- Page 1 B210 Expansion Battery User Manual V 2 . 0 Please read this manual carefully before use and keep it for future reference.
- Page 2 Warning 1. Charge the unit before first use. 2. Do not use solar panels with open circuit voltage higher than 60V. Solar input voltage range for the unit is 11V-60VDC. 3. Charge the unit immediately when the SoC drops below 5%. If the SoC drops to 0, power off the unit and charge it for at least 30 minutes before restarting.
- Page 3 Thank You! Thank you for making BLUETTI a part of your family. From the very beginning, BLUETTI has tried to stay true to a sustainable future through green energy storage solutions while delivering an exceptional eco-friendly experience for our homes and our world.
-
Page 4: Table Of Contents
Contents Safety Instructions Packing List Product Overview Power ON / OFF Charging Discharging AC240 + B210 Expansion Connection BLUETTI App Specifications Troubleshooting... -
Page 5: Safety Instructions
The safety instructions provided herein are for illustrative purposes that include but are not limited to those listed in this manual. Actual operation shall comply with all applicable safety standards. If you have any questions, feel free to contact BLUETTI support or your local BLUETTI dealers. - Page 6 • Use of an attachment not recommended or sold by the manufacturer may result in a risk of fire, electric shock, or injury to persons. • To reduce the risk of damage to the electric plug and cord, pull the plug rather than the cord when disconnecting the product.
- Page 7 • Do not stack anything on top of the product while in storage or while in use. Do not move the product while operating as vibrations and sudden impacts may lead to poor connections to the hardware inside. • In case of fire, use only a dry powder fire extinguisher appropriate for the product. •...
- Page 8 Please refer to the information on the exterior bottom enclosure for electrical and safety information before installing or operating the apparatus. SAVE THESE INSTRUCTIONS BLUETTI shall not be liable for any equipment damage caused by the violation of the above instructions. JUST POWER ON...
-
Page 9: Packing List
V 2 . 0 Please read this manual carefully before use and keep it for future reference. Product Documentation Warranty Card Optional Accessories (Available on official BLUETTI website) Item Picture USB-C to USB-C Cable (output) (100W Max. Compatible with USB-C devices.) - Page 10 Lead-acid Battery Charging Cable （Charge the B210 via a lead-acid battery.） Car Charging Cable （Charge B210 via the car's cigarette lighter port.） PV Voltage Regulator （Convert high solar panel voltage to a suitable level for battery charging.） 12V DC Power Cable （Charge 12V devices with DC5521 ports,...
-
Page 11: Product Overview
10,136Wh by connecting up to four B210 batteries in parallel. The B210 can also work independently as a power source for specific DC appliances. With USB-A, USB-C, and 12V cigarette lighter outputs, the B210 is compatible with a wide range of devices, from laptops and smartphones to car fridges and camping heaters. -
Page 12: Power On / Off
To power on the B210, press and hold the Power Button for about 2 seconds, the SoC indicator will light up. The B210 has a built-in feature that allows it to power on and starts charging as soon as it detects input from a connected power source (e.g., wall outlet, solar panel, etc.). - Page 13 Power: 500W Max. Notice： • If you unplug the solar charging cable from the B210 and you're not using any DC outputs, the B210 will automatically shut down after about 4 hours. For solar panel(s) with an open circuit voltage between 60V and 145V, you can still use them to charge the B210.
- Page 14 5.4 AC240 Power Station To charge both the AC240 and B210 simultaneously, connect the two units using the battery expansion cable provided. Then, plug the AC240 into a standard wall outlet.
-
Page 15: Discharging
6. Discharging The B210 is equipped with three DC outlets, including a USB-C port, a USB-A port, and a cigarette lighter port, which allow you to charge a variety of devices. Port Picture Specifications Compatible Loads 12V DC appliances up to 120W power. - Page 16 AC240 + 1 × B210 If you want to add more B210 units, please set up the system as shown. AC240 + 4 × B210 Attention： The AC240 connects to the upper battery expansion port of B210. JUST POWER ON...
-
Page 17: Bluetti App
8. BLUETTI APP Scan the QR code below or search "BLUETTI" in the App Store or Google Play to download the BLUETTI App. Attention： Only when connected with the AC240 can you use the app to view the operating status of the B210 and upgrade its firmware over-the-air (OTA). -
Page 18: Specifications
9. Specifications Model B210 Battery Capacity 2,150Wh (42Ah) Cell Type Lithium Iron Phosphate (LiFePO , LFP) DC Input 500W Max. Weight 27.9kg / 61.5lbs Dimensions (L × W × H) 416.6mm × 282.4mm × 269.5mm / 16.4in × 11.1in × 10.6in Charging Temperature 0°C to 40°C / 32°F to 104°F... -
Page 19: Troubleshooting
10. Troubleshooting In case of a B210 failure, the Power Button or DC Power Button light will flash. If the latter flashes, press and hold it for about 3 seconds, and the SoC indicator will start flashing. Please refer to the table below for helpful guidance. -
Page 20: Faq
If I forget to turn off the B210, will it automatically power off by itself? If the B210 is not connected to any power sources or electrical appliances, it'll automatically turn off after 4 hours of inactivity. - Page 21 For more information, please visit: @ BLUETTI Support @ BLUETTI Official @ bluetti.inc @bluetti_official @ bluetti_inc sale-au@bluettipower.com Customer Service(AU) Email: sale-au@bluettipower.com Address: Unit 15, 25 Gibbes Street Chatswood NSW 2067 Customer Service(ZA) Email: sale-za@bluettipower.com SHENZHEN POWEROAK NEWENER CO., LTD. F19, BLD No.1, Kaidaer, Tongsha Rd No.168,...
- Page 22 P/N: 17.0303.0662-01A1...
- Page 24 Cer t ific ate Inspector: Q C :...
