Summary of Contents for Tomahawk TBS500
- Page 1 TBS500 Assembly Manual SKID SPRAYER YEAR Honda Engine...
- Page 2 TBS500: Skid Sprayer Assembly Pt.1 www.tomahawk-power.com Remove the motor and all parts from the Attach the end of the orange tube to the packaging. base of the pump. Attach the front of the orange tube to the Attach the end of the clear tube below the filter.
- Page 3 TBS500: Skid Sprayer Assembly Pt.2 www.tomahawk-power.com Attach the throttle control using the last 2 Connect the throttle wires to the Honda screws and nuts. Engine wires. Left to Left. Right to Right. Place the throttle cable end into the gap and Remove the air filter to access the fit the cable along the top of the throttle.
- Page 4 With same day shipping and faster delivery times, count on Tomahawk to keep you powered throughout the day! With long lasting parts and engines, Tomahawk equipment will be the star of your fleet for years to come. Visit www.tomahawk-power.com to get started today!
