Jetway Mini-TOP Series
User's Manual
No: G03-JC600EN-F
Manual revision: 1.0
Release Date：July, 2010
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mini-TOP Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JETWAY Mini-TOP Series

Summary of Contents for JETWAY Mini-TOP Series

  • Page 1 Jetway Mini-TOP Series User’s Manual No: G03-JC600EN-F Manual revision: 1.0 Release Date：July, 2010...

  • Page 2: Package Contents

    User’s Notice Copyright of this manual belongs to the manufacturer. No part of this manual, including the products and software described in it may be reproduced, transmitted or translated into any language in any form or by any means without written permission of the manufacturer. This manual contains all information required for the utilization of this product to meet the user’s requirements.
  • Page 3 Safety Instruction Operate the product according to the correct installation steps and with great care to make sure safety and comfort using experience. Please refer to the following safety instruction guide to avoid danger of electric shock or fire. Abide by the previous safety instruction guide to use and maintain the product and the hard disk to make sure of safe operating environment.

  • Page 4: Table Of Contents

    TABLE OF CONTENT USER’S NOTICE ........................ii PACKAGE CONTENTS ......................ii SAFETY INSTRUCTION ......................iii CHAPTER 1 BRIEF INTRODUCTION PRODUCT FEATURES....................1 SPECIFICATION ......................4 FRONT PANEL DIAGRAM ..................5 REAR PANEL DIAGRAM ................... 5 CHAPTER 2 HARDWARE INSTALLATION BEFORE HARDWARE INSTALLATION..............6 TO INSTALL MEMORY MODULE(S).................
  • Page 5 4-3-4 KARAOKE ......................35 4-3-5 GAME MENU....................38 4-3-6 OTHER PROGRAM..................40 4-3-7 TO ADD PROGRAM ..................42 4-3-8 TO EXIT ......................45 APPENDIX ONE TO OVERCLOCK GPU MEMORY CLOCK..........46 APPENDIX TWO NOTICES ....................48...

  • Page 6: Chapter 1 Brief Introduction

    Chapter 1 Brief Introduction 1.1 Product Features Thank you for your support for Jetway by purchasing Mini-TOP, a new product developed, designed and manufactured by Jetway under its leading technical power and consistent dedication to fine workmanship. Mini-TOP is a product to provide you HTPC enjoyment and stunning game-playing experience.
  • Page 7 Mini-TOP has the following features besides other basic functions: HDMI: Jetway Mini-TOP series, the Jetway HTPC system, come with an HDMI output connector to realize full HD1080P high-definition multimedia home theatre enjoyment. User can enjoy seamless playback of HD DVD and Blu-ray disk in the living room by connecting system to LCD TV set with an HDMI cable for non-compressed, full digital audio and video movie transmission.
  • Page 8 ION TOP system and take necessary data from it, thus reducing the complexity in network establishment. Giga LAN: Jetway Mini-TOP series are integrated with Gigabit LAN network controller with ACPI management realizing efficient power management for the operating system.

  • Page 9: Specification

    1 * Antenna Hole 1 * power connector 1 * 12V DC-in Power Supply 1 * 60W AC-DC Adapter 1 * power cord 1 * Jetway remote control Standard Accessories 1* stand WIFI antenna Wireless keyboard/Wireless microphone/Wireless microphone receiver Optional Accessories...

  • Page 10: Front Panel Diagram

    1.3 Front Panel Diagram Remote Sensor USB Connectors Power Switch W /Power LED Card Reader Slot Line-out /Optical SPDIF out shared connector 1.4 Rear Panel Diagram RJ-45 LAN Antenna Hole DC12V Jack HDMI USB Connectors Connector Connector E-SATA/USB Connector...

  • Page 11: Chapter 2 Hardware Installation

    Chapter 2 Hardware Installation Please turn off the system and make sure that power cord is unplugged before WARNING! hardware installation to ensure safety. 2.1 Before Hardware Installation Put the side of I/O back panel towards you and push the removable cover of the chassis in the direction towards you.

  • Page 12: To Install Memory Module(S)

    2.2 To Install Memory Module(s) 1. Locate the SO-DIMM memory slot(s) on the board. Insert the gold-figure side of the compatible Press down as the photo shows. The eject DDRII SO-DIMM into the slot at a 30 degree. tabs will lock it if installed correctly.

