- Page 1 Type 2871 Direct-acting 2-way proportional valve Operating instructions...
- Page 2 We reserve the right to make technical changes without notice. Technische Änderungen vorbehalten. Sous réserve de modifications techniques. © Bürkert Werke GmbH & Co. KG, 2024 Operating Instructions 2402/00_DEde_00815468 / Original DE...
-
Page 3: Table Of Contents
Type 2871 Type 2871 able of conTenTs OPERATING INSTRUCTIONS ........................5 Symbols ............................5 1.2 Definition of the term “device” ....................5 INTENDED USE ............................6 BASIC SAFETY INSTRUCTIONS ......................7 GENERAL NOTES...........................8 4.1 Contact addresses ........................8 4.2 Warranty ............................8 4.3 Information online ........................8 PRODUCT DESCRIPTION ........................9 5.1 Product structure .........................9 5.2 Type label (example) ........................10... - Page 4 Type 2871 CONTROL ELECTRONICS ........................15 9.1 PWM frequency ..........................15 MAINTENANCE AND TROUBLESHOOTING ..................16 10.1 Maintenance ..........................16 10.2 Troubleshooting .........................16 TRANSPORTATION, STORAGE, DISPOSAL ..................17 English...
-
Page 5: Operating Instructions
Refers to information in these operating instructions or in other documentation. ‣ Designates instructions to avoid danger. → Designates a procedure which you must carry out. Definition of the term “device” In these instructions, the term “device” refers to the proportional valve type 2871. English... -
Page 6: Intended Use
Type 2871 Intended use INTENDED USE The direct-acting proportional valve can be used as an actuator for process control. ▶ Do not use the device in explosive atmospheres. ▶ Do not use the device outdoors. ▶ Do not make any internal or external changes to the device. ▶ The prerequisites for safe and trouble-free operation are correct transportation, correct storage, installa- tion, commissioning, operation and maintenance. -
Page 7: Basic Safety Instructions
Type 2871 Basic safety instructions BASIC SAFETY INSTRUCTIONS These safety instructions do not take into account any unforeseen circumstances and events which occur during installation, operation and maintenance. The operator is responsible for observing the location-spe- cific safety regulations, also with reference to personnel. -
Page 8: General Notes
Type 2871 General notes GENERAL NOTES Contact addresses Germany Bürkert Fluid Control Systems Sales Centre Christian-Bürkert-Str. 13-17 D-74653 Ingelfingen Tel. +49 (0) 7940-10-91 111 Fax +49 (0) 7940-10-91 448 Email: info@burkert.com You can find the international contact addresses at country.burkert.com in the “Contact”... -
Page 9: Product Description
Product description PRODUCT DESCRIPTION The type 2871 direct-acting proportional valve is used as an actuator for process control loops. An elastomeric seat seal makes the valve close tight up to the orifice-specific nominal pressure (integrated shut-off function). The magnetic core of the valve is stored without friction, which results in outstanding positioning behaviour. -
Page 10: Type Label (Example)
Type 2871 Product description Type label (example) 2871 A 0,8 FKM VA G1/8 PN VAK - 12bar 24 V DC PWM 1400-1500 Hz 00123456 W11LA Item Item Type Circuit function Seat size Seal material Body material Permitted pressure range Current type, power consumption... -
Page 11: Technical Data
Type 2871 Technical data TECHNICAL DATA Standards and directives The device complies with the valid EU harmonisation legislation. In addition, the device also complies with the requirements of the laws of the United Kingdom. The harmonised standards that have been applied for the conformity assessment procedure are listed in the current version of the EU Declaration of Conformity/ UK Declaration of Conformity. -
Page 12: Installation
Type 2871 Installation INSTALLATION DANGER! Risk of injury due to high pressure and escaping medium. ▶ Switch off the pressure before working on the device or system. Vent or drain the pipes. ▶ For valve body with flange connection: check seals are seated correctly. NOTE! ▶ Do not uninstall proportional valve. -
Page 13: Screw In Valve In Pipe (Threaded Connection)
Type 2871 Installation Screw in valve in pipe (threaded connection) NOTE! ▶ Use an open-end wrench for installation. ▶ Do not use the coil as a lever arm. → Hold the proportional valve with an open-end wrench on the valve body. -
Page 14: Electrical Installation
Type 2871 Electrical installation ELECTRICAL INSTALLATION DANGER! Risk of injury from electric shock. ▶ Switch off voltage before working on the device or system. Secure against reactivation. ▶ Observe any applicable accident prevention and safety regulations for electrical devices. Risk of injury from improper installation. ▶ Only trained technicians may perform installation work. -
Page 15: Control Electronics
▶ Set correct PWM frequency (see “9.1 PWM frequency”). The type 8605 control electronics (rail variant) is suitable for controlling the type 2871 proportional valve. The control electronics can be combined with all variants of the proportional valve (strand or plug). -
Page 16: Maintenance And Troubleshooting
Type 2871 Maintenance and troubleshooting MAINTENANCE AND TROUBLESHOOTING 10.1 Maintenance The valve operates maintenance-free under normal conditions. 10.2 Troubleshooting Check in case of faults: • Port connections • Operating pressure within the permissible range • Power supply and valve control... -
Page 17: Transportation, Storage, Disposal
▶ Store the device in a dry and dust-free location. Permitted storage temperature: –20…+70 °C Environmentally friendly disposal ▶ Follow national regulations regarding disposal and the environment. ▶ Collect electrical and electronic devices separately and dispose of them as special waste. Further information at country.burkert.com. English...
