- Page 1 User Manual Refrigerator-Freezer CNCQ2T620EX CNCQ2T620EW CNCQ2T620DX CNCQ2T620DW CNCQ2T618EX CNCQ2T618EW CNCQ2T618EB...
- Page 2 WARNING:Risk of fire/flammable material The symbol indicates there is a risk of fire since flammable materials are used. Take care to avoid causing a fire by ingiting flammable material. VAROVÁNÍ: Nebezpečí Požáru/Hořlavého Materiálu Symbol označuje riziko požáru, protože byly použity hořlavé materiály. Dbejte na to, aby nedošlo ke vzniku požáru zapálením hořlavého materiálu.
-
Page 3: Table Of Contents
Contents 5 Safety information Before first use Installation Daily use 10 Intended use Product description 13 Control panel 14 Use Adjust the temperature for fridge Adjust the temperature for freezer 15 Fine Tuning function ”0° “ drawer function 20 Equipment Energy saving tips 23 Care and cleaning Troubleshooting... - Page 4 Thank you Thank you for purchasing a Candy Product. Please read these instructions carefully before using this appliance. The instructions contain important information which will help you get the best out of the appliance and ensure safe and proper installation, use and maintenance.
- Page 5 Safety information WARNING – Important Safety information NOTICE-General information and tips Environmental information Disposal Help protect the environment and human health. Put the packaging in applicable containers to recycle it. Help to recycle waste of electrical and electronic appliances. Do not dispose appliances marked with this symbol with the house- hold waste.
-
Page 6: Safety Information
Safety information Before switching on the appliance for the first time read the following safety hints!: WARNING! Before first use ▶ Make sure there is no transport damage. ▶ Remove all packaging and keep out of children´s reach. ▶ Wait at least two hours before installing the appliance in order to ensure the re- frigerant circuit is fully efficient. - Page 7 ▶ Notice that the appliance，for example CNCQ2T620EX、CNCQ2T620EW、CN CQ2T618EX、CNCQ4T618EW、CNCQ4T618EB, is set for operation at a specific ambient range between 10 °C and 38°C.
- Page 8 Safety information WARNING! ▶ Do not store or use inflammable, explosive or corrosive materials in the appli- ance or in the vicinity. ▶ Do not store medicines, bacteria or chemical agents in the appliance. This ap- pliance is a household appliance. It is not recommended to store materials that require strict temperatures.
- Page 9 Safety information WARNING! ▶ Hold the plug, not the cable, when unplugging the appliance. ▶ Do not clean the appliance with hard brushes, wire brushes, detergent powder, petrol, amyl acetate, acetone and similar organic solutions, acid or alkaline solu- tions. Please clean with special refrigerator detergent to avoid damage. ▶...
-
Page 10: Intended Use
Intended use Intended use This appliance is intended for cooling and freezing food. It has been designed exclusively for use in household and similar applications such as staff kitchen areas in shops, offices and other working environments; farm houses and by clients in hotels, motels and other residential type environments as well as in bed-and-bre- ackfast and catering business. -
Page 11: Product Description
Product description NOTICE CNCQ2T620EX CNCQ2T620EW CNCQ2T620DX CNCQ2T620EW A: Refrigerator compartment 1-Control pannel 2-Glass shelf 3-Glass shelf 4-Glass shelf 5-Drawer cover 6-Humid y Zone drawer 7-Drawer cover 8-”0°“ drawer 9-Door balcony B: Freezer compartment 10-Upper freezer storage drawer 11-Middle freezer storage drawer... - Page 12 Product description NOTICE CNCQ2T618EW CNCQ2T618EB CNCQ2T618EX A: Refrigerator compartment 1-Control pannel 2-Glass shelf 3-Glass shelf 4-Glass shelf 5-Drawer cover 6- ”0°“ drawer 7-Door balcony B: Freezer compartment 8-Upper freezer storage drawer 9-Middle freezer storage drawer 10-Lower freezer storage drawer...
-
Page 13: Control Panel
Control panel Control panel Buttons Power On/Off, used to switch on/off the appliance. Fridge selection/Fine Tuning ON/OFF key, used to switch on/off ”0°“ drawer. I I ndicators ”0°“ drawer Fridge temperature display Before first use ▶ Remove all packaging materials, keep them out of children’s reach and dispose them in an environment friendly way. -
Page 14: Use
Mechanical buttons The buttons on the control panel are mechanical buttons. Switch on /off the appliance The appliance is in operation as soon as it is connected to the power supply. When the refrigerator is first powered on, the indicator “4°” of “B” (Fridge temperature display) and the indicator “... - Page 15 Frequency of door opening Amount of stored foods Installation of the appliance` Adjust the temperature for fridge/freezer compartment 1. Press the key "K2" (Fridge Temperature Selection)to select the Fridge Temperature; 2. Indicator "B" (Fridge temperature display)will be bright alternately as below; 2°C →...
- Page 16 Tips on storing fresh food Storing into the refrigerator compartment Keep your fridge temperature below 5°C. Hot food must be cooled to room temperature before storing in the appliance. Foods stored in the refrigerator should be washed and dried before storing. Food to be stored should be properly sealed to avoid odor or taste alterations.
- Page 17 WARNING! Acid, alkali and salt etc. could erode the internal surface of the freezer. • Do not place the food with these substances (e.g. sea fish) directly on the internal surface. Salt water in the freezer should be cleaned up immediately. •...
