UG569: Adapter Board for Co-Processor
Radio Boards User's Guide
The Adapter Board for Co-Processor Radio Boards is an excel-
lent way to explore and evaluate Co-Processor Radio Boards
with various host devices using either SPI or SDIO interfaces. Ex-
ample of host devices are EFM32 or EFR32 devices, Raspberry
Pi or other Linux machines with a SDcard interface, STM micro-
controllers.
When connected to a compatible host board, the Adapter Board puts the Wi-Fi Network
or Radio Co-Processor (NCP/RCP) board in direct comnunication with the host device,
securing correct operation while debugging.
The kit comes in three different variants as BRD8045A, BRD8045B and BRD8045C
which easily integrate and bring additional wireless connectivity to respectively compat-
ible Silicon Labs Wireless Pro Kit Mainboards through the EXP header, a Raspberry Pi
through the HAT interface, and other host boards equipped with an Arduino UNO rev 3
compatible host interface, for example STM32 Nucleo-64 boards.
silabs.com | Building a more connected world.
Arrow.com.
Downloaded from
Copyright © 2023 by Silicon Laboratories
ADAPTER BOARD COMMON FEATURES
• Device Interface: Silicon Labs Wireless
Radio Boards
• USB port for In System Programming
(ISP) of SiWx Devices
• Power Source Selector
• 2x analog Current Sense outputs with
different gains
• Reset button
• Break Out pads
BRD8045A FEATURES
• Silicon Labs EXP interface for EFM32 or
EFR32 Devices Wireless Pro Kit
• EXP-to-SDCard Adapter board
(BRD8046A) for other Linux machines
(SDIO)
• SiWx917-EB4346A
BRD8045B FEATURES
• HAT compatible interface for Raspberry
Pi
• SiWx917-EB4346B
BRD8045C FEATURES
• Arduino UNO rev 3 compatible Shield
interface for e.g. STM32 Nucleo-64
boards
• SiWx917-EB4346C
Rev. 1.0
Advertisement
Table of Contents
Related Manuals for Silicon Laboratories BRD8045A
Summary of Contents for Silicon Laboratories BRD8045A
- Page 1 • Reset button securing correct operation while debugging. • Break Out pads The kit comes in three different variants as BRD8045A, BRD8045B and BRD8045C which easily integrate and bring additional wireless connectivity to respectively compat- BRD8045A FEATURES ible Silicon Labs Wireless Pro Kit Mainboards through the EXP header, a Raspberry Pi through the HAT interface, and other host boards equipped with an Arduino UNO rev 3 •...
-
Page 2: Table Of Contents
3.4 Hardware Layout ......10 3.4.1 Hardware Layout of BRD8045A ..... . .10 3.4.2 Hardware Layout of BRD8045B . - Page 3 9.3 SiWx917-EB4346C Revision History ..... .28 10. Document Revision History ......29 silabs.com | Building a more connected world.
-
Page 4: Introduction
• a Raspberry Pi • an STM32 NUCLEO-F411RE, respectively. Figure 1.1. Adapter Board (BRD8045A) Connected to a Silicon Labs Wireless Pro Kit Board Figure 1.2. Adapter Board (BRD8045A) Connected to a Silicon Labs EXP-MicroSD Adapter Board silabs.com | Building a more connected world. - Page 5 UG569: Adapter Board for Co-Processor Radio Boards User's Guide Introduction Figure 1.3. Adapter Board (BRD8045B) Connected to a Raspberry Pi Figure 1.4. Adapter Board (BRD8045C) Connected to a NUCLEO-F411RE silabs.com | Building a more connected world. Rev. 1.0 | 5 Arrow.com.
