◎The cuff is a consumable. Calculate by measuring 6 times a day(3 times
each morning and evening), the service life of the cuff is about 2 year.
◎In order to correctly measure blood pressure, please replace the cuff
(using our experimental conditions)
◎If the cuff leaks, please contact our company to buy a new one. The
in time.
cuff purchased separately does not include the airway tube plug. When
replacing, please do not throw the airway tube plug away, install it on the
new cuff.
Note
When the product and accessories described in this manual are about to
exceed the period of use, they must be disposed according to relevant
product handling specification. If you want to know more information,
please contact our company or representative organization.
*The device will automatically turn off after two minutes in which there
is no operation to the device, even if you forget to turn the power off.

CHAPTER 3 EXTERNAL INTERFACES

Note
When removing NIBP cuff, please take plug at the front of the windpipe
to pull out.
1 @Cuff socket( is cuff identifier)
Left side
2 @The right side of the device has a USB port. USB socket(
identifier)
Right side
3 @The rear side of the device has a power adapter socket. Power adapter
socket( is power socket identifier)
Note
All analog and digital equipment connected to this device must be cer-
tified to IEC standards(such as IEC60950: Information technology equip-
ment-Safety and IEC60601-1: Medical electrical equipment-Safety), and
all equipment should be connected to in accordance with the require-
ment of the valid version of the IEC60601-1-1 system standard. The per-
son connecting the additional equipment to the signal input and output
port is responsible for whether the system complies with the IEC60601-1
standard.
CHAPTER 4 BATTERY/AC ADAPTER INSTALLATION
The product can use battery or AC adapter as power source.
①
1 @Demount the battery cover in the direction of the arrow.
is USB
2 @Install "AA" batteries according to
3 @Slide to close the battery cover.
Icon " ": the batteries power will exhaust. Replace with four new bat-
teries (the same sort) at the same time. Test while low power may cause
data deviation and other problems.
Turn the unit off before replacing the batteries.
Note
When the battery reaches the end of its life, or if the battery is found
to have odor, deformation, discoloration or distortion, stop using the
battery and dispose of the used battery in accordance with local regula-
Rear view
②
4.1 Battery Installation
polarities.
6
