  • Page 1 Touch Panels with TFT-Display User manual UM EN EL PPCXX 1000...
  • Page 2 2017-02-14 Designation: UM EN EL PPCXX 1000 Revision: Order No.: — This user manual is valid for: Designation Order No. EL PPC5.7 1000 2404318 EL PPC7 1000 2701481 EL PPC9 1000 2701482 EL PPC10S 1000 2400232 EL PPC12S 1000 2400233...
  • Page 3 The receipt of technical documentation (in particular user documentation) does not consti- tute any further duty on the part of Phoenix Contact to furnish information on modifications to products and/or technical documentation. You are responsible to verify the suitability and intended use of the products in your specific application, in particular with regard to observ- ing the applicable standards and regulations.

  • Page 4: Table Of Contents

    RS-422 / RS-485 (X14) ................ 46 4.3.2 RS232 (X15) ..................49 Field Bus Interfaces ..................... 51 4.4.1 CAN (X12, X13) ................... 51 Memory Card....................... 54 4.5.1 Inserting the memory card ..............54 4.5.2 Ejecting the memory card ..............54 8584_en_04 PHOENIX CONTACT...
  • Page 5 Changing the Battery ................57 5.4.2 Battery Disposal ................... 58 Technical Data .........................60 General........................ 60 EL PPC5.7 1000 ....................62 EL PPC7 1000 ..................... 63 EL PPC9 1000 ..................... 64 EL PPC10S 1000....................65 EL PPC12S 1000....................66 EL PPC12 1000 ....................67 EL PPC15S 1000....................

  • Page 6: Important Notes

    The user manual, in particular the safety notes, must be observed by all personnel working with the device. – Observe the accident prevention rules and regulations that apply to the operating site. – Installation and operation must only be carried out by qualified and trained personnel. 8584_en_04 PHOENIX CONTACT...

  • Page 7: Intended Use

    Qualified electricians or persons instructed by them, who are familiar with applicable standards and other regulations regarding electrical engineering and, in particular, the relevant safety concepts. – Qualified application programmers and software engineers, who are familiar with the safety concepts of automation technology and applicable standards. PHOENIX CONTACT 8584_en_04...

  • Page 8: Installation And Commissioning

    Mounting the device using a mounting bracket Insert the mounting brackets into the appropriate openings (figure 1) and pull the brack- ets downwards until they lock in place (2). Fasten the device into position using the threaded pins (3). 8584_en_04 PHOENIX CONTACT...

  • Page 9: Front Panel Dimensions

    EL PPCXX 1000 2.2.1 Front Panel Dimensions 2.2.1.1 EL PPC5.7 1000 Figure 2-2 Front panel (dimensions in mm) PHOENIX CONTACT 8584_en_04...
  • Page 10 Installation and Commissioning 2.2.1.2 EL PPC7 1000 Figure 2-3 EL PPC7 1000 8584_en_04 PHOENIX CONTACT...
  • Page 11 EL PPCXX 1000 2.2.1.3 EL PPC9 1000 Figure 2-4 EL PPC9 1000 PHOENIX CONTACT 8584_en_04...
  • Page 12 Installation and Commissioning 2.2.1.4 EL PPC10S 1000 Figure 2-5 EL PPC10S 1000 8584_en_04 PHOENIX CONTACT...
  • Page 13 EL PPCXX 1000 2.2.1.5 EL PPC12S 1000 Figure 2-6 EL PPC12S 1000 PHOENIX CONTACT 8584_en_04...
  • Page 14 Installation and Commissioning 2.2.1.6 EL PPC12 1000 Figure 2-7 EL PPC12 1000 8584_en_04 PHOENIX CONTACT...
  • Page 15 EL PPCXX 1000 2.2.1.7 EL PPC15S 1000 Figure 2-8 EL PPC15S 1000 PHOENIX CONTACT 8584_en_04...
  • Page 16 Installation and Commissioning 2.2.1.8 EL PPC15 1000 Figure 2-9 EL PPC15 1000 8584_en_04 PHOENIX CONTACT...

