On Your PC After you finish the installation of your computer, press the Power computer to turn it on. Then follow the on-screen instructions to complete the initial setup. Turning Off Your PC To turn off the system, close all the active windows, and then click the Windows start menu at bottom left corner of your screen, then click power button then click Shutdown button. -
Page 17: Appendix 1 : Precautions And Safety Notices
: Precautions and Safety Notices Appendix 1 Safety Precautions Observe all cautions and safety related notes located inside the display cabinet and on the display chassis. Operation of these displays outside the cabinet or with the cover removed involves a shock hazard from the display backlight’s inverter. - Page 18 Handing and Placing Methods Correct Methods Incorrect Methods Only touch the metal frame of the LCD panel . Pressing surface of LCD panel with fingers, may scratch Do not touch surface of the polarizer. the surface of panel. Take out foam on left and right side. Take out the AIO by grasping top of the machine.
- Page 19 Placing AIO on foreign objects, could scratch the Place the AIO on clean and soft foam pad. surface of the panel. If panel is placed face down on the lap, that could scratch the surface of the panel.
-
Page 20: Appendix 2: Packing Of Color Box
Appendix 2: Packing of Color Box Put the AIO in the EPE bag Left EPE cushion Right EPE cushion Stand Stand EPE AIO Body cushion Place the AIO into the carton and then put all accessories into the box and then seal the carton with tape.
