Capcom 19XX THE WAR AGAINST DESTINY Operator's Manual page 10

(g/^SKkTcO.N-OPJNC.
19XX
:
THE
WAR
AGAINST DESTINY™
22.
An
optional
Test/Volume
bracket (see
Figure
9)
is
included
in this
kit.
Your
cabinet
may
already contain
this
bracket.
If
you decide
to install,
the bracket
should be mounted
inside
the coin
door and on top of
the
cash
box
for
easy
access.
NOTE:
The
A-cartridge
also
contains the
same
Test
and
Volume
functions
found on
the
test
bracket.
GAME
CARTRIDGE
INSTALLATION
23.
Install
the four
(4)
mounting
brackets
to
the
underside of
the
"A"
cartridge as
shown
in
Figure
1 1
V300500
Figure
9:
Test Bracket Figure
1 1
:
Mounting
Bracket
Installation
Wiring
of the Test
Bracket
requires connections
to
both the
main
JAMMA
harness as well as the
auxiliary cable harness
(refer to
Figures
6,8,
&,
10).
LEAD WIRE
COLOR
SWITCH
FUNCTION
CONNECTS
TO
YELLOW VOLUME-UP
AUX.
CABLE
'29' (GRAY/
YELLOW)
GREEN
COMMON
AUX. CABLE
'31
'(BLACK/
WHITE)
BLACK VOLUME-
DOWN
AUX. CABLE
'30'(PINK/
YELLOW)
GREEN
COMMON
AUX.
CABLE
'31
'(BLACK/
WHITE)
BROWN
TEST
JAMMA
'15'
BLACK GROUND JAMMA
'A' or
'B'
or
'e'
or
'f or
'1'
or
'2'
or
'27'
or
'28'
Figure
10:
Test
Bracket Wiring Chart
24.
Using
the supplied
wood
screws, fasten
the
game
cartridge case to the control panel
shelf,
as
shown
in
Figure
12.
Figure
12:
Case Mounting
25.
Connect
the
JAMMA
harness connector
and
the auxiliary
cable connector
to the
"A'
cartridge. If
your
cabinet
is
equipped with
Q-
SOUND,
also attach the
audio
cables.
Proprietary
and
confidential information, not to
be
disclosed
or copied without
the express permission of
CAPCOM®
COIN-OP, INC.
I
