ENGLISH URINE ANALYZER Contec Medical Systems Co., Ltd. User Notice 1. Thanks for purchasing Urine Analyzer! Please read the User Manual carefully before using this product. The User Manual which describes the operating procedures should be followed strictly. 2. This manual detailed introduce the steps must be noted when using the pro- duct, operation which may result in abnormal. - Page 3 ENGLISH upgrades, the information contained in this manual is subject to change without notice. Our company reserves the final elucidative right. Meaning of symbol Note : Tips, advice and suggestions. Warning : Warnings must be complied strictly to ensure that the Urine Analyzer can operation normally and the test result are correct and true.
-
Page 4: Table Of Contents
ENGLISH Summary Urine Analyzer ................... 27 User Notice ..................27 Statement ................... 27 Chapter 1 Overview ................30 1.1 Summarization................30 1.2 Precautions for Use ..............30 1.3 Technical Specification ..............31 1.4 Principle ..................32 Chapter 2 Installation ............... 33 2.1 Operation Environment.............. -
Page 5: Chapter 1 Overview
ENGLISH CHAPTER 1 OVERVIEW 1.1 Summarization Urine test is the most common method for checking disease in clinical test, and checking with urine test strip is the most effective method. urine test strip and urine sample produce a chemical reaction, the color of each test color-area will change after reaction, the corresponding test results can be obtained according to the color change. -
Page 6: Technical Specification
ENGLISH Please don’t use the accessories not provided by manufacture. Please don’t use the analyzer in condition that the test strip is expired or the device is damaged. Please transport, install and operate the analyzer following the User Manual. To ensure the accuracy, the operation temperature should be in range of 10°C~30°C, if exceeds this range, place the analyzer in required environment for 20~30 minutes before using. -
Page 7: Principle
ENGLISH Built-in rechargeable lithium battery 3.7V Power supply Host computer: DC 5V, 1A Adapter: AC 100V~240V, 50/60Hz Test range Refer to Grads Table in appendix Temperature: 10°C~30°C Relative humidity: ≤80% Operating environ- Atmospheric pressure: 76kPa~106kPa ment Away from the strong electric field (magnetic field), avoid direct sunlight Operating frequency: 2.4 GHz ISM band Operating Range: 2402 MHz - 2480 MHz... -
Page 8: Chapter 2 Installation
ENGLISH be measured, secondary wavelength is used to eliminate the influence of back- ground light or other stray light. The reflectance R test strip of test strip block: R test strip = Tm (the reflection intensity of the test strip to the measured wave- length)/Ts (the reflection intensity of the test strip to the reference wavelength) The reflectance R blank of blank block: R blank = Cm (reflection intensity of blank to measured wavelength)/Ts (reflection... - Page 9 ENGLISH 2.3.1 Front View Figure 2-1 Front view 1. LCD display: man-machine conversation window. 2. Micro USB socket: AC adapter power supply socket, interface of data tran- smission. 3. Keyboard: 5-key touch control keyboard, operate the analyzer with the buttons. 4.
-
Page 10: Power Supply
ENGLISH 1. Battery cover: it's need to open the battery cover when install and remove the lithium battery; 2. Reset key: if necessary, press this button to reset the urine analyzer. 2.4 Power Supply The device can use the built-in rechargeable battery as power supply. Connect the urine analyzer to the AC adapter when the built-in battery power is low or it needs to use the external power. -
Page 11: Power On
ENGLISH Confirm the current operation; In the main interface, OK button press this button to start test. In the main interface, long press this button to move Up direction the tray up; in the menu interface, press this button to button move the cursor up;... -
Page 12: Start Test
ENGLISH nual to resolve abnormities. If abnormalities are still not resolved, please contact the dealer or manufacturer. When the device prompts to calibrate the clock after the self-test is completed, users need to set time themselves. 3.3 Start Test Preparation before test: •... -
Page 13: Power Off
ENGLISH 4. Measurement is completed, display and store the test result. As Figure 3-3. Note • The sample number starting from 1 after the first power-on every day, after testing 1 sample, the sample number automatically add 1. After power on again the same day, the sample number starting from the latest sample number. -
Page 14: Setup Menu
ENGLISH Note Don't directly unplug/ plug the paper tray with hand to avoid damages of me- chanical structure. 3.5 Setup Menu Figure 3-4 Menu Figure 3-4 shows the device menu interface, it includes historical records, unit, clock, language, factory settings. Select menu option through direction button , press OK button to enter next submenu, press the menu button in any interface to return to the previous interface. - Page 15 ENGLISH All records Enter the all records query interface, each page shows 10 historical data at most, user can page to see more historical records through direction button , after selecting a record, press OK button to see the corresponding record.
