Tomahawk TPS25 Operations & Parts Manual

Backpack sprayer
Hide thumbs Also See for TPS25:

Advertisement

Quick Links

T Cl tA J.\ �� J.\
Cl V�
IC I>
I: I�
\\f
BACKPACK SPRAYER
OPERATIONS & PARTS MANUAL
FIND OUR HOW TO GUIDE ON
You
www.youtube. com/tomahawk-power
For Video Assembly Instructions
Go to
www.Youtube.com
Type the following on Search Bar
assemble Tomahawk TPS25
Click on video titled:
HOW TO: Assemble TPS25 Backpack Sprayer

Advertisement

loading
Need help?

Need help?

Do you have a question about the TPS25 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tomahawk TPS25

Summary of Contents for Tomahawk TPS25

  • Page 1 BACKPACK SPRAYER OPERATIONS & PARTS MANUAL FIND OUR HOW TO GUIDE ON www.youtube. com/tomahawk-power For Video Assembly Instructions Go to www.Youtube.com Type the following on Search Bar assemble Tomahawk TPS25 Click on video titled: HOW TO: Assemble TPS25 Backpack Sprayer...
  • Page 2 TPS25 QUICK HOW-TO GUIDE www.tomahawk-power.com Start by assembling sprayer wands Washers Place washers inside brass connectors Double check that all connections -Do not add fuel while the are correct and stable. engine is hot or running Place washers inside brass -Avoid filling the tank all connectors &...
  • Page 3 Warning to Users The gasoline engi gasoline to two-stroke automobile oil. 2. Keep engine at a low speed 3-5 minutes after start and before stop. 3. Using your sprayer at a high engine speed without liquid spray or dust is prohibited and may damage your sprayer engine.

  • Page 4: Table Of Contents

    Table of Contents 2. Main Application …………………………………………………….….…………..….……6 3. Main Features ………………………………………………………….………….….….…….6 4. Main Parts ............……………………………………...……… 6 5. Operating Instructions …....…………………………………….……...……….7 6. Safe Operation….……….…………………………………………………….……………….9 7. Troubleshooting ………………………………………………….……….….……....9 8. Maintenance and Storage ..……………………………………..….……......10 9. Quick How-to-Guide .......................12...
  • Page 5 •Clothing covering arms and legs must be worn to avoid contact Safe use of the Tomahawk Power Sprayer: with pesticide. 1.The operator The operator must be in good physical 3. Using the Tomahawk Power condition and mental health.
  • Page 6 Fueling (5) For the operator’s safety, dusting / spraying Keep the fuel tank far away from the must be carried out strictly according to the flames or sparks. Do not smoke instruction of the chemicals and agricultural near fuel. When the machine is requirements.

  • Page 7: Main Application

    Recoil starting Way of stopping Shutting throttle fully 2. Main Application Main Structure This Tomahawk Power Backpack Sprayer is the ideal portable tool for prevention of diseases This machine consists mainly of: and for plant protection. It is mainly used in Engine.

  • Page 8: Operating Instructions

    5.Operating Instructions Preparation before start 5.1.1 Connecting spraying parts. Before starting, verify all the connections are working. 1.Long Spraying Nozzle 4.Valve 2.Washer 5.Handle 3.Straight Spraying Tube 6.Plastic Tube Never fill the fuel tank to the very top. Never add fuel to the tank in a closed non-ventilated area. Do not add fuel to this unit close to a open fire or sparks.
  • Page 9 5.3.3 Important notes when spraying: A) Swing the spraying tube with your hand after turning on the handle valve. In order to avoid chemical harm, it is strictly prohibited to spray only in one place. B) Operator should face the wind. The spraying tube should form an approximate 15°...

  • Page 10: Safe Operation

    6.Safe Operation 6.1 Read the instruction manual carefully. 6.2 Protective gear: a ) Wear a flanged cap b ) Wear dirt/fog-proof goggles ) Wear a gauze mask ) Wear a coat guard e ) Wear long sleeve gloves f ) Wear boots 7.Troubles hooting 7.1 Engine troubleshooting guide Problem...

  • Page 11: Maintenance And Storage

    Clean Warranty and Service Tomahawk Power guarantees problem-free quality and will assume the costs for defect remediation by replacing defective parts in the case of material or manufacturing defects that occur within the guarantee period a the date of purchase. Please note that specific guarantee conditions apply in some countries. Ask your sales person if you have any questions.
  • Page 12 9 . Te c h n i c a l M a i n t e n a n c e a n d Note: Long Term Storage The work including maintenance, cleaning and adjusting must be done (1)Spraying units after stopping the machine.
