- Page 1 SG-116 中文 Version 1...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 3: Important Note
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. Unplug this apparatus during lightning storms or when unused for long periods of time. - Page 4 For United States: Cautions to the user The changes or modifications not expressly approved by the party responsible for compliance could void the users authority to operate the equipment. The equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to part 15 of the FCC Rules.
- Page 6 Controls Power and AM/FM band switch Volume Control Speaker Dial scale Dial indicator Tuning Control AC power cord socket 12V DC input socket (ideal for vehicles/boats) Headphone socket REC out socket Aux in socket External/Internal antenna switch F-type external antenna terminal AM external antenna terminal (USA version only) Tuning LED indicator...
-
Page 7: Power Your Radio
Power your radio AC operation Before you plug the AC cord into the radio, be sure the AC voltage is correct. Insert the plug on the end of the supplied power cord into the AC power socket on the back of the radio. DC operation For outdoors use, you can power the radio by using 12V DC input socket from a DC power supply (example, from the power supply of... -
Page 8: Operating Your Radio - Fm
Operating your radio FM 1. Connect the Antenna The radio comes with built-in AM/FM antenna. To improve FM reception, insert the end of the supplied FM wire antenna into the F-type antenna terminal and adjust the wire for best reception. A 75 ohm coaxial cable of outdoor antenna may also be attached to the terminal. -
Page 9: Headphone Use
Operating your radio AM 1. Connecting the antenna The radio comes with built-in AM antenna which should be enough for normal listening. To improve the AM reception, you may connect the outdoor AM antenna with AM antenna terminal (USA version only). -
Page 10: Specifications
REC out socket The radio can be used as a separate tuner by connecting this input to Hi-Fi system (amplifier) or using this input to make recording in mono from audio program. Specifications Frequency Coverage: FM 87.50 - 108 MHz 520 - 1710 kHz AC 120V/60 Hz/25W (USA version) AC 230V/50 Hz/25W (European version) - Page 11 Aux in socket: 3.5 mm dia. Stereo jack. Input sensitivity: IN 300mV Output 7W @100Hz Input impedance: 47 Kohm REC OUT: output impedance: 2.2Kohm DC IN: 12V/1A center pin positive (operational voltage 9-14V) External diameter: 5.5mm Internal diameter: 2.0 mm Accessories: FM F-terminal antenna wire AC Power Cord...