- Page 16 ENGLISH to save the modification of the current item and enter the next modification, after completing modifications in turn, press OK button to complete all modifi- cations, the system automatically saves the new date and time, and exit to the device setup interface.
- Page 17 ENGLISH Figure 3-8 Factory settings Adjust sensitivity Adjust the sensitivity for the currently selected test strip. During using, the sensitivity can be adjusted when the user wants to increase or decrease the sensitivity of the analyzer. When you set the sensitivity, must be careful, a valid setting is recommended, you can use urine quality control materials or homemade known content quality control substitutes.
- Page 18 ENGLISH Figure 3-9 Adjust sensitivity Select the item which need modified, enter the sensitivity adjusting menu of each grads in this item, as shown in Figure 3-10. Figure 3-10 Adjust sensitivity Press direction button to select grads value which need modified, press OK button to enter the modification of current grads value, then modify the corresponding value through direction button...
-
Page 19: Chapter 4 Maintenance
ENGLISH cause detection errors. • After adjusting, the sensitivity value of the test item remains the same size and sequence as before. Sleep time The device is set to enter the sleep state when there is no operation. Under sleep state, the display is turned off, press any button can restore to the working state at this time. -
Page 20: Dismantle And Install The Paper Tray
ENGLISH 4.2 Dismantle and Install the Paper Tray Dismantle and install the paper tray according to the following steps: Under the main interface, long press the direction button for 2 seconds to make the paper tray back to the device storehouse, then long press the direction button for 2 seconds again to make the paper tray out of the device. -
Page 21: Disinfection
ENGLISH Please do not contact the calibration comparator block with NaOH. 4.4 Disinfection 1. According to one of the following three methods to configure disinfectant: • 2% glutaraldehyde solution; • 0.05% sodium hypochlorite solution -----1:100 dilution: add 1mL sodium hypochlorite solution(concentration:5%) to 99ml water; •... -
Page 22: Appendix
ENGLISH Appendix Grads Table Grads International Conventional Item code Special unit code unit unit Norm 3.3umol/l 0.2mg/dl 33umol/l 2mg/dl 66umol/l 4mg/dl 131umol/l 8mg/dl 10/ul 0.03mg/dl 25/ul 0.08mg/dl 50/ul 0.15mg/dl 250/ul 0.75mg/dl 0umol/l 0mg/dl 17umol/l 1mg/dl 50umol/l 3mg/dl 100umol/l 6mg/dl 0mmol/l 0mg/dl 1.5mmol/l 15mg/dl... - Page 23 ENGLISH 18umol/l 0.12mg/dl 1.005 1.005 1.005 1.010 1.010 1.010 1.015 1.015 1.015 1.020 1.020 1.020 1.025 1.025 1.025 1.030 1.030 1.030 0mmol/l 0mg/dl 0.6mmol/l 10mg/dl 1.4mmol/l 25mg/dl 2.8mmol/l 50mg/dl 5.6mmol/l 100mg/dl 0.01g/l 1mg/dl 0.15g/l 15mg/dl 0.9mmol/L 10mg/dl 50mg/ 4.4mmol/L dl 100mg/ 8.8mmol/L dl 200mg/dl 17.7mmol/L...
- Page 24 Disposal: The product must not be disposed of along with other domestic waste. The users must dispose of this equipment by bringing it to a specific recycling point for electric and electronic equipment. GIMA WARRANTY TERMS The Gima 12-month standard B2B warranty applies...
