MELAG Vacuklav 24 B+ Instructions For Replacing

Instructions for replacing the vacuum pump
Articles in the scope of delivery
Vacuum pump (art. no. ME57805)
Vacuum pump complete
Conversion set (art. no. ME22177) for Vacuklav 24 B+, 24-B
Diverse hoses and fittings
Cable tie
Shrink-on hose
SV vacuum adjustable
QSS T-piece
Conversion set (art. no. ME22178) for Vacuklav 24 BL+, 24-B/L
Diverse hoses and fittings
Cable tie
Shrink-on hose
SV vacuum adjustable
QSS T-piece
Conversion set (art. no. ME22176) for Vacuklav 30 B+, 30-B
Diverse hoses and fittings
Cable tie
Shrink-on hose
SV vacuum adjustable
QSS T-piece
Air regulator
Tools required: open-end wrench (AF 10, 12, 14, 17), Allen key (5 mm), Torx key (TX10, TX20), small Phillips
screwdriver (PH1), side cutter, heat gun
WARNING
Danger of electric shock from the live components
n
Switch off the device power switch and disconnect the power cable.
n Determine absence of voltage on all poles.
CAUTION
Danger of injury
Should it be necessary to remove the casing in order to perform work on the device, take care
with sharp edges.
n
Comply with the working safety regulations and wear suitable protective gloves.

1 Removing the old vacuum pump

Preparations:
1. Close the water inflow tap.
2. Empty the vacuum pump: Either start a vacuum test or working in the Diagnosis menu, actuate output
ACOUT 3 for 5 s.
3. Remove the device cover (depending on the version, TX20 or Phillips screwdriver PH1).
AS_013-19_common_EN
Vacuklav
Rev. 1 - 22/3633
Replacing the vacuum pump
®
24 B+, 24 BL+, 30 B+/24-B, 24-B/L, 30-B
Qty.
1
Qty.
8
3
1
1
1
Qty.
8
3
1
1
1
Qty.
8
3
1
1
1
1
1/7
