- Page 1 5 GALLON MOTORIZED SPRAYER Operation Manual MODEL NUMBER: TPS25 To reduce the risk of injury, the user must read and understand the Operator’s Manual before using this product. Save these instructions for future reference.
-
Page 2: Table Of Contents
1.2 Service Safety 1.3 Safety While Using Combustion Engines 1.4 Service Safety 1.5 Chemical Handling 2. General Information 2.1 Design and Features 2.2 TOMAHAWK® Engine 2.3 Adjustable Pressure 2.4 Spraying Accessories 2.5 Specifications 3. ASSEMBLY GUIDE 4. OPERATION 4.1 Start Up Guide 4.2 Sprayer Operation... - Page 3 Register Your Equipment Thank you for purchasing TOMAHAWK® equipment! Your product is covered by the TOMAHAWK® Warranty Policy, but in order to activate your warranty, we need you to register your product. In addition to activating your equipment warranty, product registration will grant you access to important product updates, streamlined customer service, and more.
-
Page 4: Safety Information
Tomahawk Power. The information contained in this manual is based on equipment’s production at the time of publication. Tomahawk Power reserves the right to change any portion of this information without notice. -
Page 5: Operating Safety
1.2.2 NEVER touch the engine or muffler while the engine is on or immediately after it has been turned off. These areas get hot and may cause burns. 1.2.3 NEVER use accessories or attachments that are not recommended by Tomahawk Power. Damage to equipment and injury to the user may result. -
Page 6: Service Safety
1.4.6 ALWAYS replace worn or damaged components with spare parts designed and recommended by Tomahawk Power. 1.4.7 ALWAYS disconnect spark plug on machines equipped with gasoline engines, before servicing, to avoid accidental start-up. -
Page 7: Chemical Handling
2. GENERAL INFORMATION 2.1 Design and Features Powered by a relentless 1.8HP 2 Stroke Engine, TOMAHAWK® Motorized Sprayers spray further than ever before covering 1 Acre in 15 minutes or less, with 30ft of reach around tall trees and buildings! Never Pump and Never Lose Pressure while maintaining constant, adjustable pressure from 50-450 PSI for even spraying! TOMAHAWK®... -
Page 8: Specifications
2.5 Specifications Model TPS25 Engine Tomahawk TE26CC Engine Type 2 Cycle Air Cooled Engine Fuel Type 50:1 Premix Displacement 26cc Ignition Electric Ignition Starting System Recoil Starter Pump Diaphragm Pump Pump Material Brass and Copper Housing/Fittings, Ceramic Seals Adjustable from 50-450 Max PSI Tank Capacity 5.3 Gallons (20L) -
Page 9: Operation
3. ASSEMBLY GUIDE CONTINUED Attach the twin tip nozzle (A) to the wand (B) Fasten the hose (D) to the backpack then attach to the handle press (C). sprayer’s pump. To attach the straps, feed the end through Fasten the hose (D) to the backpack sprayer’s pump. -
Page 10: Sprayer Operation
4.1 Start Up Guide Continued Prime the fuel injection pump Slowly pour your liquid into the Place the choke down into the 3-5 times. chemical tank. closed position . Pull the recoil starter 1-3 times Place the choke up into the Maintain the engine running on idle until the engine is starts. -
Page 11: Pump Quick Fix
Important Tip: Remember to rinse the tank with 5 gallons of water to remove any chemicals that may crystallize in the pump, hose, and attachments. 5. PUMP QUICK FIX Start the engine and keep it in idle. Using a 10mm socket wrench, loosen the 4 bolts on the right &... -
Page 12: Replacement Parts
7. WARRANTY Your new TOMAHAWK® equipment is warranted to the original purchaser for a period of one-year (12 months) from the original date of purchase. The TOMAHAWK® warranty is against defects in design, materials and workmanship. -
Page 13: Maintenance
8. MAINTENANCE Maintain the equipment in accordance with the following recommended procedures. Refer to the engine manufacturer’s instruction manual for additional information about engine maintenance. The following chart is based on a normal operation schedule. AFTER DAILY AFTER AFTER AFTER FIRST 200 BEFORE/ FIRST 20... -
Page 14: Troubleshooting
9. TROUBLESHOOTING PROBLEM CAUSE SOLUTION Push fuel-injec�ng pump un�l fuels Failed to push fuel-injec�ng pump runs through lines Water mixed with fuel Replace the fuel Fails to Start Deteriora�on of spark plug or carbon Replace the spark plug build up Bad contact between spark plug and Check the spark plug lead wire... -
Page 15: Transportation & Storage
9. TROUBLESHOOTING CONTINUED PROBLEM CAUSE SOLUTION Inlet and/or outlet valves are blocked Replace or Clean Washer is damaged Replace Liquid does not spray out Bearing is damaged Replace Piston is damaged Replace Not enough pressure Regulate Not enough elas�c force regula�ng Replace Low or no pressure spring... -
Page 16: Parts Manual
MOTORIZED SPRAYER Parts Manual MODEL NUMBER: TPS25... - Page 17 TPS25 PARTS...
