Summary of Contents for Generalscan GS P10
- Page 1 GS P10 Handheld Scanner QUICK START GUIDE...
- Page 2 GENERALSCAN QUICK START GUIDE This guide introduces the assembly method and the basic configura- tions barcodes of the handheld scanner GS P10, you can adjust the settings and modes of your device according to your wishes and get it work easily. If any further questions, please contact: support@generalscan.cloud...
- Page 3 FEATURES Scan Window Beeper Trigger Cable Hole Cable Latch...
-
Page 4: Mode Button
Illumination Mode LED Mode Button 滚滚长江东逝水 Lanyard Hole State LED Lanyard Hole SWITCH ILLUMINATION MODE We provide 3 illumination modes-white point light, red low angle ring light, red /blue dome light. Switch the mode by pressing the Mode button, and the corresponding mode LED will light up. -
Page 5: Cable Connection
CABLE CONNECTION Step1. Fully insert the cable to make the connector is flush with the scanner surface. Step2. Loosen the metal lock plate by using a screw driver. Step3. Slide lock plate to fully locked position. Step4. Tighten the screw by using a driver. -
Page 6: Power On And Power Off
POWER ON AND POWER OFF Automatically power on when connected to the power supply, automatically power off when disconnected from the power supply. DATA OUTPUT MODE P10-XX-USB refer to the picture as below USB Cable PN:886783040001 1. USB HID Mode (Default) Step1. - Page 7 2. USB COM Mode Step1. Scan the barcode below, switch to USB COM mode. USB COM Mode Step2. Open a serial port application, when you scan a barcode the data will be output in the serial port application. PARAMETERS Baudrate 115200 Data Bits 8 Flow Control N Stop Bits 1...
-
Page 8: Basic Settings
BASIC SETTINGS Default Factory Settings Carriage Return Suff x Line Feed Carriage Return & Line Feed Disable Note： Download all configration barcodes from www.generalscan.cloud... -
Page 9: Led And Beeper Indications
Illumination mode LED Two beeps stays on SOFTWARE DOWNLOAD Please download the PC configuration software EasyScan for other configurations of the scanner from our website: www.generalscan.cloud Q & A Problem Possible Causes Possible Solution No power to scanner Scanner not... - Page 10 Service Information If you have any question of your GENERALSCAN product, please visit our service page for assistance. www.generalscan.cloud/services QUICK START GUIDE Email: Support@generalscan.cloud ©2023 GENERALSCAN All rights reserved Version 1.0 8 8 6 7 8 3 0 2 1 0 0 1...
