About This Guide

The material in this document describes how to maintain the B125 OEM GNSS board using GRIL commands and
TRU software.
Manual Conventions
This manual uses the following conventions:
Convention Description
Bold Menu, or drop-down menu selection
Name of a dialog box or screen
Button or key commands
User supplied text or variable
Mono
Italic Reference to another manual or help document
Further information to note about system configuration, maintenance, or setup.
Supplementary information that can have an adverse affect on system operation, system
performance, data integrity, measurements, or personal safety.
Notification that an action has the potential to result in system damage, loss of data, loss of
warranty, or personal injury.
Intended Audience and Qualification
This guide is intended for system engineers, system designers, and programmers who are integrating the B125
board to their products to achieve GNSS positioning capabilities.
It is highly recommended that installation, commissioning, use, and maintenance of the B125 board is
preformed by personnel trained in electronics.
Supported Hardware and Firmware Versions
Maintenance procedures given in this guide correspond to the following hardware revisions and firmware
versions:
•
B125 board hardware revision 4.6.
•
GNSS firmware version 5.1p1
The configuration procedures and sample outputs in this guide are based on the functionality of the B125
running firmware 5.1p1. Your board might function differently depending on the firmware version you are
running.
Additional Documentation
The following documentation can be useful while working with the B125 board:
•
B125 Hardware Integration Guide
operation, and specifications of the B125 board.
