Operation - Kicker KPX Series Owner's Manual

Automatic Turn-On: The KPX-series
offers two different automatic turn-on
modes; +12V and DC Offset.
• Remote Turn-On: Run 18 gauge wire from the Remote
Turn-On Lead on your source unit to the blue REM wire
on the KPX amplifier's wiring harness.
• DC Offset Turn-On: The DC Offset mode detects a
>2.5V DC offset from the HI-Level speaker outputs when
the source unit has been turned on. To use DC offset
mode, the DC OFF/ON push button must be in the ON
or IN position. When using DC Offset mode, the REM
terminal becomes a switched +12V output (100mA) to
turn other amplifiers and devices on.
INPUT LEVEL: The RCA inputs are
capable of receiving either Hi or Low-level
signals from your source unit. If the only
output available from your source unit is a
Hi-Level signal, simply press in the Input
Level switch on the amplifier. Refer to the
wiring section of this manual for additional
instructions.
English

Operation

HI PASS
10-40Hz
DC
OFF/ON
/
BASS
LO PASS
BOOST
40-160Hz 0-6dB
REMOTE
BASS
INPUT
LEVEL
LO/HI
/
GAIN
0-11
10