-
Page 18: Equipment
Equipment NOTICE Due to different models, your product may not have all of the following features. Please refer to chapter Product Description. Multi-air-flow The refrigerator is equipped with a multi- air-flow system, with which cool air flows are located on every shelf level. This helps to maintain a uniform temperature to ensure that your food is kept fresher for longer. - Page 19 Equipment Fridge storage drawer For using and setting the Fridge storage compartment, please check section USE . Freezer drawer The freezer drawer can be extended straightly and completely. They are mounted on easy roll telescopic rail. So that you can store and remove the freezing good comfortably.
-
Page 20: Energy Saving Tips
Energy saving tips Energy saving tips ▶ Make sure the appliance is properly ventilated (see INSTALLATION). ▶ Do not install the appliance in direct sunlight or in the near of heat sources (e.g. stoves, heaters). ▶ Avoid unnecessarily low temperature in the appliance. The energy consump- tion increases the lower the temperature in the appliance is set. -
Page 21: Care And Cleaning
Care and cleaning WARNING! Disconnect the appliance from the power supply before cleaning. Cleaning Clean the appliance when only little or no food is stored. The appliance should be cleaned every four weeks for good maintenance and to prevent bad stored food odors. WARNING! ▶... - Page 22 Care and cleaning Replacing the LED-lamps WARNING! Do not replace the LED lamp yourself, it must only be replaced by either the manufacturer or the authorised service agent. The lamps adopts LED as its light source, featuring low energy consumption and long service life.
-
Page 23: Troubleshooting
Troubleshooting Many occuring problems could be solved by yourself without specific expertise. In case of a problem please check all shown possibilities and follow below instructions before you contact an after sales service. See CUSTOMER SERVICE. WARNING! ▶ Before maintenance, deactivate the appliance and disconnect the mains plug from the mains socket. - Page 24 Troubleshooting Problem Possible Cause Possible Solution It is not cold • The temperature is set too • Reset the temperature. nside enough i high. • Always cool down goods be- e appliance. • Too warm goods has been fore storing them. stored.
- Page 25 Troubleshooting Problem Possible Cause Possible Solution Strong ice and • The goods were not ade- • Always pack the goods well. frost in the freez- quately packaged . er compartment. • A door/drawer of the appli- • Close the door/drawer. ance is not tightly closed.
- Page 26 Troubleshooting Problem Possible Cause Possible Solution The interior • Mains plug is not connect- • Connect the mains plug. lighting or cooling ed in the mains socket. system does not • The power supply is not • Check the electrical supply to work intact.
-
Page 27: Installation
Environmental conditions The room temperature should always be between 10° C and 43° C ,for this refrig- erator,such as, CNCQ2T620EX、CNCQ2T620EW、CNCQ2T618EX、CNCQ4T618EW 、CNCQ4T618EB; either or the room temperature should always be between 10° C and 38° C ,for this refrigerator, for example, CNCQ2T620DX、CNCQ2T620DW, since it can influence the temperature inside the appliance and its energy consumption. - Page 28 Installation 1. The stability can be checked by alternately bumping on the diagonals. The slightly swaying should be the same in both directions. Otherwise the frame can warp; possible leaking door seals are the result. A low tendency to the rear facilitates the closing of the doors.
- Page 29 Installation Door Reversibility Before connecting the appliance to the power supply, you should check whether the door swing must be changed from right (as delivered) to left, if this is required by the installation location and the usability. WARNING! ▶ The appliance is heavy. You need two persons to carry out the door reversibility. ▶...
- Page 30 Installation ① ② ⑧ ⑦ ③ ④ ⑨ ⑩ ⑩ ⑤ ⑥ Ambient temperatures Extended temperate: this refrigerating appliance is intended to be used at ambient temperatures ranging from 10°C to 32°C Temperate: this refrigerating appliance is intended to be used at ambient tempera- tures ranging from 16°C to 32°C;...
-
Page 31: Technical Data
Product parameters according to regulation (EU)2019/2016 Based on standard test results for 24 hours. Actual energy consumption will depend on how the appliance is used and where it is located CNCQ2T618EW CNCQ2T620EW CNCQ2T620DW Model CNCQ2T618EX CNCQ2T620EX CNCQ2T620DX CNCQ2T618EB Type of refrigerating Refrigerator- Refrigerator- Refrigerator- appliance... - Page 32 + 16°C and +38°C Climate rating T: This appliance is intended for use in an ambient temperature of between + 16°C and +43°C Additional technical data CNCQ2T618EW CNCQ2T620EW CNCQ2T620DW Model CNCQ2T618EX CNCQ2T620EX CNCQ2T620DX CNCQ2T618EB Total volume(L) Voltage/Frequency 220~240V/50Hz 220~240V/50Hz 220~240V/50Hz Rated current(A)
-
Page 33: Customer Service
Customer service We recommend our Haier Customer Service and the use of original spare parts. If you have a problem with your appliance, please first check section TROUBLE- SHOOTING. If you cannot find a solution there, please contact ▶ your local dealer or ▶... - Page 34 Customer service * For other countries please refer to www.haier.com Haier Europe Trading S.r.l Branch UK Westgate House, Westgate, Ealing London, W5 1YY *Duration of the guarantee of the refrigerating appliance: Minimum guarantee is: 2 years for EU Countries, 3 years for Turkey, 1 year for UK, 1 year for Russia, 3 years for Sweden, 2 years for Serbia, 5 years for Norway, 1 year for Morocco, 6 months for Algeria, Tunisia no legal warranty required.