  • Page 13: To Install Hard Disk Drive

    Notice: When installing, align the notch on the module matches the break on the slot. Memory module can only be installed in such a direction. If not, it will cause serious damage to module and the board. When you install memory module fully into the DIMM socket the eject tab should be locked into the module very firmly and fit into its indention on both sides.
  • Page 14 Lock the SATA hard disk to one of the racks Lock the SATA hard disk to the other rack by by tightening the screws in the marked tightening the screws in the marked position. position. Fit the hard disk into HDD connector on the Lock the racks to the board by tightening up motherboard in this direction.

  • Page 15: To Install Wifi Antenna

    2.4 To Install WIFI Antenna Locate the marked antenna hole on back Then connect the external WiFi receiver panel. antenna to it. 2.5 To Restore Removable Chassis Cover Gently put the removable cover back to This edge with 3 plastic equidistant notches the chassis should be parallel to edge of the chassis’...
  • Page 16 Front Panel Back Panel Place the removable cover upon the chassis. See to it that the left and right edges of the cover should be parallel to those of the chassis and there should be a distance of about 1 cm left between the front edge and the front panel of the chassis as the photo shows.

  • Page 17: To Assemble The Stand

    2.6 To Assemble the Stand See to it that the marked square space See to it that the marked tiny round space and fitted into the square notch on the chassis. the screw hole in on the chassis are in the same place.

  • Page 18: To Vesa Mount The System

    2.7 To VESA Mount the System Attach the chassis rack to the back of monitor by See to it that the square notch on the tightening up the screws in the marked position. chassis is fitted into the marked square space on the stand and marked notch on the back panel of the chassis fitted in the round space of the VESA mount...
  • Page 19 The square notch on the chassis and the Lock the chassis to the rack by tightening up square space on the stand. the screw in the marked position.

  • Page 20: Chapter 3 I/O Connection And Remote Control

    Chapter 3 I/O Connection and Remote Control After needed hardware installed inside the chassis, you can proceed on to connect cables to the rear panel and power on the system to enjoy the using Mini-TOP. 3.1 Rear Panel Connection USB Connector: There are 3*USB connectors on rear IO panel (one is USB/E-SATA shared connector that functions according to device connected) and 2*USB connectors on the front panel to connect USB mouse, keyboard and other USB storage devices to the system.
  • Page 21 USB/E-SATA Shared Connector: The function of this connector depends on different device connected to this connector through different cable. It could function as: E-SATA connector when a compatible ESATA hard disk is connected to it through SATA cable. USB connector when a compatible USB device is connected to it through USB cable. DVI (Digital Visual Interface) Connector: This interface standard designed to maximize the visual quality of digital display devices such as flat panel LCD computer displays and digital projectors.
  • Page 22 HDMI (High-Definition Multimedia Interface): This point-to-point interface is for audio and video signals designed as a single-cable solution for home theater and consumer electronics equipment. DC12V Jack: Connect the power adapter to DC12V jack after connecting connector power cord to adapter.

  • Page 23: Front Panel Connection

    3.2 Front Panel Connection Remote Sensor Power on Switch W/ Power LED MIC Connector Line-out/SPDIF_Out shared Connector USB Connectors Card Reader Slot Card Reader Slot: to insert the MMC/SD/MS card to the front 3 in 1 card reader. USB Connectors: to connect USB mouse, keyboard and other USB storage devices to the system. Line-Out /Optical SPDIF out shared Connector: this connector can function as ordinary audio line-out connector or optical SPDIF out connector depending on different device connected to it: Audio Line-out connector: by connecting stereo speakers or headphones.

  • Page 24: Remote Contrl Diagram

    3.3 Remote Control Diagram The accessories of Mini-TOP include a remote control with which you could easily carry out a lot functions to bring you the friendly user-experience during HTPC watching, Karaoke, and other functions.

  • Page 25: Function Description Of The Remote Control

    3.4 Function Description of the Remote Control Icon Function Description Press this button to power on/shut down the computer. Power Press to set computer into sleep mode. STANDBY The ‘ESC’ key on the keyboard. Close the currently activated dialog box or task. CLOSE Opens the play DVD window in the Windows Media Center or opens the main menu or a DVD movie, if available.

  • Page 26: Media Center

    This is to be used with mouse control buttons for drag operation. Press and hold “Lock” to select the object and move cursor at the lock same time to desired position press again to un-lock. The ‘Enter’ key on the keyboard. The direction key that control the cursor movement.
  • Page 27 Windows common dialog forward function. Forward Opens internet explorer. Full screen function button. Full Screen To delete selected function. Delete To fast return desktop button. DeskTop Press the Mic OSD button on remote control to invoke the on-screen-display Karaoke microphone/audio options during Mic OSD...