  • Page 17: Mounting Cutout

    EL PPCXX 1000 2.2.2 Mounting Cutout 2.2.2.1 EL PPC5.7 1000 ±0,5 Figure 2-10 Mounting cutout (dimensions in mm) A Mounting Cutout B Front Panel PHOENIX CONTACT 8584_en_04...
  • Page 18 Installation and Commissioning 2.2.2.2 EL PPC7 1000 ±0,5 Figure 2-11 EL PPC7 1000 A Mounting Cutout B Front Panel 8584_en_04 PHOENIX CONTACT...
  • Page 19 EL PPCXX 1000 2.2.2.3 EL PPC9 1000 ±0,5 Figure 2-12 EL PPC9 1000 A Mounting Cutout B Front Panel PHOENIX CONTACT 8584_en_04...
  • Page 20 Installation and Commissioning 2.2.2.4 EL PPC10S 1000 ±0,5 Figure 2-13 EL PPC10S 1000 A Mounting Cutout B Front Panel 8584_en_04 PHOENIX CONTACT...
  • Page 21 EL PPCXX 1000 2.2.2.5 EL PPC12S 1000 Figure 2-14 EL PPC12S 1000 A Mounting Cutout B Front Panel PHOENIX CONTACT 8584_en_04...
  • Page 22 Installation and Commissioning 2.2.2.6 EL PPC12 1000 Figure 2-15 EL PPC12 1000 A Mounting Cutout B Front Panel 8584_en_04 PHOENIX CONTACT...
  • Page 23 EL PPCXX 1000 2.2.2.7 EL PPC15S 1000 Figure 2-16 EL PPC15S 1000 A Mounting Cutout B Front Panel PHOENIX CONTACT 8584_en_04...
  • Page 24 Installation and Commissioning 2.2.2.8 EL PPC15 1000 ±0,5 Figure 2-17 EL PPC15 1000 A Mounting Cutout B Front Panel 8584_en_04 PHOENIX CONTACT...

  • Page 25: Side View, Mounting Depth

    EL PPCXX 1000 2.2.3 Side View, Mounting Depth 2.2.3.1 EL PPC5.7 1000 Figure 2-18 Side view, mounting depth (dimensions in mm) Mounting Bracket Threaded Pin Mounting Surface Thickness 1 mm to 6 mm Circumferential Seal Front Panel PHOENIX CONTACT 8584_en_04...
  • Page 26 Installation and Commissioning 2.2.3.2 EL PPC7 1000 Figure 2-19 EL PPC7 1000 standard / field bus device Mounting Bracket Threaded Pin Mounting Surface Thickness 1 mm to 6 mm Circumferential Seal Front Panel 8584_en_04 PHOENIX CONTACT...
  • Page 27 EL PPCXX 1000 2.2.3.3 EL PPC9 1000 Figure 2-20 EL PPC9 1000 standard / field bus device Mounting Bracket Threaded Pin Mounting Surface Thickness 1 mm to 6 mm Circumferential Seal Front Panel PHOENIX CONTACT 8584_en_04...
  • Page 28 Installation and Commissioning 2.2.3.4 EL PPC10S 1000 Figure 2-21 EL PPC10S 1000 standard / field bus device Mounting Bracket Threaded Pin Mounting Surface Thickness 1 mm to 6 mm Circumferential Seal Front Panel 8584_en_04 PHOENIX CONTACT...
  • Page 29 EL PPCXX 1000 2.2.3.5 EL PPC12S 1000 Figure 2-22 EL PPC12S 1000 standard / field bus device Mounting Bracket Threaded Pin Mounting Surface Thickness 1 mm to 6 mm Circumferential Seal Front Panel PHOENIX CONTACT 8584_en_04...
  • Page 30 Installation and Commissioning 2.2.3.6 EL PPC12 1000 Figure 2-23 EL PPC12 1000 standard / field bus device Mounting Bracket Threaded Pin Mounting Surface Thickness 1 mm to 6 mm Circumferential Seal Front Panel 8584_en_04 PHOENIX CONTACT...
  • Page 31 EL PPCXX 1000 2.2.3.7 EL PPC15S 1000 Figure 2-24 EL PPC15S 1000 standard / field bus device Mounting Bracket Threaded Pin Mounting Surface Thickness 1 mm to 6 mm Circumferential Seal Front Panel PHOENIX CONTACT 8584_en_04...
  • Page 32 Installation and Commissioning 2.2.3.8 EL PPC15 1000 Figure 2-25 EL PPC15 1000 standard / field bus device Mounting Bracket Threaded Pin Mounting Surface Thickness 1 mm to 6 mm Circumferential Seal Front Panel 8584_en_04 PHOENIX CONTACT...

