H24AP
H24HP
USER MANUAL
Edition I - 2013-02-20
Serial number: _________________

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H24AP and is the answer not in the manual?

Questions and answers

Summary of Contents for HYDROSCAND H24AP

  • Page 1 H24AP H24HP USER MANUAL Edition I - 2013-02-20 Serial number: _________________...
  • Page 2: Table Of Contents

    EdItIon I 2013-02-20 CoNtENtS 1. IntroductIon ........3 2. SAFEtY ruLES ........3-4 3. EquIpmEnt ...........4-7 3.1 WArrAntY ........5 3.2 ImportAnt ........5 3.3 IdEntIFIcAtIon ......6-7 4. StArt - up ......... 8-12 4.1 mAchInE pLAcEmEnt ......8 4.2 SELEctIng dIE SEt ......
  • Page 3: Introduction

    The use of any spare parts that deviate from this manual’s specifications, any other changes/manipula- tions (however insignificant) made to your machine releases Hydroscand Machine AB from any liability for consequences that arise due to the machine’s performance, level of safety for nearby persons and/ or personal property.
  • Page 4: Equipment

    H24AP/HP is a portable crimping machine powered by compressed air and designed for service vehicles in the fi eld or in a workshop. The machine is designed for smaller hose- crimping series and not for large-scale production.
  • Page 5: Warranty

    Repairs under the warranty are to be made only by Hydroscand Machine AB or an authorized service technician approved by Hydroscand Machine AB. Lost income or extra costs that may arise for any reason are not covered by the warranty.
  • Page 6: Identification

    EdItIon I 2013-02-20 3.3 Identification The machine can be identified by the CE-label with the following information located on its backside: • Manufacturer • Serial number • Manufactured year • Weight • Voltage • Pressure • Force Note! It is absolutely prohibited to remove or damage the identification plates.
  • Page 7 EdItIon I 2013-02-20 H24HP/H24AP pump handle carrying handle Indicator lamp Test button Adjustment dial on/off valve battery compartment tank lid dies crimping head pump regulator on/off carrying handle Indicator lamp Test button Adjustment dial compressed air connection...
  • Page 8: Start-Up

    EdItIon I 2013-02-20 4. Start-up 4.1 Machine placement Place the machine on a stable and flat surface. Set the adjustable machine feet so that they cannot be over-turned or fall from the surface. Connect to compressed air source, max 6 bar.
  • Page 9: Changing Die Set

    EdItIon I 2013-02-20 H24 DIE SET SIZING CHART 0 turn 1 turn 2 turns 3 turns 4 turns 5 turns 6 turns 7 turns 20-10 20-12 20-14 USE NEXT SIZE! 20-16 20-19 20-23 20-27 20-31 20-36 20-41...
  • Page 10 EdItIon I 2013-02-20 Locking pin qc - tool die size marking die set pin qc - tool hole for qc tool Page 10...
  • Page 11: Changing Die Set With The Qc- Tool

    EdItIon I 2013-02-20 4.5 Changing die sets with the QC-tool The QC-tool allows you to change entire die sets in just one step. Fully contract the dies together to zero (0). Insert the qc-tool in the holes for the qc change tool in the contracted dies and then completely retract (return) the dies.
  • Page 12: Crimping

    2. H24HP: Turn the on/off valve dial clockwise until the dial stops. Pump the hand pump until the indicator lamp lights. 3. H24AP: Turn the on/off valve dial counter-clockwise to contract the dials and release the hose application. 4. Check the crimped hose and make adjustments if necessary.
  • Page 13: Changing The Oil

    5.2 Changing the oil The oil should be changed once per year. Retract the dies. H24AP: Fill oil to the line on the oil-level glass on the front of the pump. H24HP: Fill to the line on the oil-stick Use only the oil recommended by Hydroscand Machine AB: ISo VG32 H24HP: Oil change, the following must be done: 1.
  • Page 14: Trouble Shooting

    EdItIon I 2013-02-20 6. trouble shooting Problem Reason Solution Low crimping force: 1. Too-little lubrication Lubricate 2. Low oil level Fill oil 3. on/off valve not tightened tighten enough 4. Leakage tighten pipes 5. poor oil quality change oil 6.
  • Page 15: Technical Data

    DESIGNAtIoN PARt NUMBER: DESIGNAtIoN PARt NUMBER: h24hp............9028-00-73 h24Ap ............9028-00-74 tECHNICAL DAtA H24HP: tECHNICAL DAtA H24AP: crimping range in mm ........10 - 61 mm crimping range in mm ........10 - 61 mm crimping range in inch ........0,39 - 2,40 crimping range in inch ........0,39 - 2,40...
  • Page 16: Technical Draws

    EdItIon I 2013-02-20 Page 16...
  • Page 17 EdItIon I 2013-02-20 Page 17...
