- Page 1 GS P11 Wireless Handheld Scanner QUICK START GUIDE...
-
Page 2: Battery Safety
Handheld Scanner QUICK START GUIDE ① GS P11 x 1; ② Cradle x 1; ③ Quick Start Guide x 1; ④ Adaptor x 1; ⑤ USB Cable x 1 or RS232 Cable x 1 Note：Dierent models have dierent cables in the package. - Page 3 FEATURES Scan Window Beeper Trigger Battery Latch Charging contacts...
-
Page 4: Mode Button
FEATURES Bluetooth LED Battery LED Illumination Mode LED Mode Button 滚滚长江东逝水 Lanyard Hole State LED Lanyard Hole SWITCH ILLUMINATION MODE We provide 3 illumination modes-white point light, red low angle ring light, red /blue dome light. Switch the mode by pressing the Mode button, and the correspond- ing mode LED will light up. - Page 5 FEATURES Cradle Bluetooth address barcode Power LED Scanner- nd Button Bluetooth connection LED Hand knob Data and power port CRADLE ADJUSTMENT Tight...
-
Page 6: Power On And Power Off
BATTERY INSERTION/REMOVAL Step1. Flip the battery latch to the open position. Unlock Step2. Insert/Remove the battery. Battery Step3. Flip the battery latch to the close position. Lock POWER ON AND POWER OFF Power on Press the Trigger for 3 seconds to turn it on. Power off Scan the barcode below or keep standby for over 1 hour to turn it off. -
Page 7: Data Output Mode
DATA OUTPUT MODE P11-XX-USB-X refer to the picture as below Adapter-EU PN:01030E11202E USB Cable Adapter-US PN:886783043001 PN:01030E11202A 1. Connect Cable Connect the USB Cable and the Power Adapter. 2. Bluetooth Connection of Scanner and Cradle Put the scanner into the cradle and wait for 3 seconds to connect, or scanning the cradle bluetooth address barcode. - Page 8 4. USB COM Mode Step1. Scan the barcode below, cradle switch to USB COM mode. USB COM Mode Step2. Open a serial port application, when you scan a barcode the data will be output in the serial port application. Step3. Open the serial software, the barcode data will appear when scan the barcode.
-
Page 9: Basic Settings
RS232 Mode Step1. Connect the RS232 Cable and the Power Adapter. Step2. Bluetooth Connection of Scanner and Cradle Put the scanner into the cradle and wait for 3 seconds to connect, or scanning the cradle bluetooth address barcode. Step3. The date will be output in serial port software. PARAMETERS Baudrate 115200 Data Bits 8... - Page 10 BASIC SETTINGS Cradle Factory Setting Bluetooth Disconnected Standby for 10 min. Standby for 1 hour (Default) keep Standby...
- Page 11 Carriage Return Suff x Line Feed Carriage Return & Line Feed Disable Note： Download all configration barcodes from www.generalscan.cloud...
-
Page 12: Led And Beeper Indications
State LED blinks Six beeps Button green six times Power on Power LED stays on Bluetooth LED Bluetooth connected stays on Bluetooth disconnected Bluetooth LED off SOFTWARE DOWNLOAD Please download the EasyScan required to configurate at PC end from our website www.generalscan.cloud... - Page 13 Q & A Problem Possible Causes Possible Solution Scanner not No power to scanner Check system power working Scanner not Scanner not programmed Ensure scanner is decoding bar for barcode type programmed to read code type of bar code being scanned Barcode not clear, Ensure barcode is...
- Page 14 Service Information If you have any question of your GENERALSCAN barcode scanner, please visit our service page for assistance. www.generalscan.cloud/services QUICK START GUIDE Email: Support@generalscan.cloud ©2023 GENERALSCAN All rights reserved Version 1.0 8 8 6 7 8 3 0 1 9 0 0 1...