  • Page 28: Chapter 4 New Vision User Interface

    Chapter 4 New Vision User Interface After necessary hardwares installed and needed connections made, please install the operating system and motherboard utility driver. There is also a ‘New Vision’ user interface disk attached in the package, please find and install it afterwards to enjoy more HTPC functions provided by Mini-top! New Vision provide quick platform for user to play video, music and games or browse pictures easily.
  • Page 29 1. Click ‘Next’ on the welcom setup wizard 2. Select destination location, then click ‘Next’. menu. 3. Click ‘Next’ to select a start menu folder. If 4. Select the additional tasks you would like Setup to you would like to select a different folder, perform while installing New Vision, then click ‘Next’.
  • Page 30 5. Click ‘Install’ to continue the installation, or click 6. Click ‘Finish’ to complete the setup. The ‘Back’ if you want to review or change any application may be launched by selecting the previous settings. installed icons. Before you find the New Vision user interface program in the DVD that Notice! comes with the system and install it in default destination location, please install Windows operating system and motherboard driver.

  • Page 31: To Activate New Vision Program

    4-2．To Activate New Vision Program Double click New Vision shortcut or right-click on it, then click ‘Open’ to activate New Vision User Interface after installation completed. The following screen shall show up: Click on the New Vision square frame to continue executing (User can use [Enter] on keyboard or [OK] on remote control to enter as well).

  • Page 32: New Vision User Interface Basic Operations

    4-3． New Vision User Interface Basic Operations As shown in the photo below, you will see New Vision main menu. Before explaining the menu options, let’s learn the function keys first listed on the bottom part of the screen. • Press direction key Up/Down (↑/↓)on keyboard or remote control to select the options you wish to confirm or make changes.

  • Page 33: To Play Video

    4-3-1. To Play Video Play Video: Select this option to play Video Use direction key Up/Down (↑/↓) on keyboard or remote control to select ‘Play Video’ on the main menu. Click [OK] on remote control (or the left button of the mouse, or press [Enter] on keyboard) to confirm.
  • Page 34 When playing the video, use the following remote control buttons to change settings: VOL+/-: Volume Up/Down; :Rewind ； : Forward; ： Play/Pause; :Replay; : Skip; : Stop. Media Player: use Windows Media Player to playback video. Video Libraries：playback video in Video Libraries of your system using user preset media player.
  • Page 35 drive in advance. Removable Device：Playback video from removable devices. Press Up/Down to select the desired removable device. Return： Press Left key “←” on remote control or keyboard) to return to previous page. Please make sure that the removable device is properly connected to Notice! the system before playing video.

  • Page 36: To Play Music

    4-3-2. To Play Music Play Music: Select this option to play music. Use Up/Down (↑/↓) button on remote control or keyboard to select ‘Play Music’ on the main menu. Press [OK] on remote control (or click the left button of the mouse, or press [Enter] on keyboard or) to confirm.
  • Page 37 Music Libraries：play music from Video Libraries of your system using user preset media player DVD/CD：play music from DVD/VD. Insert DVD/CD into the optical disk drive in advance Removable Device：Playback music from removable devices. Press Up/Down to select the desired removable device. Return：...

  • Page 38: To Browse Pictures

    4-3-3. To Browse Pictures Browse Pictures: Select this option to browse pictures. Press Up/Down (↑/↓) on remote control or keyboard to select ‘Browse Pictures’ on the main menu. Click [OK] on remote control (or the left button of the mouse, or press [Enter] on keyboard or) to confirm.
  • Page 39 Picture Viewer: browse pictures stored in the computer by Microsoft Picture Viewer Media Player: use Windows Media Player to browse pictures. Picture Libraries：Browse pictures listed in Picture Libraries of Windows system. Removable Device：Browse pictures stored in desired removable device. Return： Press Left key “←” on remote control or keyboard) to return to previous page.