- Page 18 TPS25 Part Kit Part No. Part Name Qty. (If Available) 3WZ-6.5.2-1 3WZ-4.7.1-3 TPS25-LID 3WZ-4.7.1-4 3WF-8.1-1 SEALING WASHER 3WZ-6.5.1 CHEMICAL TANK TPS25-STRAP 3WZ-9.2 BANDS ASSM 3WF-3A.1-2 SEALING WASHER 3WZ-6.5-1 3WF-14-13 PLASTIC CLICK 3WZ-9.1 BACK DACK ASSM QC/T621 Q673B15 CLIP GB13527.1LS-10x2.5x140 TUBE GB13527.1LS-10x2.5x340...
- Page 19 PUMP SYSTEM Part Kit Part No. Part Name Qty. (If Available) 3WZ-7B.5-1 CLUTCH DRUM COVER 1E36F.2 SEAL 3WZ-7B.5.1-1 CONNECTING BASE GB/T276 BEARING 6000/P6 TPS25-PUMP 3WZ-7B.5.1-4 WHEEL GB/T276(17x42x12} BEARING 6203x3 GB/T276(10x32x9} BEARING 6200xl 3WZ-7B.5.1-2 NOUMENON...
- Page 20 SPRING SEAT 2 3WZ-7B.5.5-5 SPRING GB70.1 SCREW ASSM M6X16 3WZ-7B.5.5-2 VALVE 3WZ-7B.5.5.1 BATTER BOARD GB845ST4.2X10 SCREW ASSEM 3WZ-7B.5.5-4 SPRING SEAT 1 TPS25-PUMP GB3452.1 O-RING 12.5x2.65 3WZ-7B.5.5-7 VALVE SEAT GB3452.1 O-RING 11.8xl.8 3WZ-7B.5.3-2 DISCHARGE METAL A 3WZ-7B.5-3 BOX BACK COVER GB/T3452.1 O-RING 46.2x2.65 GB70.1+GB93...
- Page 21 ENGINE ASSEMBLY...
- Page 22 ENGINE ASSEMBLY Part Kit Part No. Part Name Qty. (If Available) GB70.1+GB93+GB97 SCREW M5X16 TPS25-RS4 P23.10A STARTER TPS25-FLYWL P23.9A GUIDE COVER ASS'Y 1E36F.2 OIL SEAL P23.11-2 CRANK CASE R GB/T119.1 PIN 4XH8X8 GB/T276 BEARING 6001/P53 P23.11-3 GASKET CRANK CASE P23.6A.1 CRANK SHAFT ASSY 1E40FP-3Z.3-1...
- Page 23 Part No. Part Name Qty. (If Available) HP23.1-1 COVER CLEANER 1E34FG.1.1 KNOB COVER 1E34F-3 GASKET MUFFLER 1E34F-2E.2 MUFFLER HP23-SA COVER TPS25-ENGINE HP23-8 SCREW MSXSS-10.9 GB70.1+GB93+GB97 SCREW MSX14 HP23-2 CLAPBOARD HP23.3 TOP COVER 1E33F-4 SPACER LG COIL 1E44F-E.5.1-2-EPA FUEL PIPE CP5XCP2.SX100 1E36FF.8.1-1 PLUG 1E44F-E.5.1-1-EPA...
-
Page 24: California Emission Control Warranty
Tomahawk Power, LLC recommends that you retain all receipts covering maintenance on your small engine/ equipment, but Tomahawk Power, LLC cannot deny warranty solely for the lack of receipts or for your failure to ensure the performance of all scheduled maintenance. - Page 25 Owner's Manual is warranted for the warranty period stated above. If the part fails during the period of warranty coverage, the part will be repaired or replaced by Tomahawk Power, LLC according to Subsection (4) below. Any such part repaired or replaced under warranty will be warranted for the remainder of the period.
- Page 26 The use of any non-exempted add-on or modified parts by the ultimate purchaser will be grounds for disallowing a warranty claims. Tomahawk Power, LLC will not be liable to warrant failures of warranted parts caused by the use of a non-exempted add-on or modified part.
- Page 27 (4) Catalytic Muffler Assembly including: (a) Muffler gasket (b) Exhaust manifold (c)Catalytic converter (5) Crankcase Breather Assembly including: (a) Breather connection tube. (6) Fuel tank evaporative emissions control system including: (a) Purge Valves (b) Carbon Canister (c) Canister Mounting Brackets (d) Fuel Cap (e) Fuel Tank (7)Miscellaneous items Used in Above Systems including:...
- Page 28 With same day shipping and faster delivery times, count on Tomahawk to keep you powered throughout the day! With long lasting parts and engines, Tomahawk equipment will be the star of your fleet for years to come. Visit www.tomahawk-power.com to get started today!