  • Page 33: Connecting The Device

    Fit the wires with wire end ferrules and connect the wires to the socket strip. Plug the socket strip onto pin strip X1. Secure the socket strip in place with a screw-type locking to prevent it from slipping out. PHOENIX CONTACT 8584_en_04...

  • Page 34: Grounding

    Fit the stripped wires - depending on the type of device - with a slip-on sleeve or a ring cable lug. Plug the slip-on sleeve on the flat tab or mount the ring cable lug with the nut to the threaded bolt. Figure 2-27 Noiseless ground / protective ground 8584_en_04 PHOENIX CONTACT...

  • Page 35: Switching On

    Briefly press twice on the desktop icon. Press the button to start the cockpit before the progress bar is down. You can customize the language of the cockpit interface with the regional settings / lan- guage settings menu item. PHOENIX CONTACT 8584_en_04...
  • Page 36 Installation and Commissioning Press the button Language. Select the desired language. Confirm your selection with the green check. 8584_en_04 PHOENIX CONTACT...

  • Page 37: Identification

    WIN 7 PRO SP1 X64 - ENG OS41 Operating system WIN 7 PRO SP1 X86 - ENG OS62 Operating system WIN EMB STD 7P SP1 X64 - MUL OS64 Operating system WIN 10 IOT ENT LTSB x86 - MUL PHOENIX CONTACT 8584_en_04...
  • Page 38 Configuration OS65 Operating system WIN 10 IOT ENT LTSB x64 - MUL Options No options Options 1x RS232, 1x RS485 Options 1x RS232, 1x RS485, 2x CAN Software options No software option Software options PC WORX SRT 8584_en_04 PHOENIX CONTACT...
  • Page 39 EL PPCXX 1000 PHOENIX CONTACT 8584_en_04...

  • Page 40: Control And Display Elements

    NOTICE: Damage To protect the touch screen you can use special protection foils. You receive correspond- ing protection foils directly from Phoenix Contact. Display DANGER: Toxic If the display is damaged, avoid touching, swallowing or breathing in the liquids or gases...
  • Page 41 EL PPCXX 1000 PHOENIX CONTACT 8584_en_04...

  • Page 42: Interfaces Of The Device

    Interfaces of the Device Interfaces of the Device Figure 4-1 Rear view Slot for SD / SDHC Memory Card 2 x Ethernet (10/100/1000 MBit) 4 x USB (Host - Type A) Supply Voltage Threaded Bolt For Protective Grounding 8584_en_04 PHOENIX CONTACT...

  • Page 43: Ethernet

    Use a twisted pair cable of category 5 or 6 (CAT 5 or 6). Use twisted pair cable of category 6 for optimal transfer rate at 1000 Base-T. The maximum cable length is 100 m (328.084 feet). See the IEEE 802.3 standard for further information. PHOENIX CONTACT 8584_en_04...

  • Page 44: Diagnosis

    4.2.1 Cable For the specification of a suitable cable, please refer to the „Universal Serial Bus Specifi- cation“. NOTICE: Use industrial-suited USB cables with a length of maximally 2.5 m (8.202 feet). 8584_en_04 PHOENIX CONTACT...

  • Page 45: Serial Interfaces

    2 x Ethernet (10/100/1000 MBit) 4 x USB (Host - Type A) Supply Voltage Diagnostics LEDs (RS-422/RS-485) Termination Switch (RS-422/RS-485) Male Connector X14 (RS-422/RS-485) Diagnostics LEDs (RS-232) Male Connector X15 (RS-232) 10 Threaded Bolt For Protective Grounding PHOENIX CONTACT 8584_en_04...

