Summary of Contents for KoolMore KM-PHR-45C
- Page 2 Stay informed with the latest information for your KoolMore KeepWarm Appliance. If you need any assistance or have questions, our customer support team is here to help.
- Page 4 Dear KoolMore users: We appreciate your choice of the KoolMore medical cooler. We urge you to go through the subsequent details for a comprehensive grasp of the User Manual, which will aid in safe utilization of this device and minimize risks to both individuals and objects.
- Page 5 Warning 1. Use a grounded outlet to prevent shocks. If not grounded, get technicians to set up a grounding wire. 2. Position the cooler on a stable, level surface to avoid toppling or injuries. 3. When extending the power cord, maintain a thickness >2 mm² and a length ≤3 m (9.8 feet). 4.
- Page 6 • Protect the refrigerator's circuitry. • Use only approved appliances inside the refrigerator. Precautions for use: • Confirm cabinet temperature before adding items; don't exceed 1/3 volume. • Displayed temperature varies from actual; it stabilizes over time. • Use the testing hole correctly; ensure thermal insulation when plugging back. •...
- Page 7 Product Handling: • When transporting the pharmacy refrigerator, ensure it is moved with care, using the handcart method shown in the accompanying image, cushioning the unit appropriately. • Upon arrival at the desired location, remove all packing materials and the bottom cushion. Relocate the refrigerator to its final placement within the house or facility.
- Page 8 Installation Site • It's crucial not to place the device in cramped or confined spaces. Choose a location that ensures easy access and minimizes the chance of goods blocking airflow or causing storage issues. • The installation location should be stable and free from flammable materials, ensuring the appliance remains upright during operation and minimizing hazards.
- Page 9 2. Verify the contents by counting the included accessories. Compare the items you have to the contents listed in the packing list. Should you find any discrepancies or missing items, make sure to contact the after-sales service as soon as possible. 3.
-
Page 10: Warning And Precautions
Initial Setup: Once the equipment has been positioned, leveled, and cleaned, ensure it remains untouched for at least 24 hours before you turn it on. This step ensures optimal functioning. Power Connection: Connect the power cord to a socket that matches the required specifications and can handle the device's load. - Page 11 Temperature Range: This product is specifically designed as a medical refrigerator, operating within a temperature range of 35.6°F-46.4°F. It is essential to verify that the environment within the refrigerator aligns with the storage needs of the items. This precaution ensures the safety and integrity of the stored items and prevents potential financial setbacks due to damages.
- Page 12 Button(s) Function - Display current temperature set point (St) when held for 3s (if unlocked).<br>- Save and exit settings when held for 3s (in setting status). - Toggle between parameters.<br>- Increase selected parameter ▲ (UP) value. - Toggle between parameters.<br>- Decrease selected parameter ▼...
-
Page 14: Alarm Description
General Menu Parameters: • Brie y press the "SET" button to con rm any changes made. • Continue adjusting other parameters as needed. • To save and nalize settings, hold the "SET" button for three seconds. Time Setting (Optional USB): •... - Page 15 Warning • Always disconnect the power before conducting any repairs or maintenance to ensure safety against electrical shock or potential injuries. • Be cautious about inhaling any medications or suspended particles nearby to avoid health risks. Note • Avoid sprinkling water directly on the unit, as this could affect the electrical components and induce rust.
- Page 16 • Any discarded device should be allocated to speci ed zones, ensuring they remain out of children's reach to prevent potential hazards. Fault Troubleshooting Method Refrigerator not working - Verify the input power supply meets the requirements. - Check if the plug and socket are in good contact. - Inspect if the input and control lines are faulty.
-
Page 17: Specification
Specification Details Name Medical Refrigerator Model KM-PHR-45C External dimensions (WD H) (inches) 24.2-23.4-31.9 Internal dimensions (WD H) (inches) 19.9-18.4-24.4 Effective volume 4.45 cu.ft. (approx.) Door Transparent glass door Foaming agent Cyclopentane Shelf Plastic-dipped steel wire shelf (3 pcs.) Load-bearing capacity per shelf 52.9 lbs. - Page 18 （optional） USB Panel （ Optional） LED lamp Control sensor Temperature Master control Alarm Terminal block Door heating Switch Temperature sensor Controller Refrigeration fan Normally open board Switching Power Door heating Common wire Supply Door Switch Defrost sensor AC 115V...
- Page 19 At its sole discretion, Koolmore Supply Inc. may decide to replace the product. In such an event, your replace- ment appliance will carry the warranty for the remaining term of the original unit's warranty period.
