MG DLC E2 Series Instruction Manual

INSTRUCTION MANUAL
REMOTE I/O INTERFACE UNIT
16 contact inputs & 16 open collector outputs
Thank you for choosing us . Before use, check specifications on the
unit label.
If you have any problems or questions with the product, please contact
our s ales o ffice or representatives.

General Description

The Model DLC- E2 accepts 16-channel contact inputs into serial
signal and provides 16-channel open collector outputs.

Installation

[mm (inch)]
• Operating temperature: -5 to +50°C (23 to 122°F)
• Operating humidity: 30 to 90% RH (non-condensing)
Keep away from water, corrosive gas, dust and vibration.
MG CO., LTD. www.mgco.jp
5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
model
SURFACE MOUNTING
55 55
3.5 (.14) (2.17) (2.17)
SIDE MOUNTING (terminal block at the right side)
170 (6.69)
DLC- E2
DLC- E2
2–M4 SCREW
4–M4 SCREW
WIRING SPACE
95 (3.74) MIN.
P. 1 / 4 EM-6512-E2 Rev.7
