- Page 1 Thermostatic shower valve with adjustable rigid riser VADO Wedmore Road, Cheddar, Somerset, England BS27 3EB tel 01934 744466 fax 01934 744345 www.vado.com INSTALL ATION GUIDE sales@vado.com Version 1, 1-6-22...
-
Page 2: General Installation
Important - please read Notes Please read these instructions carefully before starting installation and keep for future reference. Remove all packaging and check the product for missing parts or damage before starting installation. Any alterations made to this product and fittings may infringe water regulations and will invalidate the guarantee. -
Page 3: Contents Of Packaging
Notes Contents of Packaging Valve Installation guide & User manual Accessory box 3 Accessory box 1 Quick fit connectors Covers Hex key Filter/washers Offset connectors Accessory box 2 Wall bracket Wall bracket Cover Wall plugs x 11 Screws x 11... - Page 4 Contents of Packaging Commissioning The valve has been factory set under balance pressures and hot water supply at 65°C. When your specific operating conditions are significantly different from the above, the temperature of the water may vary from the setting. When the difference is too great, you can adjust the calibration of the valve to suit individual requirements of the installation: 1.
- Page 5 Installation - Shower hose Dimensions Shower head 360mm Make sure there is a rubber washer in Riser arm place in the shower head and screw onto Shower head the riser arm. Washer Ø250mm Handset Place one of the rubber washer into the 69-90mm cone end of the hose and screw to the handset.
- Page 6 Installation - Quick guide Installation - Riser rail Place the bracket against the wall. Make sure that the riser is vertical, mark the three fixing holes in the wall bracket with a pencil. Wall bracket Level Warning! Please check for any Wall bracket hidden cables and pipes before drilling holes in the wall.
- Page 7 Installation - Riser rail Installation - Quick guide You can adjust the height of the riser to suit your requirements. Riser arm Loosen the securing nut and carefully Securing nut slide the riser arm until you reach the required position, then re-tighten the nut. Riser bracket 150mm Riser...
- Page 8 Installation - Quick guide Installation - Quick fit connectors Slide on the olive, screw on and tighten the nut. Before installation flush through the pipe work to ensure removal of debris, turn off the water supply. Olive Covers Locking nuts Rubber filter/washer Screw the covers on each connector.
- Page 9 Installation - Quick fit connectors Installation - Quick guide Note: Make sure that the valve is positioned to allow room for the riser rail to be fitted later (see dimensions on page 5). Prepare the wall with 2 copper pipes at 150mm centres.
- Page 10 Installation - Quick guide Installation - Offset connectors Note: There are two options for installing your valve, using offset connectors (below) or quick fit connectors (see page 12). Cold Offset connector Rubber ½” connector filter/washer Locking nuts Offset connector Cover Riser rail connection Before installing your new mixer, flush through the pipe work to ensure removal of...
