3. Specify the setting for the FTP server. You need to enter a TCP port number; the board's FTP server will
listen for FTP client connections on that port. The other FTP server settings include connection timeout,
username, and password.
GRIL Command/TRU Controls
%%set,/par/net/ftp/port,x...x
Receiver Settings>Network (FTP)>FTP Port
%%set,/par/net/ftp/timeout,1...2
Receiver Settings>Network (FTP)>Timeout
%%set,/par/net/ftp/login,xxxx.xxxx.xxxx.xxxx
Receiver Settings>Network (FTP)>Login
%%set,/par/net/ftp/passwd,x...x
Receiver Settings>Network (FTP)>Password
4. After you configure the FTP server settings, reset the board to activate them. You can do this by one of the
following methods:
•
Sending the command %%set,/par/reset,yes.
•
Powering cycle the board.
•
Clearing the NVRAM.
Once the settings are activated, the B125 stores them in the permanent area of NVRAM allowing
them to leave intact after you clear the NVRAM or reset all parameters to default.

Displaying Firmware Version

Background
Each B125 board contains firmware, which controls and executes all operations in the board. All B125 boards
in your project must be loaded with the same firmware version. Use the latest firmware version to ensure your
board(s) have the most recent updates. If a new version of the firmware is released, you can load new firmware
to the board using TRU. For details, see
Typical Use
You may need to know the firmware version of the B125 board in certain situation, such as troubleshooting with
TPS technical support or determining which new firmware to upload.
Procedure
Display the firmware version currently running on the board.
%%print,/par/rcv/ver/main
Displaying Firmware Version
TCP port number. The default is 21.
Example: %%set,/par/net/ftp/port,21 instructs the FTP server to listen
for FTP connections on port 21.
Connection timeout. Specify the amount of time, in seconds, the FTP
31
-1
server will wait for data before terminating FTP connections. The default
is 600 seconds.
Example: %%set,/par/net/ftp/timeout,300 instructs the FTP server to
terminate the FTP connections after 5 minutes of no communications.
Username. Specify the username required by the FTP server for a client
to connect. The default is "topcon". The username is case sensitive and
can contain up to 31 alphanumeric characters.
Example: %%set,/par/net/ftp/login,"FTPclient1".
Password. For security reasons, it is recommended to protect access to
your FTP server using password. If the password is specified, the clients
have to enter it to access the FTP server. The default is "topcon". The
password is case sensitive and can contain up to 15 alphanumeric
characters.
Example: %%set,/par/net/ftp/passwd,"Admin"
"Updating Firmware" on page
P/N: 1020443-01
Description
9.
4