  • Page 40: Karaoke

    4-3-4. KARAOKE KARAOKE: Enjoy the fun of Karaoke with interesting audio settings. Press Up/Down (↑/↓) key on remote control or keyboard to select ‘KARAOKE’ function. Press [OK] on remote control (or the left button of the mouse, or [Enter] on keyboard) to confirm.
  • Page 41 Video Libraries：Find and play music video in Videos Libraries. KARAOKE：Play music video/music in DVD/CD. Insert DVD/CD into the optical disk drive in advance. Removable Device：play music/music video in desired removable device. Return： Press Left key “←” on remote control or keyboard) to return to previous page. Delete: Press the DEL on keyboard to delete programs user added later to the menu (the default programs cannot be deleted).
  • Page 42 Mic Volume: increase or decrease the volume of MIC. Mic Echo: increase or decrease the echo effect of MIC. Mic Magic Voice: change MIC input voice into a desired magic voice. Change Key: change the key of the music upward or downward to meet singer’s desired key.

  • Page 43: Game Menu

    4-3-5. Game Menu Game Menu: Select this option to play game listed on game menu. Press Up/Down (↑/↓) on remote control or keyboard or to select ‘Game Menu’ on the main menu. Press [OK] on remote control (or the left button of the mouse, or press [Enter] on keyboard) to confirm.
  • Page 44 The packaged New Vision software has no game program added to the list by default. User shall add game programs as desired to the list through ‘Add Program’ option on main menu. For more detail on how to add program please refer to 4-3-7.

  • Page 45: Other Program

    4-3-6. Other Program Other Program：User can add programs to this list Press Up/Down (↑/↓) on remote control or keyboard to select ‘Other Program’ on the main menu. Press [OK] on remote control (or the left button of the mouse, or press [Enter] on keyboard) to confirm.
  • Page 46 The default setting for New Vision has no program added to the list by default. User shall add other programs as desired to the list through ‘Add Program’ option on main menu. For more detail on how to add program please refer to 4-3-7.

  • Page 47: To Add Program

    4-3-7. To Add Program Add Program: Add programs to New Version User Interface Press Up/Down (↑/↓) on remote control or keyboard to select ‘Add Program’ option. Press [OK] on remote control (or the left button of the mouse, or press [Enter] on keyboard) to confirm.
  • Page 48 The “Open” dialog window will automatically appear. Select the file you wish to add from the dialog window. Click ‘Open’ to confirm the operation. Only programs with .exe file extension can be added. You will see the following screen pop up for you to decide where the .exe program to be added to.
  • Page 49 Press Up/Down (↑/↓) on remote control or keyboard to select desired destination for the added program. For example, if you added ‘DVDMaker’ program to [Other Program], a newly added option ‘DVDMaker’ will appear in [Other Program] menu list. If you add it to ‘Game Menu’, it shall appear on the Game Menu list.

  • Page 50: To Exit

    4-3-8. To Exit Press Up/Down (↑/↓) on remote control or keyboard to select ‘Play Music’ on the main menu. Press [OK] on remote control (or the left button of the mouse, or press [Enter] on keyboard) to confirm. You can exit New Vision program now.

  • Page 51: Appendix One To Overclock Gpu Memory Clock

    Appendix One To Overclock GPU Memory Clock Use can overclock GPU memory clock through One-Key Overclocking function: During normal POST process, the following picture will show for about 4 seconds: During POST, user can: Press [DEL] to run Setup; Press [F6] to over GPU memory Clock 7%; Press [F7] to over GPU memory Clock 7%.
  • Page 52 Computer restarts automatically. If previous overclocking steps have taken effect, POST will not ask user to press[F6] or [F7] to overclock. Notice！ 1. One-Key Overclock GPU memory clock function will be removed if you clear CMOS. 2. BIOS setting/Miscellaneous Control/GPU Memory Clock should be the default setting ‘Auto’...

  • Page 53: Appendix Two Notices

    Appendix Two Notices General Notices European Union CE Marking and Compliance Notices Products intended for sale within the European Union are marked with the Conformity European (CE) Making, which indicates compliance with the applicable Directive and European standards and amendments identified. Shielded Cables Notice All connections to other computing devices must be made using shielded cables to maintain compliance with FCC regulations.

  • Page 54: Electronic Emissions Notices

    for use by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature. In some situation or environment, the use of Wireless LAN PCI Express Mini Card may be restricted by the proprietor of the building or responsible representatives of the organization.
  • Page 55 equipment. FCC Rules and Regulations-Part 15 This devices uses, generates and radiates radio frequency energy. The radio frequency energy produced by this device is well below the maximum exposure allowed by the Federal Communications Commission (FCC) This device complies with the limits for the Class B digital device pursuant to Part 15 subject to the following two conditions: This device may not cause harmful interference.
