Generalscan GS F50 Quick Start Manual

Fixed-mount scanner
Hide thumbs

Advertisement

Quick Links

Download this manual
GS F50
Fixed-Mount Scanner
QUICK START GUIDE
EN

Advertisement

loading

Related Manuals for Generalscan GS F50

Summary of Contents for Generalscan GS F50

  • Page 1 GS F50 Fixed-Mount Scanner QUICK START GUIDE...
  • Page 2 GENERALSCAN QUICK START GUIDE This guide introduces the assembly method and the basic parameters of the fixedmounted scanner GS F50, you can adjust the settings and modes of your device accord-ing to your wishes and get it work easily. lf any further questions, please contact us via email support@generalscan.cloud.
  • Page 3 FEATURES Scanner Interface A Tirgger Button Status LED...
  • Page 4 DIMENSIONS 40mm Screw M2.5 33mm...
  • Page 5 CABLES Control Box Scanner Interface B USB Interface USB Cable for F50-RL15-USB 886783029001...
  • Page 6 CABLES Control Box Scanner Interface B RS232 Interface RS232 Cable for F50-RL15-RS232 886783030001...
  • Page 7 CABLES Control Box Scanner Interface B Ethernet Interface Ethernet Cable for F50-RL15-Ethernet 886783031001...

  • Page 8: How To Connect

    HOW TO CONNECT 1. Connect the Scanner Interface A to Scanner Interface B. 2. Connect "Host" with data collection terminal to transfer data. a. The "Host" of F50-RL15-USB is USB interface.
  • Page 9 HOW TO CONNECT b. The "Host" of F50-RL15-RS232 is RS232 interface. c. The "Host" of F50-RL15-Ethernet is RJ45 interface.
  • Page 10 HOW TO CONNECT 3. Connect Pin VCC and Pin GND to external DC power supply of 5-30V. When host using the USB interface(Current>500mA), it can be powered by USB. 4. When using sensor switch to trigger, connect switch to Pin IN on control box to trigger.
  • Page 11 HOW TO CONNECT b. Connect to NPN Photoelectric Switch. NPN Photoelectric Switch c. Connect to Relay Photoelectric Switch. Relay Photoelectric Switch...
  • Page 12 HOW TO CONNECT 5. Connect external device with Pin OUT on control box to get output feedback signal or control signal. 6. Installation Example. Data collection terminal External device...
  • Page 13 BRACKET ASSEMBLE ① Fixed the scanner to the bracket. ② Scanner angle can be adjusted freely. ③ Scanner can move vertically up and down. ② M2.5 ① ③...

  • Page 14: Mounting Angle

    MOUNTING ANGLE Three commonly used mounting angles recommended: vertical mounting, a slight angle of 15° mounting, and an inclination angle of 45° mounting. Actually mounting angles can be chosen freely according to different reflection of differ- ent application materials to ensure the best reader performance. vertical mounting 15°...

  • Page 15: Decode Range

    INDICATIONS Indication Beeper Power on Status LED flashes red once Prompt sound Decode successfully Status LED flashes blue once One beep DECODE RANGE 3.28mil Code 128 3.8in. - 4.7in./97.0mm - 119.0mm 4.93mil Code 128 3.3in. - 7.0in./83.0mm - 179.0mm 8.22mil Code 128 2.2in.

  • Page 16: Software Download

    SOFTWARE DOWNLOAD Please download EasyScan to configurate at PC end from our website www.generalscan.cloud Service Information If you have a question of your GENERALSCAN barcode scanner, please visit our service page for assistance. www.generalscan.cloud/services QUICK START GUIDE Email: Support@generalscan.cloud 2023 GENERALSCAN All rights reserved 886783020001 Version 1.0...
