- Page 1 Portable Power Bank User Manual Please read this manual carefully before use and keep it for future reference.
- Page 3 Thank You! Thank you for making BLUETTI a part of your family. From the very beginning, BLUETTI has tried to stay true to a sustainable future through green energy storage solutions for both indoor and outdoor use while delivering an exceptional eco-friendly experience for our homes and our world.
- Page 4 The contents of this manual are subject to change without notice. Please get the latest version from: https://www.bluettipower.com/pages/user-guides If you have any questions or concerns about this manual, please contact BLUETTI support for further assistance. SHENZHEN POWEROAK NEWENER CO., LTD.
-
Page 5: Table Of Contents
Contents Safety Instructions General Safety Storage and Usage What’s In The Box Product Overview LCD Screen Operations Powering On/Off Charging Discharging Set ECO Mode Specifications Troubleshooting Abbreviations... -
Page 6: Safety Instructions
• Unauthorized disassembly, alteration of the equipment or modification of the software code is not allowed. BLUETTI shall not be liable for the following circumstances: • Equipment damage caused by force majeure, such as earthquake, fire, storm, flood, mudslide, etc. - Page 7 Do not move the unit during operation as the vibrations and shocks associated with movement may cause damage to the internal hardware. • In case of malfunction, turn off the unit immediately and contact BLUETTI support or your local BLUETTI dealers if this manual cannot adequately explain the malfunction to you.
-
Page 8: Storage And Usage
2)Charging within 48 hours. 3)Battery should be kept at an ambient temperature of 5 C to 35 C for 24 hours before charging. BLUETTI shall not be liable for any equipment damage caused by the violation of above instructions. JUST POWER ON... -
Page 9: What's In The Box
2. What’s In The Box Standard Packaging Item Picture Qty. Portable Power Bank DC 24V/4A Power Cable DC 24V/4A Power Cable DC 24V/4A Power Cable DC 12V/5A Power Cable (Ⅰ) DC 12V/5A Power Cable (Ⅱ) Ⅲ DC 12V/5A Power Cable ( DC 16V/4A Power Cable JUST POWER ON... - Page 10 Standard Packaging Item Picture Qty. DC Power Cable (Cigaratte Lighter to DC 12.5V~26V/8A) Connector for HP (Connecting with together to power AirSense 10) AC Adaptor (Wall Outlet to DC 12.5V~26V/8A) Storage Bag Portable Power Station User Manual User Manual Please read this manual carefully before use and keep it for future reference. JUST POWER ON...
-
Page 11: Product Overview
3. Product Overview X60 is a DC portable power bank with an internal integrated large capacity battery pack. With external adapter charging and car charging, LCD screen, USB-A, USB-C and 12V/16V/24V DC output, it is suitable for CPAP power supply and mobile devices charging. -
Page 12: Lcd Screen
4. LCD Screen The LCD screen is lit when X60 is powered on. If X60 is powered off, press and hold the power button for 3 seconds to turn it on. The display is shown in the following figure. Table 4-1 Description of LCD Screen... -
Page 13: Operations
X60 supports 2 ways of charging: AC adaptor and car charging. 5.2.1 AC adaptor charging Connect one end of the adaptor to the charging port of X60, and the other end to a wall outlet. The charging will automatically stop when the battery is fully charged. - Page 14 The engine of the vehicle is running. Connect one end of the cable to the charging port of X60, and the other end to a cigarette lighter port of the car. The charging will automatically stop when the battery is fully charged.
-
Page 15: Discharging
5.3 Discharging X60 is equipped with five types of DC output ports: USB-C, USB-A, DC 12V/5A, DC 16V/4A, and DC 24V/4A. When X60 is on, use the matching power cable to connect your device and X60. Note: Only one of the three ports (DC 12V/5A, DC 16V/4A and DC 24V/4A) can be used at a time. -
Page 16: Specifications
6. Specifications Item Specification General Battery capacity 614Wh Battery cell LiFePO Net weight About 7kg Dimensions 305mm×252mm×128mm Charging temperature C～40 Discharging temperature C～+40 Storage temperature C～+35 Working humidity 5%～95% DC Output DC4017 12V/5A DC output ports DC6530 16V/4A DC5525 24V/4A USB-A 5V/3A 5/9/12/15/20V 3A;... -
Page 17: Troubleshooting
Refer to Table 10-1 for details of the fault codes. Table 10-1 Fault Codes Defination Fault Code Defination Recommended Solutions Unable to charge Restart X60 Unable to discharge (DC ports) Restart X60 Unable to charge/discharge Restart X60 Unable to charge/discharge... - Page 18 For more information, please visit: Web: https://www.bluettipower.com @ BLUETTI Support @ BLUETTI Official @ bluetti_inc @bluetti.inc @bluetti_official service@ bluettipower.com SHENZHEN POWEROAK NEWENER CO., LTD. Add: F19, BLD No.1, Kaidaer, Tongsha Rd No.168, Xili Street, Nanshan, Shenzhen, China Customer Service Tel: 800-200-2980 (Monday to Sunday 9:00-17:00) Email: sale@bluettipower.com (Pre-sales),...
- Page 19 Warranty Card Manufacture Date Sale Date File No. Manufacturer Warranty Instructions 1. 12-months warranty 2. After-Sale-Service mailbox：service@ bluettipower.com 3. Following situations will go against the warranty terms: A. Any problems, malfunction or damages due to incorrect using methods or caused by unauthorized disassembly or repair. B.
- Page 20 Cer ti fi cate Inspector: Q C : P/N:17.0303.0589-04A4...
