F L E X
S E R I E S
USER MANUAL
v.1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FLEX Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Spypoint FLEX Series

Summary of Contents for Spypoint FLEX Series

  • Page 1 F L E X S E R I E S USER MANUAL v.1.0...
  • Page 2 This User Manual will introduce you to the features of your new FLEX Series been a cellular trail camera leader for some time, the FLEX Series is a major and will guide you through the acquisition of its functionalities so that you can step forward in customer-friendly and innovative design, optimized antenna, use it to its full potential.

  • Page 3: Table Of Contents

    Table Of Content SPYPOINT FLEX Series Components ..................4 Features ....................6 Power Supply ..................8 Memory Card ..................10 Preparation ..................12 Activation .................... 13 Installation ..................14 Starting Your Camera ..............15 Configuration ..................16 Verification ..................19 Tool – Accessories – Options ............21 Transferring Files to a Computer ..........

  • Page 4: Components

    Components SPYPOINT FLEX Series Solar panel FLEX-S only Battery door Signal level Cable lock hole    Microphone microSD card slot STATUS light Locking latch     IR LED Micro SIM card slots FORMAT button Slots for installation strap ...
  • Page 5 The SIM cards, pre-installed and preactivated, are included with the camera. LOCKING LATCH It is important to use a SPYPOINT SIM cards (supplied by SPYPOINT), otherwise the cellular functions of the camera will be inoperative. Allows you to lock, unlock and open the door.

  • Page 6: Features

    Features SPYPOINT FLEX Series FLEX-M FLEX G-36/G-36C FLEX-PLUS FLEX-S NETWORK LTE MULTI-CARRIER AUTO CONNECTIVITY PHOTO RESOLUTION PHOTO FILE FORMAT JPEG TIME-LAPSE CHECK CHECK CHECK CHECK TIME-LAPSE + CHECK CHECK CHECK CHECK MULTI-SHOT MODE Up to 3 CAPTURE MODE Color Photo/Video by day | Black & White Photo/Video by Night...
  • Page 7 Power Supply SPYPOINT FLEX Series flex-s only BEFORE YOUR FIRST USE, CHARGE THE INTERNAL BATTERY • Ensure the camera is powered OFF • Plug the charging cable (12 V DC connector) to the camera. • The status light will illuminate red while charging and turn OFF when fully charged.

  • Page 8: Power Supply

    Power Supply SPYPOINT FLEX Series CHOOSING A POWER SOURCE • When batteries of different brand or type are used together, or new and old batteries are used together, some batteries may be over-discharged due to a difference in voltage or capacity. This can result in venting, leakage, FLEX-S only - It's not required to add additional power sources to your and rupture and may cause personal injury.
  • Page 9 Power Supply SPYPOINT FLEX Series MANAGING VARIOUS CAMERA POWER SUPPLY FLEX-PLUS ONLY If you choose to plug an external 12V battery (SPLB-22, SPLB-10 or KIT-12V, You can use them in any configuration with compatible batteries.  sold separately) into your camera, it becomes your camera's new primary Please check the chart below to confirm compatibility.

  • Page 10: Memory Card

    • The card is inserted correctly when a click is heard. • If using a microSD card 64 GB or larger - the SD card should be formatted in the flex series camera directly.
  • Page 11 Memory Card SPYPOINT FLEX Series REMOVING YOUR MEMORY CARD • Before removing a memory card, always turn your camera OFF to prevent files on the card from being deleted or damaged. • To remove the card, push it lightly into the camera until you hear a click.

  • Page 12: Preparation

    The antenna doesn't come installed. Please insert as shown in the photo. Before you can use your camera, you must activate it.  To do so, you will need the activation code. FINDING THE ACTIVATION CODE The activation code is located inside the FLEX Series’s battery compartment. Activation code...

  • Page 13: Activation

    FLEX Series SPYPOINT APP - NEW USERS On your mobile device or a computer, use the web browser and navigate to www.spypoint.com, select “LOGIN” in the top navigation menu. On the displayed “SPYPOINT” page, select “CREATE AN ACCOUNT“, fill out the required fields, then log in. Once your account is created you can either continue to use the web version of the application or you can switch to the mobile application.