  • Page 46: Rs-422 / Rs-485 (X14)

    T(B) Transmitted Data T(A) Transmitted Data R(A) Received Data R(B) Received Data Not Connected Not Connected Not Connected Not Connected NOTICE: The D-SUB connector strips must be shielded sufficiently. See chapter „Shielding D-SUB Connectors“ on page 55. 8584_en_04 PHOENIX CONTACT...
  • Page 47 Half-duplex (DTR active / on): The transmitter is activated during the transmission. On intermissions, the transmitter is highly resistive. The receiver is disabled during the transmission. The operating device does not receive the own transmit data at the receiver. PHOENIX CONTACT 8584_en_04...
  • Page 48 Diagnostics LEDs are located on the rear of the operating device. The diagnostic LEDs at the operating device have the following functions: Table 4-7 Functions of the RS-422 / RS-485 diagnostics LEDs Designation Color State Function Green Flashes Data transfer active Yellow Flashes Data transfer active 8584_en_04 PHOENIX CONTACT...

  • Page 49: Rs232 (X15)

    Function Not Connected Received Data Transmitted Data Not Connected Ground Not Connected Request to Send Clear to Send Not Connected NOTICE: The D-SUB connector strips must be shielded sufficiently. See chapter „Shielding D-SUB Connectors“ on page 55. PHOENIX CONTACT 8584_en_04...
  • Page 50 Diagnostics LEDs are located on the rear of the operating device. The diagnostic LEDs at the operating device have the following functions: Table 4-10 Functions of the RS-232 diagnostics LEDs Designation Color State Function Green Flashes Data transfer active Yellow Flashes Data transfer active 8584_en_04 PHOENIX CONTACT...

  • Page 51: Field Bus Interfaces

    Male Connector X13 (CAN2) 10 Termination Switch (CAN2) 11 Diagnostics LEDs (CAN2) 12 Diagnostics LEDs (RS-422/RS-485) 13 Termination Switch (RS-422/RS-485) 14 Male Connector X14 (RS-422/RS-485) 15 Diagnostics LEDs (RS-232) 16 Male Connector X15 (RS-232) 17 Threaded Bolt For Protective Grounding PHOENIX CONTACT 8584_en_04...

  • Page 52: Can

    A shielded twisted-pair cable complying with ISO 11898-2 must be used. NOTICE: The housing of the M12 connectors must be connected to the cable shield. A suitable cable with the designation „SAC-5P- 2,0-920/FS SCO“ is offerd by Phoenix Contact with article number 1518216. 8584_en_04 PHOENIX CONTACT...

  • Page 53: Can

    Green Node is operational Green Flashes Node is not operational µC Green Microcontroller inactive Green Flashes Microcontroller is operational slowly Green Flashes Microcontroller is operational slowly Requests of the host CPU are received and fast and processed PHOENIX CONTACT 8584_en_04...

  • Page 54: Memory Card

    4.5.2 Ejecting the memory card To remove, push the memory card into the operating device until it clicks. The memory card bounces when released automatically out of the operating device. Now you can remove the memory card. 8584_en_04 PHOENIX CONTACT...

  • Page 55: Shielding D-Sub Connectors

    The shield must be folded back into a flat position over the cable sheath. When fastening the cable with the cable clip, as much of the shielding as possible must be in contact with the housing and sufficient strain relieve must be ensured. PHOENIX CONTACT 8584_en_04...

  • Page 56: Maintenance And Servicing

    20 seconds. The higher the ambient temperature, the longer the regeneration takes. Battery The minimum battery life is 5 years, even under unfavorable operating conditions. We recommend you change the battery approximately every 4 years as part of the regular maintenance work. 8584_en_04 PHOENIX CONTACT...

  • Page 57: Changing The Battery

    NOTICE: Damage Batteries must only be changed by authorized and trained experts! NOTICE: Damage For changing the battery you may only use replacement batteries of Phoenix Contact. NOTICE: Damage Electrostatic discharge can damage electronic components. Observe the ESD protective measures! After a battery change, you must set the date and time newly! Remove the connector of the supply voltage.

