3.4.6.1
Smart Fan Mode Configuration
Options Summary
Fan 1 Smart Fan Control
Smart Fan Mode Select
Temperature Source
Select the monitored temperature source for this fan.
Temperature 1
Temperature 2
Temperature 3
Temperature 4
Duty Cycle 1
Duty Cycle 2
Duty Cycle 3
Duty Cycle 4
Duty Cycle 5
Auto fan speed control. Fan speed will follow different temperature by different duty
cycle 1-100
Chapter 3 – AMI BIOS Setup
Manual Duty Mode
Auto Duty-Cycle Mode Optimal Default, Failsafe Default
CPU Temperature
System Temperature
System Temperature 2
60
50
40
30
80
70
60
50
40
Optimal Default, Failsafe Default
46