-
Page 6: Ordering Information
1x BRD4346A SiWx917 Wi-Fi 6 and Bluetooth LE Co-Processor EB4346A cessor EXP Expansion Kit Radio Board 1x BRD8045A Adapter Board for Co-Processors 1x BRD8046A EXP-to-SDCard Adapter board SiWx917- SiWx917 Wi-Fi 6 and Bluetooth LE Co-Pro- 1x BRD4346A SiWx917 Wi-Fi 6 and Bluetooth LE Co-Processor... -
Page 7: Specifications
UG569: Adapter Board for Co-Processor Radio Boards User's Guide Specifications 2. Specifications 2.1 Recommended Operating Conditions The following table is intended to serve as guideline for a correct use of Adapter Board, indicating typical operating conditions and some design limits. Table 2.1. -
Page 8: Hardware Overview
Here is an overview of the signal routed to the host interface, by product variant: Table 3.1. Overview of Host Connectivity BRD8045A BRD8045B BRD8045C SPI/SDIO... -
Page 9: Uart And Usb Connections
UG569: Adapter Board for Co-Processor Radio Boards User's Guide Hardware Overview 3.2.1 UART and USB connections As the BRD8045x Adapter Board for Co-Processor Radio Boards comes from the factory, the UART data lines are mapped to a particu- lar UART port of the SiWx917 Wi-Fi Co-processor, supporting ISP mode. A slide switch allow users to connect this port either to the host, for remote programming , or to the on-board UART-USB bridge, to connect a PC and load the Co-processor firmaware using a terminal. -
Page 10: Power Supply And Current Sense Outputs
The physical implementations of the different BRD8045x Adapter Boards are shown below. Dashed areas indicate not mounted compo- nents. 3.4.1 Hardware Layout of BRD8045A BRD8045A Adapter Board has components on top side only: View from Top side View from Bottom side... -
Page 11: Hardware Layout Of Brd8045B
UG569: Adapter Board for Co-Processor Radio Boards User's Guide Hardware Overview 3.4.2 Hardware Layout of BRD8045B BRD8045B Adapter Board is designed to be mounted on top of a Raspberry Pi using the HAT connector (bottom view). There are M2.5 mounting holes to secure the board to the Raspberri Pi host by optional spacers. View from Top side View from Bottom side Raspberry Pi... -
Page 12: Connectors
UG569: Adapter Board for Co-Processor Radio Boards User's Guide Connectors 4. Connectors This chapter gives an overview of the Adapter Board for Co-Processor Radio Boards connectivity. 4.1 USB Type-C Connector The USB Type-C connector is located on the bottom right corner of the board and can be used to provided auxiliary power, or to access In System Programming (ISP) mode. -
Page 13: Exp Header Pinout
UG569: Adapter Board for Co-Processor Radio Boards User's Guide Connectors 4.2.1 EXP Header Pinout The table below shows the pin assignments of the EXP Header. Table 4.1. EXP Header Pinout EXP Header Function HOST_5V PTA_GRANT UART_RX UART_TX SPI_CS / SDIO_CMD SPI_SCLK SPI_MISO / SDIO_D1 SPI_MOSI / SDIO_D0... -
Page 14: Raspberry Pi Connector (Hat)
UG569: Adapter Board for Co-Processor Radio Boards User's Guide Connectors 4.3 Raspberry Pi Connector (HAT) The Raspberry Pi connector (HAT) is located on the bottom side of the Adapter Board for Co-Processor Radio Boards. The figure below shows how the SiWx917 Wi-Fi Co-processor peripherals are mapped to the Raspberry Pi Connector. I2C_SDA I2C_SCL ISP_MODE... -
Page 15: Raspberry Pi Connector (Hat) Pinout
UG569: Adapter Board for Co-Processor Radio Boards User's Guide Connectors 4.3.1 Raspberry Pi Connector (HAT) Pinout The table below shows the pin assignments of the Raspberry Pi connector, and the port pins and peripheral functions that are available on the Adapter Board. Table 4.2. -
Page 16: Shield Interface
UG569: Adapter Board for Co-Processor Radio Boards User's Guide Connectors Raspberry Pi Connector Pin(s) Function Raspberry Pi Pin #RESET GPIO 13 RADIO_F17 GPIO 19 Not Connected SDIO_RPI_D2 GPIO 26 RADIO_F15 GPIO 20 RADIO_P10 GPIO 21 4.4 Shield Interface The Arduino UNO rev 3 compatible Shield interface is a cluster of four pin headers mounted on the bottom side of the Adapter Board for Co-Processor Radio Boards. -
Page 17: Shield Interface Pinout
UG569: Adapter Board for Co-Processor Radio Boards User's Guide Connectors 4.4.1 Shield Interface Pinout The table below shows the pin assignments of the Shield Interface, and the port pins and peripheral functions that are available on the Adapter Board. Table 4.3. Bottom Row (P101) Pinout Shield Interface Pin(s) Function... -
Page 18: Breakout Pads
UG569: Adapter Board for Co-Processor Radio Boards User's Guide Connectors Shield Interface Pin(s) Function Nucleo Shield Pin Ground Ground Not Connected Table 4.6. Top Row (P104) Pinout Shield Interface Pin(s) Function Nucleo Shield Pin Not Connected Not Connected Not Connected Not Connected Not Connected Not Connected... -
Page 19: Breakout Pads Pinout
UG569: Adapter Board for Co-Processor Radio Boards User's Guide Connectors 4.5.1 Breakout Pads Pinout Breakout pads are grouped in clusters by function and in most cases positioned at board edges. Power Breakout Pads VMCU HOST_IOVDD Table 4.7. Power Breakout Power Breakout Pin(s) Function Breakout Pads... - Page 20 UG569: Adapter Board for Co-Processor Radio Boards User's Guide Connectors Current Sense Output Breakout Pads I_SNS_LG I_SNS_HG Table 4.9. Current Sense Output Breakout Current Sense Output Breakout Pin(s) Function Breakout Pads B0705 B0706 B0707 Note: Refer to Section for current consumption. UART Breakout Pads TASS_UART1_TX TASS_UART1_RX...