  • Page 58: Battery Disposal

    NOTICE: Damage To prevent short circuitry in the collection boxes, insulate the poles of each battery with insulation tape or put each single battery into a plastic bag. 8584_en_04 PHOENIX CONTACT...
  • Page 59 EL PPCXX 1000 PHOENIX CONTACT 8584_en_04...

  • Page 60: Technical Data

    Max. output current: 100 mA per output Zentraleinheit Zentraleinheit Intel® Atom™ E3845 AMD Embedded G-Series Taktfrequenz 1,91 GHz Quad-Core 1 GHz Single / Dual-Core Connection Method Female and male connector strip Phoenix MINI COMBICON, 3 pin RJ45 female connector USB female connector A 8584_en_04 PHOENIX CONTACT...

  • Page 61: Standards

    NOTICE: Radio Interference This is a class A device. This device may cause radio interference in residential areas. In this case, the user may be required to introduce appropriate countermeasures, and to bear the cost of same. PHOENIX CONTACT 8584_en_04...

  • Page 62: El Ppc5.7 1000

    Technical Data EL PPC5.7 1000 Display Size (diagonal) in cm (inch) 14.48 (5.7) Type TFT (color) Resolution (pixels) 640 x 480 Colors 262144 Viewing angle (left / right / up / down) 65 / 65 / 55 / 52 in °...

  • Page 63: El Ppc7 1000

    Front: IP65 / Enclosure Type 4X (indoor use only) Rear: IP20 Total weight About 1300 g Approvals Intel® Atom™ E3845: UL / cUL Class I, Division 2, Groups A, B, C and D AMD Embedded G-Series: UL / cUL PHOENIX CONTACT 8584_en_04...

  • Page 64: El Ppc9 1000

    Front: IP65 / Enclosure Type 4X (indoor use only) Rear: IP20 Total weight About 1600 g Approvals Intel® Atom™ E3845: UL / cUL Class I, Division 2, Groups A, B, C and D AMD Embedded G-Series: UL / cUL 8584_en_04 PHOENIX CONTACT...

  • Page 65: El Ppc10S 1000

    Front: IP65 / Enclosure Type 4X (indoor use only) Rear: IP20 Total weight About 2400 g Approvals Intel® Atom™ E3845: UL / cUL Class I, Division 2, Groups A, B, C and D AMD Embedded G-Series: UL / cUL PHOENIX CONTACT 8584_en_04...

  • Page 66: El Ppc12S 1000

    Front: IP65 / Enclosure Type 4X (indoor use only) Rear: IP20 Total weight About 2400 g Approvals Intel® Atom™ E3845: UL / cUL Class I, Division 2, Groups A, B, C and D AMD Embedded G-Series: UL / cUL 8584_en_04 PHOENIX CONTACT...

  • Page 67: El Ppc12 1000

    Front: IP65 / Enclosure Type 4X (indoor use only) Rear: IP20 Total weight About 2300 g Approvals Intel® Atom™ E3845: UL / cUL Class I, Division 2, Groups A, B, C and D AMD Embedded G-Series: UL / cUL PHOENIX CONTACT 8584_en_04...

  • Page 68: El Ppc15S 1000

    Front: IP65 / Enclosure Type 4X (indoor use only) Rear: IP20 Total weight About 3900 g Approvals Intel® Atom™ E3845: UL / cUL Class I, Division 2, Groups A, B, C and D AMD Embedded G-Series: UL / cUL 8584_en_04 PHOENIX CONTACT...

  • Page 69: El Ppc15 1000

    Front: IP65 / Enclosure Type 4X (indoor use only) Rear: IP20 Total weight About 3900 g Approvals Intel® Atom™ E3845: UL / cUL Class I, Division 2, Groups A, B, C and D AMD Embedded G-Series: UL / cUL PHOENIX CONTACT 8584_en_04...
  • Page 70 CAN ..............53 Intended use ..............7 RS-485 ..............47 Interface Touch screen .............. 40 CAN............... 51 RS-232 ..............49 RS-422 ..............46 Unpacking..............8 RS-485 ..............46 USB............... 44 Version................ 37 Maintenance ............... 56 Maintenance interval........... 56 8584_en_04 PHOENIX CONTACT...
  • Page 71 EL PPCXX 1000 PHOENIX CONTACT 8584_en_04...
