- Page 3 This preventive maintenance step must be completed to ensure your package gives you 61-NV2 SINGLE GRIP-LOCK LADDER RACK ASM FOR NISSAN NV200 VAN ADRIAN STEEL COMPANY WWW.ADRIANSTEEL.COM 906 JAMES STREET ADRIAN, MI 49221 800-677-2726 44923 17830 Publication Number: Revision Level:...
- Page 4 MEASURING TAPE STOP AND/OR WRENCHES ADDITIONAL TOOLS MAY BE NEEDED FOR THIS INSTALLATION AND THEY WILL BE IDENTIFIED IN THE STEPS THAT FOLLOW. ADRIAN STEEL COMPANY WWW.ADRIANSTEEL.COM 906 JAMES STREET ADRIAN, MI 49221 800-677-2726 44923 17830 Publication Number: Revision Level:...
- Page 5 61-NV2 G/L LADDER RACK Assembly/Install Instructions BAG61-NV2 FASTENER BAG FOR 61-NV2 LADDER RACK ADRIAN STEEL COMPANY WWW.ADRIANSTEEL.COM 906 JAMES STREET ADRIAN, MI 49221 800-677-2726 44923 17830 Publication Number: Revision Level: ECN Release:...
- Page 6 61-NV2 G/L LADDER RACK Assembly/Install Instructions BAG37291 ACCESSORY BAG FOR 61-NV2 ADRIAN STEEL COMPANY WWW.ADRIANSTEEL.COM 906 JAMES STREET ADRIAN, MI 49221 800-677-2726 44923 17830 Publication Number: Revision Level: ECN Release:...
- Page 7 SLIDE WEAR INSERT INTO CROSS BOW UNTIL INNER HOLES LINE UP ON EACH END. INSERT (1) 36496-0 END CAP INTO EACH END OF EACH BOW ASM. 44420 WEAR INSERT 44417 CROSS BOW ADRIAN STEEL COMPANY WWW.ADRIANSTEEL.COM 906 JAMES STREET ADRIAN, MI 49221 800-677-2726 44923 17830 Publication Number:...
- Page 8 SAME AS FRONT. PO- SITION FRONT AS SHOWN. REAR BOW FRONT POSITION WILL BE DETERMINED BY THE OUTER RAIL. SEE NEXT STEP. ADRIAN STEEL COMPANY WWW.ADRIANSTEEL.COM 906 JAMES STREET ADRIAN, MI 49221 800-677-2726 44923 17830 Publication Number: Revision Level: ECN Release:...
- Page 9 HEX SCREW, 2 PLCS TORQUE TO 10 FT.LBS 25340-0 LATCH ASM FAS0830 5/16-18X1.25 HEX SCREW FOR LATCH TORQUE TO 10 FT.LBS ADRIAN STEEL COMPANY WWW.ADRIANSTEEL.COM 906 JAMES STREET ADRIAN, MI 49221 800-677-2726 44923 17830 Publication Number: Revision Level: ECN Release:...
- Page 10 FAS0588 5/16 LOCK WSHR 35335-0 SLIDES PREVIOUSLY INSTALLED FAS0552 5/16 FLT WSHR FAS0552 FLT WSHR FAS0588 LK WSHR FAS0830 HEX SCR ADRIAN STEEL COMPANY WWW.ADRIANSTEEL.COM 906 JAMES STREET ADRIAN, MI 49221 800-677-2726 44923 17830 Publication Number: Revision Level: ECN Release:...
- Page 11 FASTENER. TORQUE TO 10 FT LBS FAS0588 LK WSHR FASO552 WSHR DOUBLE-CHECK ALL FASTENER LOCATIONS TO BE SURE THAT ALL FASTENERS ARE TIGHTENED TO SPECIFICATIONS! ADRIAN STEEL COMPANY WWW.ADRIANSTEEL.COM 906 JAMES STREET ADRIAN, MI 49221 800-677-2726 44923 17830 Publication Number: Revision Level: ECN Release:...
