48 Appendix B: Technical information
PIN SIGNAL
1 CAMCTRL1, OUTPUT, TTL
2 CC4_B, OUTPUT, +
3 CC2_B, OUTPUT, -
4 CC1_B, OUTPUT, -
5 HSYNC_B, OUTPUT, -
6 HSYNC_B, OUTPUT, +
7 CLOCK_B, OUTPUT, +
8 CC3_A, OUTPUT, +
9 CC2_A, OUTPUT, +
10 CC2_A, OUTPUT, -
11 CLOCK_A, OUTPUT, +
12 CC1_A, OUTPUT, +
13 CC1, OUTPUT, TTL
14 GROUND
15 VSYNC, OUTPUT, TTL
16 CAMCTRL2, OUTPUT, TTL
17 CC4_B, OUTPUT, -
18 CC3_B, OUTPUT, -
19 CC2_B, OUTPUT, +
20 CC1_B, OUTPUT, +
21 VSYNC_B, OUTPUT, -
22 CLOCK_B, OUTPUT, -
For customers planning to build their own cable, parts can be purchased from:
Manufacturer:
Connector:
PIN SIGNAL
23 USER0, INPUT, -
24 CC3_A, OUTPUT, -
25 VSYNC_A, OUTPUT, -
26 HSYNC_A, OUTPUT, -
27 CLOCK_A, OUTPUT, -
28 CC1_A, OUTPUT, -
29 GROUND
30 GROUND
31 USER1, INPUT, -
32 USER1, INPUT, +
33 CC3_B, OUTPUT, +
34 GROUND
35 CAMCTRL0, OUTPUT, TTL
36 VSYNC_B, OUTPUT, +
37 USER0, INPUT, +
38 CC4_A, OUTPUT, -
39 CC4_A, OUTPUT, +
40 VSYNC_A, OUTPUT, +
41 HSYNC_A, OUTPUT, +
42 GROUND
43 CC2, OUTPUT, TTL
44 HSYNC, OUTPUT, TTL
NorComp Interconnect Devices
HDT44P
