- Page 1 H24Dynamic USER MANUAL Edition I 2015-08-21 Serial number:...
-
Page 2: Table Of Contents
EdItIon I 2015-08-21 CoNtENtS 1. IntroductIon ........3 2. SAFEtY ruLES ........3-4 3. EquIpmEnt .......... 4-6 3.1 WArrAntY ........5 3.2 ImportAnt ........5 3.3 IdEntIFIcAtIon ......5 - 6 4. StArt - up ......... 7-11 4.1 FILLIng thE oIL ....... -
Page 3: Introduction
Hydroscand Machine AB in order to secure result validity ac- cording to 2006:42/Ec. -
Page 4: Equipment
All maintenance operations except those described in this manual must be performed by an authorized service technician. 3. Equipment the h24dynamic is crimping machine designed for crimping hydraulic hoses and intended for use in service shops. the machine is designed for smaller hose-crimping series and not for large-scale production. -
Page 5: Warranty
Ensure that the machine is undamaged and that all of the described items are present upon arrival or shortly after. Hydroscand Machine is not liable for incorrect or missing parts that are not reported within eight (8) days after delivery. - Page 6 EdItIon I 2015-08-21 Note! It is absolutely prohibited to remove or damage the identification label. Contact an authorized service workshop for new labels if they become damaged and unreadable. Always provide the following information and technical explanation of the machine’s...
-
Page 7: Start Up
4.1 Filling the oil H24Dynamic is delivered with an empty oil tank. Fill the tank to the indicator mark on the oil stick. Use only the oil recommended by Hydroscand Machine AB. Recommended oil: ISO VG46 4.1.1 Machine placement The placement of the machine in relation to the operator’s position must make it possible to observe the result of the operation and maintain safety conditions. - Page 8 EdItIon I 2015-08-21 For example: Crimping 16mm hose requires die nr 16 with the adjustment dial set to zero (0) and lined up with zero (0) in the window. Crimping 21,2mm hose requires die nr 19 with the adjustment dial turned (two clock-wise rotations) at 2.
-
Page 9: Changing Die Set
EdItIon I 2015-08-21 4.5 Changing die set 1. Retract the dies completely by pressing the die return button. 2. Remove inserted die set by using the enclosed QC - tool and pull the locking pin until the die segment releases. -
Page 10: Changing Die Set With The Qc- Tool
EdItIon I 2015-08-21 4.6 Changing die with the QC - tool A die set storage compartment and QC-tool are available as option to the machine. The QC-tool allows you to remove the entire die set in one step. See below illustrations. -
Page 11: Crimping
Use a small brush to lubricate the cone shaped surfaces in the cylinder. Better to lubricate sparingly and more often than seldom and excessively. Without lubrica- tion, the machine looses power and will damage the sliding surfaces. Use only the lubrication recommended by Hydroscand Machine AB: Optimol viscogen 4. Page 11... -
Page 12: Changing The Oil
The oil should be changed once per year. Retract the dies. Empty the tank thru the filling plug. Refill oil, level should be between the marks on the oil stick. Use only the oil recommended by Hydroscand Machine AB: ISo VG46 4 liters... -
Page 13: Trouble Shooting
EdItIon I 2015-08-21 6. trouble shooting Problem Reason Solution machine will not start: 1. no power. check fuses and connection. check motor protection in elec- 2. motor protection tric box. function has been triggered. Machine starts but cylinder will 1. -
Page 14: Technical Data
........140 DESIGNAtIoN PARt NUMBER: crimping force in kn ..........1400 h24dynamic ..........9028-00-65 maximum hose size in inch ........1 ½” die Set ..............h24 maximum travel of dies in mm ......25 mm master die diam. /Length in mm ......84 / 80 master die diam. - Page 15 EdItIon I 2015-08-21 Page 15...
-
