INSTRUCTION MANUAL
ANALOG I/O MODULE
1. BEFORE USE .... .......................................................................................... 2
2. GENERAL DESCRIPTION ........................................................................... 2
3. POINTS OF CAUTION .................................................................................. 3
4. INSTALLATION ............................................................................................ 3
5. HARDWARE SPECIFICATIONS .................................................................. 4
5.1 61C-x1 (No. of channels codes 04, 08, or 16 in x) ...........................................................................4
5.2 61C-x2 (No. of channels codes 04, 08, or 16 in x) ...........................................................................4
5.3 61C-163 ...........................................................................................................................................5
6. COMPONENT IDENTIFICATIONS & HARDWARE ADJUSTMENTS .......... 5
7. TERMINAL CONNECTIONS ........................................................................ 6
8. CONNECTING DATA LINK WIRES .............................................................. 7
8.1 TWISTED-PAIR CABLE ...................................................................................................................7
8.2 POINTS OF CAUTION IN HANDLING WIRES ...............................................................................7
8.3 WIRING DIAGRAM ..........................................................................................................................7
9. POINTS OF CAUTION IN CONNECTING WIRES ....................................... 7
10. I/O SIGNALS ................................................................................................ 8
10.1 REMOTE I/O ..................................................................................................................................8
10.2 ASSIGNING REMOTE REGISTERS .............................................................................................8
10.3 A/D CONVERSION ......................................................................................................................10
11. PARAMETERS SETTING BY PLC PROGRAM ..........................................11
11.1 GENERAL DESCRIPTION .......................................................................................................... 11
12. TROUBLESHOOTING .................................................................................12
12.1 L ERR. INDICATOR BLINKING ...................................................................................................12
12.2 L ERR. INDICATOR ON ...............................................................................................................12
12.3 L RUN INDICATOR OFF ..............................................................................................................12
12.4 UNABLE TO READ/WRITE DIGITAL VALUES? ..........................................................................12
13. LIGHTNING SURGE PROTECTION ...........................................................12
MG CO., LTD. www.mgco.jp
5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
(CC-Link)
C O N TE N TS
61C
MODEL
EM-6627 Rev.9 P. 1 / 12
Advertisement
Table of Contents
Related Manuals for MG 61C
Summary of Contents for MG 61C
-
Page 1: Table Of Contents
3. POINTS OF CAUTION .................. 3 4. INSTALLATION .................... 3 5. HARDWARE SPECIFICATIONS ..............4 5.1 61C-x1 (No. of channels codes 04, 08, or 16 in x) ................4 5.2 61C-x2 (No. of channels codes 04, 08, or 16 in x) ................4 5.3 61C-163 ............................5 6. -
Page 2: Before Use
/C03: Rubber coating Various inputs and outputs are available by employing Mini-M series, Pico-M series or other signal conditioners. The 61C input module converts analog inputs (0 – 100%) proportionally into 16-bit signed binary signals. The one for output converts 16-bit signed binary signals proportionally into analog outputs (0 –... -
Page 3: Points Of Caution
• The unit is designed to function as soon as power is supplied, however, a warm up for 10 minutes is required for satisfying complete performance described in the data sheet. 4. INSTALLATION Use the Installation Base (model: MxBS2). EM-6627 Rev.9 P. 3 / 12 MG CO., LTD. www.mgco.jp 5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN... -
Page 4: Hardware Specifications
5. HARDWARE SPECIFICATIONS 5.1 61C-x1 (No. of channels codes 04, 08, or 16 in x) ITEM SPECIFICATIONS Analog input 1 – 5 V DC (input resistance ≥ 1 MΩ) Protocol CC-Link, Ver.1.10 Digital output 16-bit signed binary (14 bits for data) I/O characteristics 0 –... -
Page 5: 163
OFF: normal transmission SD (red) ON when transmitting RD (red) ON when receiving Euro type connec- For wiring to CC-Link tor terminal for CC-Link EM-6627 Rev.9 P. 5 / 12 MG CO., LTD. www.mgco.jp 5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN... -
Page 6: Terminal Connections
Base Modular Jack for Factory MODULAR JACK Calibration * Attach the terminating resistor when the module is at the termination of a transmission line. EM-6627 Rev.9 P. 6 / 12 MG CO., LTD. www.mgco.jp 5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN... -
Page 7: Connecting Data Link Wires
The following explanations apply to the wires connecting the 61C to the Master Unit. 8.1 TWISTED-PAIR CABLE The following types of wire are recommended for connecting the 61C to the Master Unit. KURAMO ELECTRIC FANC-SB 0.5 mm × 3 or equivalent... -
Page 8: I/O Signals
10.1 REMOTE I/O The 61C occupies from 1 up to 4 nodes according to the number of I/O channels. Regardless of the number of nodes, 32 bits are assigned to each of input and output for sending to/receiving from the Master Unit. One (1) bit among RXxB* is used as remote device (61C) READY signal, turned ON when the 61C is in normal operation. - Page 9 (2) 61C-x2, 61C-163 The 61C-x2 does not use the remote registers for the direction from the Remote to Master (RWrn to RWrn+15). The table below shows the data assignment of those for the direction from the Master to Remote. DIRECTION...
-
Page 10: A/D Conversion
Hexadecimal (Decimal) (3) OUTPUT IN AN ABNORMALITY When an abnormality such like CPU error, STOP, time-out occurs at the PLC, the output signal of the 61C is maintained as HOLD (no clearing output signal, keeping the value just before the abnormality). -
Page 11: Parameters Setting By Plc Program
(set for the number of MOV D connected modules.) T0 H0002 H0020 D13 K RST M1 *1. [Example] 11xx for model 61C-04 12xx for model 61C-08, 61C-163 14xx for model 61C-16 xx = 61C Station No. EM-6627 Rev.9 P. 11 / 12 MG CO., LTD. -
Page 12: Troubleshooting
13. LIGHTNING SURGE PROTECTION We offer a series of lightning surge protectors for protection against induced lightning surges. Please contact us to choose appropriate models. EM-6627 Rev.9 P. 12 / 12 MG CO., LTD. www.mgco.jp 5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN...
