I2C Breakout
Pin(s)
1
2
3
Current Sense Breakout Pads
The Current Sense Breakout pads expose the differential signals positioned far from the board edge, along the current path of the volt-
age buffer to avoid exposing the circuit to excessive noise.
SNS Breakout
Pin(s)
1
2
silabs.com | Building a more connected world.
Arrow.com.
Downloaded from
Function
SDA
SCL
GND
Table 4.12. SNS Breakout
Function
Positive
Negative
UG569: Adapter Board for Co-Processor Radio Boards User's Guide
Table 4.11. I2C Breakout
Breakout Pads
B0101
B0100
B0109
+
POSITIVE
NEGATIVE
-
Breakout Pads
B0708
B0709
Connectors
Rev. 1.0 | 21
