INSTRUCTION MANUAL
ANALOG I/O MODULE
BEFORE USE ....
Thank you for choosing us. Before use, please check con-
tents of the package you received as outlined below.
If you have any problems or questions with the product,
please contact our sales office or representatives.
■ PACKAGE INCLUDES:
Analog I/O module ..............................................................(1)
Terminating resistor (110 Ω, 0.25 W) .................................(1)
■ MODEL NO.
Confirm Model No. marking on the product to be exactly
what you ordered.
■ INSTRUCTION MANUAL
This manual describes necessary points of caution when
you use this product, including installation, connection and
basic maintenance procedures.
MG CO., LTD. www.mgco.jp
5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
(Modbus; RS-485)
MODEL
POINTS OF CAUTION
■ POWER INPUT RATING & OPERATIONAL RANGE
• Locate the power input rating marked on the product and
confirm its operational range as indicated below:
85 – 132V AC rating: 85 – 132V, 47 – 66 Hz, approx. 4VA
24V DC rating: 24V ±10%, approx. 4W, approx. 160mA
■ GENERAL PRECAUTIONS
• Before you remove the unit or mount it, turn off the power
supply, input signal and output signal for safety.
■ ENVIRONMENT
• Indoor use.
• When heavy dust or metal particles are present in the
air, install the unit inside proper housing with sufficient
ventilation.
• Do not install the unit where it is subjected to continuous
vibration. Do not subject the unit to physical impact.
• Environmental temperature must be within -5 to +55°C
(23 to 131°F) with relative humidity within 30 to 90% RH
in order to ensure adequate life span and operation.
■ WIRING
• Do not install cables close to noise sources (relay drive
cable, high frequency line, etc.).
• Do not bind these cables together with those in which
noises are present. Do not install them in the same duct.
■ AND ....
• The unit is designed to function as soon as power is sup-
plied, however, a warm up for 10 minutes is required for
satisfying complete performance described in the data
sheet.
INSTALLATION
Use the Installation Base (model: MxBS2).
61M
EM-6631 Rev.6 P. 1 / 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 61M and is the answer not in the manual?

Questions and answers

Summary of Contents for MG 61M

  • Page 1 10 minutes is required for satisfying complete performance described in the data sheet. INSTALLATION Use the Installation Base (model: MxBS2). MG CO., LTD. www.mgco.jp EM-6631 Rev.6 P. 1 / 5 5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN...
  • Page 2: Component Identification

    ON at errors in parity, framing, overrun, CRC, LRC SD (red) ON when transmitting RD (red) ON when receiving Euro type connector For wiring to Modbus terminal for Modbus MG CO., LTD. www.mgco.jp EM-6631 Rev.6 P. 2 / 5 5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN...
  • Page 3: Terminal Connections

    (AWG24 to 12) Stripped length: 7 mm COMMUNICATION CABLE CONNECTIONS HOST PC ANALOG I/O MODULE ANALOG I/O MODULE TERMINATOR Tx+ / Rx+ Tx– / Rx– Rx– MG CO., LTD. www.mgco.jp EM-6631 Rev.6 P. 3 / 5 5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN...
  • Page 4 Contents of the diagnostic data (2 bytes) Change ASCII Input Delimiter Delimiter character of ASCII message Force Listen Only Mode Force the slave into Listen Only Mode MG CO., LTD. www.mgco.jp EM-6631 Rev.6 P. 4 / 5 5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN...
  • Page 5: Modbus I/O Assignments

    Analog output 17 – Analog output 49 – Full scale 81 – 112 Zero scale ■ 61M Type 1: Analog input 2: Analog output ■ Data Type F: Floating I : Int 0 – 10000 (0 – 100%) * Averaging SW...