  • Page 14: Installation

    Installation INSTALLING YOUR CAMERA 1. To install the camera, loop the installation strap through the intended slots. 2. Choose a solid tree that does not move in the wind, as movement will cause false detections. 3. Make sure the area immediately in front of your camera is free of branches or twigs that could be blown away by the wind.

  • Page 15: Starting Your Camera

    Starting Your Camera SPYPOINT FLEX Series OPERATIONAL VALIDATION TEST You can use the following test to make sure everything works as it should: TEST BUTTON The TEST button forces the camera to take a single photo and transmits it. It will NOT work if the camera is already busy with another task.

  • Page 16: Configuration

    SPYPOINT FLEX Series MANAGE DEVICE Use the SPYPOINT app to configure your camera. EDIT DEVICE NAME Allows you to name the camera for easy identification. This function is very useful for users with more than one camera. All possible values RESTORE FACTORY SETTINGS Allows you to reset the camera to its original state.
  • Page 17 Configuration SPYPOINT FLEX Series CELLULAR Allows you to choose the time when the camera makes its first transfer of the day, each day. DAILY SYNC TIME Note: The camera transfers are configured by default with 6 times per day, determined from the time you activated All possible combinations your camera.
  • Page 18 Configuration SPYPOINT FLEX Series GENERAL DATE FORMAT Allows you to choose the date format displayed. MM/DD/YYYY or DD/MM/YYYY TIME FORMAT Allows you to choose the time format displayed. 12 h or 24 h BATTERY TYPE Allows the user to select the battery type installed in the camera.

  • Page 19: Verification

    VERIFYING CAMERA STATUS Different tools are available to help you check the status of your Here are the different indicators of the FLEX Series status you have access to. FLEX Series and to inform you of any problems that may occur They are accessible on your app or on the SPYPOINT website.
  • Page 20 Verification SPYPOINT FLEX Series STATUS LIGHT EXPLAINED STATUS LED COLOR PATTERN INDICATION When device gets triggered or Green Solid is taking a photo or video Blue Solid When photo or video is getting transmitted Blinking each second Blue Factory reset...

  • Page 21: Tool - Accessories - Options

    From the app, you can: SPYPOINT WEB APP • Manage camera statuses, settings and plans As well as with the SPYPOINT mobile app, you can • View and manage photos and videos manage your device and photos/videos using the • Sort photos with advanced AI species filters web app.

  • Page 22: Transferring Files To A Computer

    • The computer will recognize the microSD card. There may be two the “Ctrl” and “V” keys). The photos and videos will be copied in the new folder. different disks recognized, this is normal after use in the FLEX Series. • If the computer doesn't detect the microSD card, this means ON A MAC the memory card is corrupt and needs to be replaced.

  • Page 23: Offered Accessories

    Boosts the cellular signal. 15 feet (4.57 meters) 12 V BATTERY, CHARGER & HOUSING KIT cable. No external power source necessary. Compatible with all SPYPOINT devices with a #CA-01 12 V socket. Case, AC charger, 12 ft (3.6 meters) power cable (#PW-12FT) and strap included.

  • Page 24: Troubleshooting

    Troubleshooting SPYPOINT FLEX Series ISSUES POSSIBLE SOLUTIONS 1. Slide the power switch to the OFF position and then back to the ON position. IN GENERAL 2. Check that the power source is fully charged. 3. Format or Replace the MicroSD Card.

  • Page 25: Warranty

    FLEX Series LIMITED WARRANTY This SPYPOINT product is covered by a 2-year warranty that also covers parts and workmanship from the purchase date. The electronic cash register receipt is a proof of purchase and must be presented to confirm that the warranty is applicable.

  • Page 26: Regulation

    Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in Use the FLEX Series in the environment with the temperature between -1°C and a residential installation. This equipment generates uses and can radiate 35°C.

  • Page 27: Disposal & Frequency

    24 DBM + 1,7/-3,7 DB UMTS 800 24 DBM + 1,7/-3,7 DB SPYPOINT FLEX Series | Made in China 12 V DC • LIT-22 Lithium battery pack • 8 X R6 (AA) batteries (2 X 6 V) Contain FCC ID: XMR201807EG91NA • IC: 10224A-2018EG91NA Manufacturer: SPYPOINT Address: 330 de la Jacques-Cartier, Victoriaville QC G6T 1Y3 •...
