HYDROSCAND AutoCal H24D User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
H24D AutoCal
H32D AutoCal
UseR MAnUAL
edition I - 2013-02-27
serial number:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AutoCal H24D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HYDROSCAND AutoCal H24D

Summary of Contents for HYDROSCAND AutoCal H24D

  • Page 1 H24D AutoCal H32D AutoCal UseR MAnUAL edition I - 2013-02-27 serial number:...
  • Page 2 High quality and reliable performance in a demanding environment was the primary focus. Downtime and unnecessary service is always more expensive than the small extra cost of a quality product. That was the philosophy and still is for what became Hydroscand Machine AB in Säter, 20 years ago.

  • Page 3: Table Of Contents

    Contents 1. INtroductIoN ..........3 2. SAFETY RULES ..........3-4 3. EqUipMEnT ..........4-9 3.1 WARRAnTY ..........5 3.2 iMpORTAnT ........5 - 6 3.3 iDEnTiFiCATiOn ........ 6 - 7 3.4 USER inTERFACE iDEnTiFiCATiOn ..8 - 9 4. START - Up ..........10-14 4.1 MACHinE pLACEMEnT......10 4.2 ELECTRiCAL inSTALLATiOn ......10 4.3 FiLLinG THE OiL ........10...

  • Page 4: Introduction

    The use of any spare parts that deviate from this manual’s speci- fications, any other changes/manipulations (however insignificant) made to your machine releases Hydroscand Machine AB from any liability for consequences that arise due to the machine’s performance, level of safety for nearby persons and/or personal property.

  • Page 5: Equipment

    H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27 Disassembling or side-stepping safety devices or rules is extremely hazar- dous and absolutely prohibited. Refusal to follow these requirements puts others at severe risk of injury! Always dispose of operation waste according to current local laws and regula- tions.

  • Page 6: Warranty

    3/16”-1 ½”, H32D AutoCal for dimensions 3/16”-2”. Any other use of this machine is conside- red improper and Hydroscand Machine AB is not liable for injury or damage to persons, pro- perty or the machine. The machine shall only be used for crimping hydraulic hose according to specifi cation.

  • Page 7: Identification

    H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27 3.3 Identifi cation The machine can be identifi ed by the CE-label with the following information located on its backside: • Manufacturer • Serial number • Manufactured year • Weight • voltage • pressure • Force note! It is absolutely prohibited to remove or da- mage the identifi cation plates.

  • Page 8: User Interface Identification

    H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27 H24D/H32D AutoCal Crimping head Dies Filter User interface tank lid electrical unit Power switch oil plug Contact for foot pedal/back stop Lifting ring...
  • Page 9 4. Display window. indicates selected die set and crimping counter. 5. Service lamp. indicates when it is time for service. Can only be turned off by an authorized Hydroscand service technician. 6. Shift. press the shift button to toggle between the minus (-) button functions.
  • Page 10 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27 13. Crimping diameter plus (+). increases crimping opening diameter in 1mm/0.01 inch increments. Holding down the button increases the increment with 10mm/0.1 inch. 14. Crimping diameter minus (-). Decreases crimping opening diameter in 1 mm/0.01 inch increments.

  • Page 11: Start-Up

    4.3 Filling the oil H24D/H32D AutoCal is delivered with an empty 24 liter oil tank. Fill the tank to the indi- cator mark on the oil stick. Use only the oil recommended by Hydroscand Machine AB. Recommended oil: iSO vG46 4.4 selecting dies Determine the crimping dimensions for the current operation and select the die set with the correct interval that corresponds to the crimping measurement.

  • Page 12: Changing Die Set

    H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27 H24 DIes H32 DIes Die Set Crimping area Die Set Crimping area 20-10 10-12 mm 32-10 10-12 mm 20-12 12-14 mm 32-12 12-14 mm 20-14 14-16 mm 32-14 14-16 mm 20-16 16-19 mm 32-16 16-19 mm 20-19...

  • Page 13: Qc- Tool

    H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27 Locking pin die tool Die size marking Die set pin qC - tool Hole for qC Tool 4.7 Changing die sets with the QC-tool The qC-tool allows you to change entire die sets in just one step. Use the plus/minus buttons for die set selection and select the die sitting in the machine.
  • Page 14 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27 insert the qC-tool in the desired die set in the die set holder and turn clock-wise until it stops. Remove the die set from the die set holder and mount it in the machine.

  • Page 15: Crimping

    It is better to lubricate sparingly and more often than seldom and excessively. Without lubrication, the machine looses power and can damage the gliding surfaces. Use only the lubrication recommended by Hydroscand Machine AB: optimol viscogen 4...

  • Page 16: Changing The Oil And Filter

    Change the filter every time the oil is changed. Fill the new oil to the mark on the measurement stick (see photo 1). Loosen the filter lid screws (see photo 2), lift the filter (see photo 3) and change. Use only the oil recommended by Hydroscand Machine AB: Iso VG46 Photo 1 Photo 2 Photo 3 5.3 Calibration...

  • Page 17: Easy Calibration

    H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27 if there is a need to calibrate the machine without the simple calibration function, press the shift button and push the opening diameter minus (-) button twice. The indicator lamp will now be red. if simple calibration is activated and you believe that calibration is unnecessary, press the shift and opening diameter minus (-) button.

  • Page 18: Trouble Shooting

    Change direction of motor rota- not move: rotation. tion. 2. Low oil level. Add oil. 3. poor oil quality Service is required, contact Hydroscand Machine AB. Low crimping force: 1. insufficient lubrication. Lubricate. 2. Low oil level. Add oil. 3. poor oil quality.

  • Page 19: Technical Data

    DIMensIons H24D AutoCal: teCHnICAL DAtA H24D AutoCal: Depth/ Width/ Height ......400x800x530 mm Capacity ..........3/16” – 1 1/2” Crimping range .......... 10 - 61 mm Weight .......... 125 kg (without oil) Max opening ............ +25 mm Crimping force ..........1370 kN DIMensIons H32D AutoCal: pump fl ow .............9,4 l/min Depth/ Width/ Height ......

  • Page 20: Technical Draws

    H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 21 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 22 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 23 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 24 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 25 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 26 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 27 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 28 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 29 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...

  • Page 30: Electrical Draw 400V 3-Phase

    H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 31 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 32 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 33 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 34 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 35 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 36 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 37 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 38 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 39 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...
  • Page 40 H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...

  • Page 41: H24D Autocal Spare Parts

    H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...

  • Page 42: H24 Crimping Head

    H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...

  • Page 43: H32D Autocal Spare Parts

    H24/H32D AutoCal USER MAnUAL EDiTiOn i 2013-02-27...

  • Page 44: H32 Crimping Head

    1, SE-783 90 Säter, Sweden phone: +46-(0)225-573 30 Fax: +46-(0)225-501 08 info@hydroscand-machine.se www.hydroscand-machine.se...

This manual is also suitable for:

Autocal h32d
