PRE-ASSEMBLY:
Please read all instructions before beginning assembly.
For your safety and ease, assembly by two adults is recommended.
Remove all parts and hardware from box and lay out on a carpeted or scratch-free work surface, as this will
avoid damaging any parts during assembly. The shipping box provides an ideal work surface.
Do not dispose of any contents until assembly is completed to avoid accidentally discarding small parts or
hardware.
Use the parts and hardware lists to identify and separate each of the pieces included.
Note: Do not fully tighten all bolts until all parts are in place. Failure to follow these instructions may cause
the bolts to misalign during assembly.
The use of power tools for assembly is not recommended. Power tools can damage hardware or split wood.
HARDWARE INCLUDED:
(E) Allen Key – 1pc
(H) Spring Washer – 16pcs
ASSEMBLY INSTRUCTIONS:
1.
Place Bottom Panel (D) upside down on a soft, scratch free surface. Attach (4) Caster (I) to pre-drilled holes
near corners of the Bottom Panel (D) and secure each caster with (4) Wood Screws using Philips Head Screw
Driver.
Date: 29-May-2012
pottery barn kids
Carolina Activity Cart S/2
B
D
C
(F) Bolt ¼" x 28mm – 16pcs
(I) Caster – 8pcs
D
Page 1/2
PARTS INCLUDED:
(A) Chalk Panel – 2x
C
(B) Short Side Panel – 2x
(C) Long Side Panel – 4x
(D) Bottom Panel – 2x
TOOLS REQUIRED:
A
Philips Head Screw
Driver
(not included)
(G) Flat Washer – 16pcs
(J) Wood Screw – 32pcs
I
J

Advertisement

loading
Need help?

Need help?

Do you have a question about the Carolina Activity Cart S/2 and is the answer not in the manual?

Questions and answers

Summary of Contents for pottery barn kids Carolina Activity Cart S/2

  • Page 1 Carolina Activity Cart S/2 PRE-ASSEMBLY:  Please read all instructions before beginning assembly.  For your safety and ease, assembly by two adults is recommended.  Remove all parts and hardware from box and lay out on a carpeted or scratch-free work surface, as this will avoid damaging any parts during assembly.
  • Page 2 Slide a Flat Washer (G) and a Spring Washer (H) onto each Bolt (F). Attach a Long Side Panel (C) to Short Side Panel (B) by aligning wooden dowels to pre-drilled holes located on the Short Side Panel (B) and insert (2) Bolts with washers to secure the Long Side Panel to the Short Side Panel.