- Page 21 UG569: Adapter Board for Co-Processor Radio Boards User's Guide Connectors Table 4.11. I2C Breakout I2C Breakout Pin(s) Function Breakout Pads B0101 B0100 B0109 Current Sense Breakout Pads The Current Sense Breakout pads expose the differential signals positioned far from the board edge, along the current path of the volt- age buffer to avoid exposing the circuit to excessive noise.
-
Page 22: Power Supply
UG569: Adapter Board for Co-Processor Radio Boards User's Guide Power Supply 5. Power Supply This section covers two important aspects connected to power supply: how to power the Adapter Board and how to power the Co-Pro- cessor Radio Boards attached to the Adapter Board. 5.1 Board Power Options The Adapter Board needs a 5V power source to operate correctly. -
Page 23: Device Power Options
UG569: Adapter Board for Co-Processor Radio Boards User's Guide Power Supply 5.2 Device Power Options When correctly powered, the Adapter Board interfaces a Host and a Device on differents boards and it ensures that the two portions of circuit in communication always operate at the same voltage level. This is important to avoid back-feeding one of the two circuits and to perform correct current measurements. -
Page 24: Current Measurements
UG569: Adapter Board for Co-Processor Radio Boards User's Guide Current Measurements 6. Current Measurements Measuring current consumption of a Co-processor is in general a more complex task than measuring the consumption of a Microcon- troller. While a Microcontroller can be programmed for test purposes, to enter a determinate state (e.g. sleep state) at start up, a Co- processor typically needs a Host that sends specific instructions to operate and enter a determinate state, which one might want to investigate. -
Page 25: Using External Current Meters
UG569: Adapter Board for Co-Processor Radio Boards User's Guide Current Measurements 6.2 Using External Current Meters When in HOST mode, the current drawn by the Co-processor is tracked along with the current drawn by the Host and other devices on the same power domains. -
Page 26: Downloading Firmware To Siwx917 Wi-Fi Co-Processors
UG569: Adapter Board for Co-Processor Radio Boards User's Guide Downloading Firmware to SiWx917 Wi-Fi Co-processors 7. Downloading Firmware to SiWx917 Wi-Fi Co-processors Co-Processor Radio Boards feature an ISP button for In System Programming, i.e. to load firmware to SiWx devices. For manual acti- vation of the ISP mode, i.e. -
Page 27: Schematics, Assembly Drawings, And Bom
UG569: Adapter Board for Co-Processor Radio Boards User's Guide Schematics, Assembly Drawings, and BOM 8. Schematics, Assembly Drawings, and BOM Schematics, assembly drawings, and bill of materials (BOM) are available through Simplicity Studio when the kit documentation pack- age has been installed. They are also available from the kit page on the Silicon Labs website: silabs.com. silabs.com | Building a more connected world. -
Page 28: Kit Revision History
UG569: Adapter Board for Co-Processor Radio Boards User's Guide Kit Revision History 9. Kit Revision History The kit revision can be found printed on the kit packaging label, as outlined in the figure below. The revision history given in this section may not list every kit revision. - Page 29 UG569: Adapter Board for Co-Processor Radio Boards User's Guide Document Revision History 10. Document Revision History Revision 1.0 December 2023 • Initial document revision. silabs.com | Building a more connected world. Rev. 1.0 | 29 Arrow.com. Downloaded from...
- Page 30 Note: This content may contain offensive terminology that is now obsolete. Silicon Labs is replacing these terms with inclusive language wherever possible. For more information, visit www.silabs.com/about-us/inclusive-lexicon-project Trademark Information Silicon Laboratories Inc. , Silicon Laboratories , Silicon Labs , SiLabs...
