INSTALLATION INSTRUCTIONS
FLOOR STAND MAXI
OMB srl │ Via Risorgimento, 25 │ 38070 STENICO (TN) │ ITALY
Tel. +39 0465 771036 │ omb@ombitaly.it │www.ombitaly.it
CAPACITY
Max Screen Size: up to 55" to 100"
Max weight capacity: 100 Kg (lbs 220)
Min VESA 200x200
Max VESA 1200x600
INDEX
Page 2 - Safety instruction
Page 3 - 4 - Assembly
REL 2023 – document code 04784
1
Advertisement
Table of Contents
Related Manuals for OMB MAXI
Summary of Contents for OMB MAXI
- Page 1 Max VESA 1200x600 INDEX Page 2 - Safety instruction Page 3 - 4 - Assembly REL 2023 – document code 04784 OMB srl │ Via Risorgimento, 25 │ 38070 STENICO (TN) │ ITALY Tel. +39 0465 771036 │ omb@ombitaly.it │www.ombitaly.it...
- Page 2 OMB o ad eventuale combinazione di prodotti OMB non idonei a quella installazione. 1 Prima dell'uso controllare che tutti i dadi e bulloni siano fissati saldamente. 2. Utilizzare il supporto solamente su superfici piane. 3. Quando si sposta il supporto si consiglia di togliere il monitor dal support stesso al fine di evitare eventuali danneggiamenti.
- Page 3 ASSEMBLY PROCESS STEP 1 STEP 2 Fix the FREESTANDING BASE (A) to Insert the two monitor support bars the 2 poles (B) using 4 screws M8x20 (D) inside the two poles (B) and secure (C). them with screws M6x20. It is possible to choose one of the three possible heights where to position the screen.
- Page 4 ASSEMBLY PROCESS STEP 4 Installation of OPTIONAL shelves for web-cam (product code 07076) and front shelf (product code 07164). Front Shelf (H): insert and fit the shelf. Web-cam shelf (I): bring the shelf closer to the upper bar and fix it at the desired height with the screws M6x12 (L) STEP 5 Hook the screen (E) on the...
